- Page 1 POWER STATION Back-up Power Supply for Signature Series Audio Racks User Guide Glensound 6 Brooks Place, Maidstone Kent, UK, ME14 1HE Tel: +44 (0)1622 753662 www.glensound.co.uk...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to highlight that This symbol is intended to warn that there are important operating & dangerous voltages within the product are maintenance instructions in the literature present and constitute a risk of electric accompanying this unit. - Page 4 IMPORTANT: MAINS PLUG WIRING INSTRUCTIONS This Signature unit is supplied with a moulded mains plug fitted to the AC mains lead. Mains wiring colours/ connections: The Green/ Yellow or Green wire must be connected to the terminal in the plug marked ‘E’...
- Page 5 Power Station for Signature Series This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union harmonisation legislation:...
- Page 6 RoHS DIRECTIVE RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for this purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%...
- Page 7 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page 7 of 19...
-
Page 8: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workmanship and that the... -
Page 9: Table Of Contents
PS1 Power Station Handbook Contents Issue 1, Description Page No. Contents IMPORTANT SAFETY INSTRUCTIONS ........................3 PRODUCT WARRANTY: ..............................8 OVERVIEW ................................. 10 PHYSICAL INSTALLATION............................11 EXAMPLES OF USE ..............................13 Master DC Power Supply ..........................13 Redundant DC Power Supply ........................14 USER CONTROLS &... -
Page 10: Overview
The master AC power input accepts 100 – 240 VAC for Worldwide compatibility. As well as providing a backup DC supply for up to six Signature Series units, the PS1 can also act as a master DC power distribution to six Signature units. -
Page 11: Physical Installation
PHYSICAL INSTALLATION The Glensound Signature Series have been designed to be highly versatile for installation and can be installed in 19” racks with either their front or rear panels facing the front of the rack. They can also be mounted underneath desks or work tops and can be either permananetly mounted or stood (using the supplied feet) on top of desks or worktops. - Page 12 SWAPPING RACK EARS TO ALLOW THE REAR TO BE INSTALLED AT THE FRONT OF A RACK PART No Signature Series PWR ON Keeps Working PIN 1 = GND PIN 2 = +12V (100mA) PIN 3 = -12V (100mA) 100-240V +/-12V - - - 50/60Hz 2.7 Watts First remove the 4 silver button head screws that fix the rack ears onto the front of the unit as shown in the top picture above.
-
Page 13: Examples Of Use
Series units. There are 6 x ±12VDC outputs. Each of these can connected to any single Signature Series unit, providing it with the primary power source. The PS1 must be connected to a 100-240VAC mains power supply in order to distribute DC power to the other Signature units. -
Page 14: Redundant Dc Power Supply
Each Signature unit connects to a 100V - 240V AC supply as normal. The PS1 has 6 x ±12VDC outputs. Each of these connects to any single Signature Series unit, providing it with the redundant power source. In the event of a failure of the AC power supply on the Signature units, the PS1 will simply take over and ensure that the unit remains operational. -
Page 15: User Controls & Connections
USER CONTROLS & CONNECTIONS FRONT PANEL 1. PSU ON LEDS PSU ON LEDS The two front panel PSU LEDs are each connected to the output of one of the two internal power supplies. If these LEDs are on then the unit is functioning correctly. Page 15 of 19... -
Page 16: Psu 2 Outputs
PSU 2 Outputs These three DC power outputs are fed from one of the two internal power supplies. Each one can be connected to an associated input on a Signature Series unit to provide DC power to that unit. Each output is individually fused so a short on one output or other external problem on that output will not affect any other devices connected to the PS1. -
Page 17: Maximum Current Output
MAXIMUM CURRENT OUTPUT IMPORTANT: MAXIMUM OUTPUT CURRENT Each Glensound Signature rack has printed on its rear panel near the 4 pin XLR DC input connector the maximum current consumption of that rack for both its postive and negative DC input rails. -
Page 18: Wiring Information
WIRING INFORMATION DC OUTPUTS: PIN 1: GND PIN 2: +12V PIN 3: -12V 4 PIN XLR SOCKET (FEMALE) Page 18 of 19... -
Page 19: Specifications
SPECIFICATIONS POWER PHYSICAL Mains Input Size Filtered IEC, 100 to 240VAC 336 x 123 x 44mm (LxDxH) no rack ears 47 - 63Hz 482mm (19”) 1RU with rack ears AC Consumption Weight 0.85kg 10 Watts @ 230VAC DC Output Mechanics FEATURES 6 off 4 Pin Neutrik XLR plug ±...
