- Page 1 BEA TRICE LUCIA Party-Line Dante Interface PRODUCT DETAILS Glensound Electronics Ltd BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.com FAX: +44 (0) 1622 762330...
- Page 2 Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions Keep these instructions Heed all warnings Follow all instructions Do not use this apparatus near water Clean only with a dry cloth Do not block any ventilation openings. Install in accordance with manufacturer’s instructions Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat Do not defeat the safety purpose of the polarized or grounding type plug. - Page 4 PRODUCT WARRANTY All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years.
-
Page 5: Eu Declaration Of Conformity
Party-Line Dante/ AES67 interface This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union... -
Page 6: Rohs Directive
RoHS DIRECTIVE RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for these purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%... -
Page 7: Waste Electrical And Electronic Equipment Regulations 2006 (Weee)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR... -
Page 8: Table Of Contents
GLENSOUND BEATRICE LUCIA HANDBOOK CONTENTS Description Issue 1.3 Page No. Contents IMPORTANT SAFETY INSTRUCTIONS ..............3 EU DECLARATION OF CONFORMITY ................5 RoHS DIRECTIVE ......................6 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) ... 7 HANDBOOK CONTENTS ..................... 8 Contents ........................ - Page 9 Receiving AES67 Audio ..................25 AES67 Restrictions ....................25 SMPTE 2110-30 MODE ................... 26 UPDATING THE BROADWAY CHIPSET ..............27 Finding Out Current Installed Version ................. 27 Finding Out What The Latest Available Version Is ............27 Updating the device ....................27 Equipment needed .....................
-
Page 10: Overview
OVERVIEW The BEATRICE LUCIA allows Dante and 2 Wire intercom units to communicate with one another and is available in 1 and 2 module versions. Each module can be set to interface with either the Clear-Com or RTS single channel party-line (two wire) intercom standard or the RTS two audio channel partyline standard. -
Page 11: Lucia Front Panel Layout
CURRENT DRAW IF MAXIMUM CURRENT IS EXCEEDED MAINS ALL LEDS www.glensound.com WILL FLASH WET POWER ONLY AVAILABLE FROM MAINS PoE Power LED This indicates that the unit is being powered by Power Over Ethernet (POE). In this mode the unit cannot supply power (wet) to the party-line intercom. -
Page 12: Lucia Party-Line Circuits
LUCIA Party-Line Circuits PARTY-LINE CIRCUIT A CH 1 CH 2 AUDIO TO Clear-Com Tecpro PARTY-LINE 400 Ohms NULL AUDIO FROM PARTY-LINE MODE POWER IMPEDANCE NULL 1. Clear-Com Tecpro Mode Indicator This indicates the party-line is set to interface with the Clear-Com two wire standard (which is also used by Tecpro (amongst others)). - Page 13 7. 400 Ohm Impedance Indicator When the unit is in RTS Wet mode and this LED is off, the audio on pin 2 has a line impedance of 200 ohms. When the 400 Ohm LED is on the audio on pin 2 has a line impedance of 400 ohms. This allows two power supplies each with an output impedances of 400 ohm to be run in parallel on the party-line maintaining a 200 ohm line impedance for the audio signal.
- Page 14 13. Audio from Party-Line CH 1 Indicator This indicates the level of the audio being sourced from the party-line intercom XLR pin 3 and sent to the Dante/ AES67 network. When the null process is underway, in conjunction with the send indicator (12) this acts as a progress bar indicating how much of the null process remains.
-
Page 15: Lucia Rear Panel Layout
21. SFP Fibre Network Port A standard SFP Fibre network interface module can be fitted into this port. SFP modules are available in many different formats, if required Glensound can supply suitable SFP modules, contact sales@glensound.com for further information. -
Page 16: Party-Line Outputs
Party-Line Outputs PARTY-LINE XLR PARTY-LINE PARTY-LINE WIRING CIRCUIT A CIRCUIT B FOR RTS: PIN 1: COMMON PIN 2: POWER+CH2 PIN 3: CH1 FOR CLEAR-COM/ TECPRO PIN 1: COMMON PIN 2: POWER XLRS CONNECTED IN PARALLEL XLRS CONNECTED IN PARALLEL PIN 3: CH1 22. -
Page 17: Lucia Functions
LUCIA FUNCTIONS Auto null In order to null the unit, depress and hold the null control for a minimum of 3 seconds, upon release the unit will start the null process. If the unit is in Clear-Com mode, channel 1 will be nulled taking approximately 30 seconds. -
Page 18: Call Signal
Network Audio Mixers The Beatrice Lucia uses the Broadway chipset from Audinate as its network audio interface. The variant of the Broadway that we use in the Lucia is 8 audio channels in and out. As only 4 audio channels are required for the two party-line interfaces we have 4 ‘spare’... -
Page 19: Lucia Audio Block Diagram (Analogue Representation Of Digital Circuits)
LUCIA AUDIO BLOCK DIAGRAM (analogue representation of digital circuits) -
Page 20: Connecting The Beatrice Unit To A Dante Network
CONNECTING THE BEATRICE UNIT TO A DANTE NETWORK The Beatrices are network audio devices utilizing the reliable and versatile Dante audio over IP protocol. Dante is a proprietary system (although very widely used) the originators of which are Audinate. The information below is only meant as a very basic guide. Full details of the power of Dante network audio and instructions for using it can be found at www.audinate.com Getting Dante Controller... -
Page 21: Running Dante Controller
Running Dante Controller At the time of writing this manual the Dante Controller looks as per the screenshot below: The Beatrice LUCIA will have been named at the factory during test to allow them to be identified by the Dante controller. -
Page 22: Device Not Showing Up In Dante Controller
Device not showing up in Dante Controller If your Dante device does not show up in Dante Controller then the most likely issue is that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server. -
Page 23: Aes67 Mode
Beatrice can be set to AES67 mode for interaction with other AES67 devices. Please note however that Glensound are relying on Audinate’s AES67 interface and are unfortunately not able to provide full AES67 support for the unit. AES67 support should be sought directly from Audinate. -
Page 24: Sending Aes67 Audio
Sending AES67 Audio To transmit AES67 audio to the network a multicast flow must first be setup. This is done by selecting the ‘Create New Multicast Flow’ Icon in the Device View. Tick the AES67 Flow check box, then select channels to be included in the flow then click ‘Create’... -
Page 25: Receiving Aes67 Audio
Receiving AES67 Audio Once a compatible AES67 stream is detected on the network by Dante Controller the AES67 flows will appear in the Dante Transmitters section in the Routing tab. AES67 Restrictions AES67 flows can only be generated with the following constraints: ... -
Page 26: Smpte 2110-30 Mode
SMPTE 2110-30 MODE The Broadway chipset from Audinate that is used for the network interface of the Beatrice Lucia has been made SMPTE 2110-30 compliant by Audinate. However the only way of turning on SPTE 2110-30 and correctly setting it is by using Audinate’s ‘Dante Domain Manager’... -
Page 27: Updating The Broadway Chipset
Dante/ AES67 network audio streams. There is one Broadway Chipset in each Beatrice LUCIA. We supply special code (a .dnt file) that sets up/ initiates the Broadway Chipset and makes it work in particular way that is compatible to the Beatrice. -
Page 28: Equipment Needed
GIGABIT ETHERNET Figure 2 USB connector Connect the Beatrice Lucia to the PC via the USB cable. The micro USB connector is located on the rear panel of the Beatrice Lucia. Page 28 of 33... - Page 29 USB device. 5. Loading the firmware Now open DfuSe Demo. If the Beatrice Lucia successfully entered DFU mode then it will appear as ‘STM Device in DFU Mode’ under the ‘Available DFU Devices tab’. Figure 3 Device successfully recognised Now the .dfu file needs to be selected so that DfuSe Demo knows the correct...
- Page 30 Figure 4 Choose .dfu file Click choose and then select the .dfu file that you downloaded from the Glensound website. This will be located in your downloads folder by default. If the file loads successfully then it will read along the bottom ‘File correctly loaded’.
- Page 31 6. Upgrading the Beatrice Lucia firmware The firmware is now ready to be put on to the Beatrice Lucia. Tick the ‘Verify after download’ box first and then click ‘Upgrade’. Figure 6 Upgrade Click yes to proceed. Figure 7 Start upgrade The progress bar along the bottom will show the status of the operation.
- Page 32 Figure 9 Successful upgrade! 7. Final steps Now click “Leave DFU mode” to finish the procedure. Figure 10 Final step You may now disconnect the USB cable and continue to use the Beatrice Lucia with the freshly updated firmware! Page 32 of 33...
-
Page 33: Specifications
SPECIFICATIONS NETWORK/ Dante® PARTY-LINE AUDIO Frequency Response Physical Interface 1 off RJ45 & 1 off SFP slot Network to Party Line <-2dB 230Hz to 8.1kHz (-3dB @ 200Hz & 9.1kHz) Party Line to Network <-2dB 230Hz to 8.5kHz (-3dB @ 200Hz & 8.7kHz) (Can be set to work in redundant mode) Gain Control Audio...
