Assembly Guide -
Please read your Instructions thoroughly and please retain for future reference
Multiple Thickness's:
28mm/35mm and
44mm
Before
You
Start
1) Reacquaint yourself
with the parts on the Tech
Document.
Kent / Seattle Home Office Range
Build within 1 month of receiving product
44mm Modern option shown
Double Door Full Glazed
35mm Modern option shown
Double Door Full Glazed
2) Read the instructions
thoroughly and then
re-read if necessary.
W4.0m x D3.0m
W4.0m x D4.0m
3) Group all boards by Walls/Floor/Roof
together rst to make assembly easier.
Ensure all parts are there before assembly.
Double
Door Covered
CODE:
INS-0051
Treatment
4) We recommend to paint boards
after assembly to get the best
quality nish.
Please note that all images are for illustration purposes only.
V3.2-240120
Advertisement
Related Manuals for Billyoh INS-0051
Summary of Contents for Billyoh INS-0051
- Page 1 Double Door Covered W4.0m x D3.0m 44mm Modern option shown Double Door Full Glazed Multiple Thickness’s: CODE: 28mm/35mm and INS-0051 W4.0m x D4.0m 44mm 35mm Modern option shown Double Door Full Glazed Before Treatment 2) Read the instructions 4) We recommend to paint boards...
- Page 2 01909 768 858 PAGE 01 For Queries and Help please call Product Support: IMPORTANT SAFETY NOTICES GENERAL RECOMMENDATIONS Thank you for purchasing this building. We hope you will be delighted with your new building for many years to come. GARDEN BUILDINGS: THESE PRODUCTS ARE INTENDED FOR DOMESTIC AND OUTDOOR USE ONLY. These instructions have been written as a guide to assembling this building and will provide you with an overview of the process of constructing this building.
- Page 3 01909 768 858 PAGE 02 For Queries and Help please call Product Support: PRODUCT MAINTENANCE CHECK LIST: STORAGE/ASSEMBLY Level Base: We Recomend that the building is assembled within 1 month of recieving the building. maintaining the building. Seal The Windows: STORAGE - The timber pack must be kept raised Use a silicone sealant on the inside and outside of the windows as soon as possible after assembly is a strong way of sealing the windows.
- Page 4 Log Cabin Timber Movement PAGE 03 Maintenance: 2 weeks after build & on-going - Due to the nature of timber and the Interlocking style the building will want to settle and move. Follow the stages for the explanation of timber movement and the prevention/solution of issues.
- Page 5 0 1 9 0 9 7 6 8 8 5 8...
- Page 6 0 1 9 0 9 7 6 8 8 5 8...
-
Page 7: Exploded View
Exploded View - 44mm W4.0m x D3.0m Shown, please refer to tech details for specific building Roof Felt (Comes in roll(s)) Roof Assembly - T&G (RA) Finial (FI) Fascia Board (FB) Purlins (PU) Wall - D Wall - C Wall - E Wall - B Windows Double Door (DD) - Page 8 Exploded View - 35mm W4.0m x D4.0m Shown, please refer to tech details for specific building Roof Felt (Comes in roll(s)) Roof Assembly - T&G (RA) Finial (FI) Fascia Board (FB) Purlins (PU) Wall - D Wall - C Wall - E Wall - B Windows Double Door (DD)
- Page 9 01909 768 858 For Queries and Help please call Product Support: 28/35/44mm Bearer Layout Wall Board Fixing 28/35/44mm Bearer Layout 75PT-69.5 75PT-69.5 cut from cut from Front Bearer Front Bearer Back Back Back S50 x 6 75PT 75PT 75PT 75PT 75PT 75PT 75PT...
- Page 10 01909 768 858 For Queries and Help please call Product Support: Floor Assembly Floor Assembly 28, 35, 44mm Floor Assembly Back Front W4.0m x D4.0m N40 - 28/35/44mm N40 - 28/35/44mm Floors in 2 as shown Floor Assembly Floor Assembly Pile up atleast 4 Wall Boards before Build up the walls of the cabin in this order;...
- Page 11 01909 768 858 For Queries and Help please call Product Support: Gable Top S70 x 2 Continue building Place the Gable top on up the Wall Boards Gable Top S70 x 4 S50 x 4 S50 x 4 W4.0m x D3.0m W4.0m x D4.0m Repeat previous stage of Gable top assembly.
-
Page 12: Roof Assembly
01909 768 858 For Queries and Help please call Product Support: Line up the external Eaves Framing on top of front wall boards, use 3 x S50 per frame S70 x 4 per Purlin EF-01 28mm = 109mm Check the Tech Details 35mm = 102mm for the length required. - Page 13 01909 768 858 For Queries and Help please call Product Support: S30 x 6 S30 x 6 Line up the Door Threshold to the front of the Floor BB-01 x 2 BB-01 x 2 S50 x 4 DT x 1 1616mm 2054mm 2054mm...
- Page 14 01909 768 858 For Queries and Help please call Product Support: Fixing Window Glazing (Modern) Fixing Window Glazing (Georgian) Place the Glazing in the Place the Glazing in the around the edges around the edges PP x 14 PP x 14 S25 x 8 GL x 1 GL x 1...
- Page 15 01909 768 858 For Queries and Help please call Product Support: Window Latch Fixing Door Fixing Stage Fixing Door Glazing (Modern) Hinges Place the Glazing in the around the edges place PP x 36 S30 x 4 GL x 1 Back View of Doors Fixing the Door Lock Handle Fixing Door Glazing (Georgian)
- Page 16 01909 768 858 For Queries and Help please call Product Support: S30 x 10 Fix the Fix the Door Cloaking Door Cloaking Strip on the side of Strip to the door. frames on each side PP x 16 TBT-BL x 1 Bottom 1854mm 100mm...
- Page 17 01909 768 858 For Queries and Help please call Product Support: FR-F3 x 2 FR-F5 x 1 1873mm 1646mm S40 x 3 S40 x 6 Repeat previous stage for 1916mm EF-02 (x2) S40 x 6 Fixing Wall Framing 200mm 1290mm FR-F6 x 1 S40 x 2 FR-F4 x 2...
- Page 18 01909 768 858 For Queries and Help please call Product Support: Fixing Wall Framing Place the Eaves Cloaking Trim on the roof boards and wall boards meet. S40 x 8 2054mm Check the Tech Details for dimensions FR-02 x 2 EC-01 (x1) FR-F1 (x2);...
- Page 19 01909 768 858 For Queries and Help please call Product Support: 70mm overhang at each end Fold over Corner Tack to hold in place 100mm Repeat previous stages Fold over Eaves for this side For Shingles Roof Covering Only Cut the full roll of felt in half lenght ways Repeat previous stage Only 1 roll of felt is used...
- Page 20 01909 768 858 For Queries and Help please call Product Support: Facia Fixing Stage For Shingles Roof Covering Only For Shingles Roof Covering Only N30 x 6 100mm Use the Shingles Instructions FB-01 that come with the packs 1646mm Side Weather Fixing Stage Barge Board Fixing Stage SF-02 SF-01...
- Page 21 01909 768 858 For Queries and Help please call Product Support: Protect your building Protect your building Please refer to page 3 for Please refer to page 3 for the required building the required building maintenance for the seasonal maintenance for the seasonal timber movement timber movement...
