Summary of Contents for Glensound TR-12
- Page 1 TR-12 Large Screen TimeCode Viewer With 12 Distributed Outputs MANUAL E&EO...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at:...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to highlight that there are important This symbol is intended to warn that dangerous operating & maintenance instructions in the literature voltages within the product are present and constitute accompanying this unit. a risk of electric shock. This product is fitted with an internal ceramic fuse cartridge. -
Page 4: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workmanship and that the Customer shall return the goods to the... -
Page 5: Eu Declaration Of Conformity
Timecode Viewer This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union harmonisation legislation:... - Page 6 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR RoHS2 DIRECTIVE EC directive EN 63000:2018 restricts the use of the hazardous substances listed below in electrical and electronic equipment.
- Page 7 Timecode Viewer & Distribution OVERVIEW The Glensound TR-12 is a timecode reader. From an analogue input there is a large format display for maximum clarity of the timecode. Four XLR outputs of the timecode are provided, along with eight further analogue outputs on a d-type 25 pin connector.
- Page 8 Input Select & Signal Integrity A green push button scrolls through the available inputs: analogue, Dante channel 1, or Dante channel 2. Please note that Dante inputs are only available if the optional Dante input module is installed. An LED indicates the incoming signal integrity: ∞...
- Page 9 REAR PANEL LAYOUT & FUNCTIONS A. VAC Mains Input IEC connector for 100-240VAC mains input. The TR12 does not operate on PoE. B. Timecode Dante Input/Output In analogue only mode this port will be blanked off. If the Dante option has been fitted, this will be an RJ45 network Ethercon connection for connecting to a Dante/AES67 network.
- Page 10 Getting Dante Controller If you are connecting the TR-12 to a new Dante network the first thing you will need to do is to get the free Dante controller software from Audinate. This can be downloaded by visiting Audinate’s web site at www.audinate.com...
- Page 11 The format used for the factory name is: ‘TR12-SN-XXXX’ Where ‘TR12’ refers to the Glensound product. The ‘SN-XXXX’ refers to the serial number of the TR12 Dante module which can be found printed on the unit. The unit may be renamed in Dante controller by opening the ‘Device view’ window and selecting TR12 in the drop-down menu.
- Page 12 Device not showing up in Dante Controller If your Dante device does not show up in Dante Controller then the most likely issue is that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server.
-
Page 13: Aes67 Mode
TR12 can be set to AES67 mode for interaction with other AES67 devices. Please note however that Glensound are relying on Audinate’s AES67 interface and are unfortunately not able to provide full AES67 support for the unit. AES67 support should be sought directly from Audinate. - Page 14 Sending AES67 Audio To transmit AES67 audio to the network a multicast flow must first be setup. This is done by selecting the ‘Create New Multicast Flow’ Icon in the Device View. Tick the AES67 Flow check box, then select channels to be included in the flow then click ‘Create’...
- Page 15 Receiving AES67 Audio Once a compatible AES67 stream is detected on the network by Dante Controller the AES67 flows will appear in the Dante Transmitters section in the Routing tab. AES67 Restrictions AES67 flows can only be generated with the following constraints: ...
- Page 16 Updating the Dante firmware The TR12 has Dante specific firmware that runs inside its chipset. Updating the device The firmware that runs in the TR12 can be updated using the built-in Dante Updater in Dante Controller. Please ensure you have a connection to the internet. If you want to update devices on a Dante network that is not connected to the Internet, you can download the files ahead of time to your computer, move the computer to the offline network, and then update the devices using the downloaded files.
- Page 17 Caution! Audio will be interrupted during the device update B. Press to update device A. Tick box to confirm Update is in progress A. Update finished. Tick box to B. Press to continue reboot device Update finished, device will now reboot E&EO...
-
Page 18: Wiring Information
Wiring Information STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth 2: INPHASE/ POSITIVE/ LINE + 3: MATE/ NEGATIVE/ LINE - Output Bottom Number Phase Mate Ground Phase...
