ASSEMBLY INSTRUCTIONS
®
RiverRidge
Ladder Wall Shelf
ITEM #: 02-154/06-096 WHITE
ITEM #: 02-155/06-097 GRAY
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken in
unpacking and assembling this item to keep small parts away from children.
WARNING
SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don't use
this item for a TV stand or place heavy objects on top of item. Always use
angle-braces or anchors to secure furniture to the wall.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 02-154/06-096 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RiverRidge 02-154/06-096

Summary of Contents for RiverRidge 02-154/06-096

  • Page 1 ASSEMBLY INSTRUCTIONS ® RiverRidge Ladder Wall Shelf ITEM #: 02-154/06-096 WHITE ITEM #: 02-155/06-097 GRAY ADULT ASSEMBLY REQUIRED This product requires assembly by an adult because of small parts. Care should be taken in unpacking and assembling this item to keep small parts away from children.
  • Page 2 THIS SHELF UNIT WILL HOLD UP TO 20 POUNDS PER SHELF OR A TOTAL OF 60 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 20 POUNDS OR 60 POUNDS TOTAL WEIGHT. IF OVERLOADED WITH MORE THAN 20 POUNDS PER SHELF OR 60 POUNDS TOTAL WEIGHT, SHELF MAY TIP FROM WALL AND CAUSE SERIOUS INJURY OR DEATH.

  • Page 3: Parts List

    PARTS LIST DESCRIPTION TOP SHELF LEFT RAIL BOARD TOP SHELF RIGHT RAIL BOARD MIDDLE SHELF LEFT RAIL BOARD MIDDLE SHELF RIGHT RAIL BOARD BOTTOM SHELF LEFT RAIL BOARD BOTTOM SHELF RIGHT RAIL BOARD TOP SHELF MIDDLE SHELF BOTTOM SHLF 3PCS REAR RAIL BOARD REAR LOWER BACK BOARD LEFT SIDE FRAME...
  • Page 4 PARTS LIST PART DESCRIPTION WOOD DOWEL 22PCS MACHINE SCREW (6 X 20MM) 12PCS 27PCS WOOD SCREW (3.5 X 25MM) 5PCS WALL SCREW (4 X 30MM) 2PCS PLASTIC ANCHOR 3PCS WOOD PEG TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED) THE USE OF POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY TOOL NEEDED FOR SECURING TO WALL: POWER DRILL (NOT INCLUDED) To order replacement parts at no cost to you, email customer.service@ssi-rr.com,...
  • Page 5 STEP 1 1. Insert 1 wood dowel (A) into wood dowel hole on end of rear rail board (10). 2. Attach top shelf left rail board (1) to rear rail board (10) by inserting wood dowel (A) into hole on top shelf left rail board (1).
  • Page 6 STEP 3 1. Insert 1 wood dowel (A) into wood dowel hole on end of rear rail board (10). 2. Attached bottom shelf left rail board (5) to rear rail board (10) by inserting wood dowel (A) 3. into hole on bottom shelf left rail board (5). 4.
  • Page 7 STEP 5 1. Insert 4 wood dowels (A) into wood dowel holes on middle shelf (8). 2. Attach middle shelf (8) to pre-assembled middle shelf left rail board (3), middle shelf right rail board (4) and rear rail board (10) by inserting wood dowels (A) into wood dowel holes on middle shelf left rail board (3), middle shelf right rail board (4) and rear rail board (10).
  • Page 8 STEP 7 1. Insert 4 wood dowels (A) into wood dowel holes on end of rear lower back board (11). 2. Attach 3 wood pegs (F) to rear lower back board (11) by inserting 3 wall screws (D) through holes on rear lower back board (11) and tighten to wood pegs (F).
  • Page 9 STEP 9 1. Attach the pre-assembled top shelf (7) and rail boards to right side frame (13) by inserting 2 machine screws (B) through holes on top shelf left rail board (1) and tighten to right side frame (13). 2. Repeat above steps to assemble middle shelf (8) and bottom shelf (9) to right side frame (13). 3.
  • Page 10 ATTENTION ADULTS: Cabinet should be checked periodically for damage or loose screws/parts. Take appropriate action necessary to correct hazards such as tightening of screws and taking any damaged parts away from children. WARNING Please make sure your item is secured to the wall, per assembly instructions.
  • Page 11 ® Thank you for purchasing this RiverRidge Home item. We hope you ® enjoy it and consider purchasing other RiverRidge items. To order replacement parts at no cost to you, email customer.service@ssi-rr.com, call 1-(844)-223-5201 or order parts online at www.riverridgehome.com ®...
