Before you start
Relax..
Have a tea or coffee.
V1.2-05/05/2021
Build within one month of receiving product.
Pressure Treated Only: Do not treat for the first
6 months following the delivery of your building.
Images are for illustration purposes only.
Mia Log Cabin
Product ID: 19351
Read the parts list and
acquaint yourself with the
sizes and quantities.
WARNINGS
Small parts - Choking Hazard.
Read through the instructions
and familiarise yourself with the
steps.
Adult assembly only
Minimum 2 people
4-6 Hours building time
based on building size and
experience
Made in
CE
Great
certified
Britain
Please read the instructions
carefully and retain for
future reference.
Kybotech, Claylands Avenue,
Worksop S81 7BQ
|
01909 768858

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mia 19351 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billyoh Mia 19351

Summary of Contents for Billyoh Mia 19351

  • Page 1 WARNINGS Build within one month of receiving product. Pressure Treated Only: Do not treat for the first 6 months following the delivery of your building. Small parts - Choking Hazard. Images are for illustration purposes only. Adult assembly only Minimum 2 people Mia Log Cabin Product ID: 19351 4-6 Hours building time...
  • Page 2 01909 768840...
  • Page 3 01909 768840...
  • Page 5 01909 768840...
  • Page 6 01909 768840...
  • Page 7 You will need: Your Installation Explained: Pilot Drilling Holes Pilot drill all screw holes to Customer Technical Document: Contains wall elevations, floor, roof, door and window options, packlists, bill of materials and avoid building kits. wood Packlist - Contains all wall and gable boards, strips, splitting.
  • Page 8 Step Step Step Build up the cabin wall boards another 4 layers, Place the first floor board inside the building flush to Continue adding the floor board (internally) making ensuring you complete each layer. Use a mallet and a the log board on one side. Fix the first board in place sure to interlock each board.
  • Page 9 Step Step Step Following the same process in stage 4, lay the next Place the first gable board on each side wall of the Proceed onto the next layer of the gable, by following board levels onto the assembly to finalise the base cabin, followed by the full length front wall board.
  • Page 10 Step Step Step Lay the purlins into the slots on the front and rear of the Please see the technical document for your cabin’s Continue adding the roof boards along the roof, fixing each building, Screw these in place using 50mm screws by one into position using 30mm nails, making sure that each roof board length.
  • Page 11 Step Step Step To affix the door frame into position, push the left door Following the process completed in stage 22, repeat Once you have affixed the door frame on the side of frame up against the wall boards as shown. Before again with the opposite side door frame.
  • Page 12 Step Step Step Place the glazing into the door frame as shown, once Once the glazing is fixed into position, affix the door Following the process in stage 28, carefully place the in position, use cardboard to protect the glazing when hinges onto the door frame with 30mm screws.
  • Page 13 Step Step Step Once the lower window is complete. Fix the upper To secure the edges around the window frame, Once complete, fix the window casement in the window frame into position by fixing the hinges as centre of the window frame, fix in place with 30mm place the window rebates as shown, fix in place shown.
  • Page 14 Step Step Step Lay the first roll of felt ensuring the felt is folded over Continue to lay the felt onto the cabin’s roof, Align the fascia’s with the roof and fix into place the edge as shown above. Ensure a 70mm overhang following the same process listed in step 40, fix the using 30mm nails, making sure to nail through the is maintained over both ends.
  • Page 15 Thank you for purchasing this BillyOh product, we hope you will be delighted with your new building for years to come, and if you are we’d love for you to leave a review at billyoh.com and send us pictures of your fully assembled building to @billyohcom on Instagram! If for whatever reason you are not satisfied with your purchase, you have any queries or you need...
