Glensound Signature Series User Manual
Analogue audio to dante interface 4 analogue audio inputs & outputs to dante network audio
Hide thumbs
Also See for Signature Series:
- Quick start manual (2 pages) ,
- User manual (19 pages) ,
- User manual (19 pages)
Related Manuals for Glensound Signature Series
Summary of Contents for Glensound Signature Series
- Page 1 AoIP44 Analogue Audio To Dante Interface 4 analogue audio inputs & outputs to Dante network audio User Guide Glensound 6 Brooks Place, Maidstone Kent, UK, ME14 1HE Tel: +44 (0)1622 753662 www.glensound.co.uk...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to highlight that This symbol is intended to warn that there are important operating & dangerous voltages within the product are maintenance instructions in the literature present and constitute a risk of electric accompanying this unit. - Page 4 IMPORTANT: MAINS PLUG WIRING INSTRUCTIONS This Signature unit is supplied with a moulded mains plug fitted to the AC mains lead. Mains wiring colours/ connections: The Green/ Yellow or Green wire must be connected to the terminal in the plug marked ‘E’...
- Page 5 Emissions: EN55103.1 Immunity: EN55103.2 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR RoHS2 DIRECTIVE EC directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment.
-
Page 6: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workmanship and that the... -
Page 7: Table Of Contents
AoIP44 Handbook Contents Issue 2, Description Page No. Contents IMPORTANT SAFETY INSTRUCTIONS ........................3 PRODUCT WARRANTY: ..............................6 OVERVIEW ..................................8 PHYSICAL INSTALLATION ..............................9 AUDIO BLOCK DIAGRAM ..............................11 EXAMPLES OF USE ................................12 1. Interface To Existing Dante Newtork ........................12 2. -
Page 8: Overview
OVERVIEW The Glensound AoIP44 is an economical subrack designed to interface balanced analogue audio circuits to and from a network audio system featuring Dante. It provides 4 audio inputs to the network and also 4 audio outputs from the network on balanced 3 pin XLRs. -
Page 9: Physical Installation
PHYSICAL INSTALLATION The Glensound Signature Series have been designed to be highly versatile for installation and can be installed in 19” racks with either their front or rear panels facing the front of the rack. They can also be mounted underneath desks or work tops and can be either permananetly mounted or stood (using the supplied feet) on top of desks or worktops. - Page 10 SWAPPING RACK EARS TO ALLOW THE REAR TO BE INSTALLED AT THE FRONT OF A RACK PART No Signature Series PWR ON Keeps Working PIN 1 = GND PIN 2 = +12V (100mA) PIN 3 = -12V (100mA) 100-240V +/-12V - - - 50/60Hz 2.7 Watts First remove the 4 silver button head screws that fix the rack ears onto the front of the unit as shown in the top picture above.
-
Page 11: Audio Block Diagram
DANTE NETWORK AUDIO DC:DC CONVERTER NETWORK INTERNAL FUSE +12V 100 - 240 VAC AC/DC PSU -12V AUDINATE ULTIMO EXT DC +/-12V CHIPSET ANALOGUE DIGITAL TO TO DIGITAL ANALOGUE ANALOGUE AUDIO IN ANALOGUE AUDIO OUT CONVERTER CONVERTER MICROPROCESSOR... -
Page 12: Examples Of Use
The AoIP44 is located in the commentary booth, and connected into the broadcast network via a single CAT5/6 cable. The Glensound GS-CU001B is the most widely used commentary unit by broadcasters. It provides a programme mix output (direct outputs also available), and has 3 talkback outputs. -
Page 13: Interface To News/ Voiceover Studio
2. Interface To News/ Voiceover Studio Programme Send With Stereo Return Monitoring News Studio Control Room News Control 2 x XLR3 2 x XLR3 2 x XLR3 2 x XLR3 stereo stereo (balanced or (balanced or Studio Room programme programme unbalanced) unbalanced) (balanced or... -
Page 14: User Indicators
USER INDICATORS 1. Power On LED 2. Network LED Power On LED The front panel bright blue LED lights when power is available from either the internal mains power supply or the external DC input. Network LED The front panel Network LED is on when data is being transferred to/ from the network. It is not unusual for this LED to flicker quickly. -
Page 15: Rear Panel Connectors
REAR PANEL CONNECTORS 4. Network 3. Audio Outputs 5. Audio Inputs 6. DC In 7. Mains In Network The Neutricon RJ45 connector provides connectivity to your IP network Audio Outputs Four balanced analogue audio outputs are provided for the return audio from the Dante network on Neutrik XLR plugs. -
Page 16: Connecting The Aoip44 To A Dante Network
CONNECTING THE AoIP44 TO A DANTE NETWORK The AoIP44 is a network audio device utilizing the reliable and versatile Dante audio over IP protocol. Dante is a proprietary system (although very widely used) the originators of which are Audinate. The information below is only meant as a very basic guide. Full details of the power of Dante network audio and instructions for using it can be found at www.audinate.com Getting Dante Controller... -
Page 17: Running Dante Controller
Running Dante Controller At the time of writing this manual, Dante Controller looks as per the screenshot below: The AoIP44 will have been named at the factory during test to allow them to be identified by the Dante controller. The format used for the factory name is: ‘AOIP44-serial-XXXX-YYYYYY’. -
Page 18: Updating The Ultimo Chipset
AoIP44. 1. Finding Out What The Latest Available Version Is Go the AoIP44’s’s web page at http://www.glensound.co.uk/product-details/aoip44/ open the ‘Firmware Latest Version’ Tab. This will give both the latest version numbers/ file names and also the location to download the file from. -
Page 19: Wiring Information
WIRING INFORMATION STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth XLR SOCKET (FEMALE) 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - XLR PLUG (MALE) EXTERNAL DC INPUT: PIN 1: GND PIN 2: +12V PIN 3: -12V 4 PIN XLR PLUG (MALE) Page 19 of 20... -
Page 20: Technical Specification
TECHNICAL SPECIFICATION AUDIO POWER Frequency Response <= 0.25dB Mains Input Flat until 22k Filtered IEC, 100 to 240VAC 47 - 63Hz Maximum Input Before Clip AC Consumption +18dBu 4.3 Watts @ 230VAC Maximum Output Level DC Input +18dBu FEATURES 4 Pin Neutrik XLR. +12v 240mA, -12v N/A Input Impedance Internal Mains Fuse >20k Ohm...
