- Page 1 Analog Resistive Touch Screen Controller TSC-55/RU User’s Guide...
-
Page 2: Table Of Contents
7. Warranty ..........................10 7.1. Warranty Period ..........................10 7.2. Warranty Target ..........................10 7.3. Warranty Exceptions ........................10 8. Precautions for Use ......................11 8.1. General Handling ..........................11 8.2. Others............................... 11 Dimensional Drawing Document No. DER-S0189A Rev.2.0 ©2021 DMC Co., Ltd. -
Page 3: Product Overview
This specification is applicable to TSC-55/RU. 1.2. Overview TSC-55/RU is 5 wire touch screen controller board that performs an A/D conversion of an analog signal of a 5 wire resistive touch screen, and transmits the coordinate data to the host in a 10-bit resolution serial correspondence at 9600bps and USB. -
Page 4: Peripheral Composition Overview
The detected voltage in supply side is higher than the GND side, which means ‘A_in’=Vcc at the point ‘E’ and ‘A_in’=0(*1) at the point ‘A’. TSC-55/RU calculates coordinates data starting from A/D conversion of the ‘A_in’ voltage. The Y-coordinates is measured in the same way. By repeating this process alternately, coordinate value at the input point is determined. -
Page 5: Specifications
Performance Specifications Description Rating Note (1) point mode (2) 30p/s (3) 50p/s Default: 150p/s with DMC original Coordinate Output Rate (point/sec) (4) 80p/s (5) 100p/s driver software. (TSC-DD) (6) 130p/s (7) 150p/s The value will be lower in the active... -
Page 6: Connector
RS-232C Data Output RS-232C Data Input RS-232C GND Power Input *1: When you use it at 3.3V of the serial mode, please do not connect TSC-55/RU to Vbus of CN4. 3.2. The mounted connector Manufacturer RE-H052SD-1110 J.S.T. Mfg Co., Ltd S5B-PH-K-S J.S.T. -
Page 7: Interface Type
TSC-55/RU User’s Guide 4. Interface type TSC-55/RU has serial and USB interface type. You choose either type. You cannot use both these at the same time. (Notice) In the state that connected a serial and a USB cable to a computer, please do not start power on of TSC-55/RU and computer. -
Page 8: Packing Specification
TSC-55/RU User’s Guide 5. Packing Specification 5.1. Outline TSC-55/RU is wrapped up in the air packing of the prevention of static protection type and puts it in a packing box. 5.2. Packing material Outer case: 75 x 55 x 15 mm, clay coated newsback board... -
Page 9: Product Name Label
May : E Nov : K Jun : F Dec : L 09: Date manufactured ② S01: Control number for DMC use ③ 00001: Serial number (5 digits) Rev: Revision information (PbFree): lead free Data Matrix: lot number [3I09S0100001] can be read with a barcode reader. -
Page 10: Changes & Improvements
1.2. Overview: Added the description that EEPROM is built in TSC-55 / RU. 2. Specifications: Revised the operating temperature and storage temperature of general specifications. 5.4. Product name label: Corrected the QR code to Data Matrix. Document No. DER-S0189A Rev.2.0 ©2021 DMC Co., Ltd. -
Page 11: Warranty
§ If the product is remodeled, disassembled or repaired by the user. § If the product is glued onto the equipment and uninstalled. § Any malfunctions and damages caused by an improper usage and handling against the specifications and notes. Document No. DER-S0189A Rev.2.0 ©2021 DMC Co., Ltd. -
Page 12: Precautions For Use
This document can be freely distributed, but any alternation to this document is prohibited. DMC Co., Ltd. http://www.dmccoltd.com/english/ 11F Takanawa Sengakuji Ekimae Bldg., 2-18-10 Takanawa, Minato-ku, Tokyo 108-0074, Japan Phone: +81-3-6721-6731 (Japanese), 6736 (English) Fax: +81-3-6721-6732 Document No. DER-S0189A Rev.2.0 ©2021 DMC Co., Ltd.
