- Page 1 ELEVATION ™ SERIES 95T TREADMILL & PLATINUM CLUB SERIES TREADMILL DISCOVER SE3, DISCOVER SI, & EXPLORE ASSEMBLY INSTRUCTIONS M051-00K92-0000 REV F...
- Page 2 21 Wong Chuk Hang Road marketing.benelux@lifefi tness.com HONG KONG Operating Hours: 9.00h-17.00h (CET) Telephone: (+852) 2575.6262 Fax: (+852) 2575.6894 Service Email: HongKongEnquiry@lifefi tness.com Sales/Marketing Email: * Also check www.lifefitness.com for local representation or distributor/dealer Marketing.HK.Asia@lifefi tness.com Operating Hours: 9.00h-17.00h Service Operating Hours: 9.00h-18.00h...
- Page 3 AVERTISSEMENT: Des problèmes de santé peuvent être causés par une utilisation incorrecte ou excessive de l’équipement. LIFEFITNESS recommande FORTEMENT de consulter un médecin pour subir un examen médical complet avant de commencer tout programme d’exercice, et tout particulièrement si l’utilisateur a des antécédents familiaux d’hypertension ou de troubles cardiaques, s’il a plus de 45 ans, s’il fume, s’il a du choles-...
-
Page 4: Table Of Contents
Table of Contents 1. Getting Started ................4 1.1 Important Safety Instructions . -
Page 5: Getting Started
Getting Started 1.1 Important Safety Instructions Read all instructions before using the LIFE FITNESS treadmill. DANGER: To reduce the risk of electrical shock, always unplug Life Fitness products before cleaning or attempting any maintenance activity. WARNING: To reduce the risk of burns, fi re, electric shock, or injury, it is imperative to connect each product to a properly grounded electrical outlet. - Page 6 Use these products for their intended use as described in this manual. Do not use attachments that have not been recommended by the manufacturer. Keep the power cord away from heated surfaces. Do not pull the equipment by the power cord or use the cord as a handle.
- Page 7 1.1 Consign s De S curit Importantes É É É Lire toutes les instructions avant d’utiliser le tapis roulant. DANGER:Pour réduire les risques de décharge électrique, toujours débrancher cet appareil Life Fitness avant lenettoyage ou toute mesure d’entretien. AVERTISSEMENT:Pour réduire les risques de brûlures, d’incendies, de décharges électriques ou de blessures, chaque appareil doit absolument être branché...
- Page 8 Laisser les consoles ACL se « normaliser » pendant une heure quant à la température avant le branchement et l’utilisation de l’appareil. Cet appareil ne doit être employé que pour l’usage auquel il est destiné, conformément aux directives du manuel.
-
Page 9: Set-Up
1.2 Set-Up Read the entire manual before setting up the Life Fitness Treadmill. Place the treadmill where it will be used before beginning the setup procedure. Electrical Power Requirements The Life Fitness Treadmill requires a dedicated* line with isolated neutral according to the electrical confi gurations listed in the chart below. - Page 10 How to Position and Stabilize the Life Fitness Treadmill Follow all safety instructions. Move the treadmill to the location in which it will be used. Note: To center the striding belt see Section 2.5 How to Adjust and Tension the Striding Belt. Safety Clearances The following information is supplied as regional reference data regarding safety clear- ances around the exterior of the treadmill.
- Page 11 Install Coaxial & Ethernet Cables (if necessary) - Discover SE3 and Discover SI Consoles Only (Explore Optional) The following connection receptacles are located at the front of the Elevation Series 95T Treadmill with Discover Con- soles: Coaxial Cable (A), and ...
- Page 12 Power Cord Routing WARNING: Make sure the power cord is unplugged before attempting to route it around or through the treadmill. The POWER CORD (A) can be run to the user-front left or right sides. Excess POWER CORD can be bundled and tied to the pre-installed CLIPS (B) located under the front of the treadmill.
-
Page 13: Service And Technical Data
Service and Technical Data 2.1 Preventive Maintenance Tips Life Fitness products are backed by the engineering excellence and reliability of Life Fitness and are one of the most rugged and trouble-free pieces of exercise equipment on the market today. Note: Safety of the equipment can be maintained only if the equipment is examined regularly for damage or wear. Keep the equipment out of use until defective parts are repaired or replaced. -
Page 14: Preventive Maintenance Schedule
2.2 Preventive Maintenance Schedule Item Weekly Monthly Biannually Console Overlays Clean Inspect Bottle Holders / Accessory Trays Clean Inspect Console Mounting Bolts Inspect Hardware Inspect Frames Clean Inspect Plastic Covers Clean Inspect Inspect Lifepulse Sensors Clean / Inspect Striding Belt Centered Inspect Machine Level * Inspect... -
Page 15: Troubleshooting The Treadmill
2.3 Troubleshooting the Treadmill Malfunction Probable Cause Corrective Action ON / OFF switch is not in proper posi- Turn the switch to the ON position. tion. Plug treadmill into an appropriate circuit. Refer to Grounding Instructions. Note: In North America use a dedicated 20 amp circuit for Commercial Units or a 15 Power source is insuffi... - Page 16 Troubleshooting the Treadmill (continued) Malfunction Probable Cause Corrective Action Check levelers and level treadmill. Striding belt slips off- Check striding belt & re-tension as Floor surface is uneven. center. necessary. Refer to How to Adjust and Tension the Striding Belt. User is pushing striding belt.
- Page 17 Troubleshooting the Treadmill (continued) Malfunction Probable Cause Corrective Action Plug treadmill into an appropriate circuit. Refer to Grounding Instructions. Note: In North America use a dedicated 20 Power source is insuffi cient. amp circuit for Commercial Units or a 15 amp circuit for Consumer Units.
-
Page 18: Troubleshooting The Optional Polar
® 2.4 Troubleshooting the Optional Polar Telemetry Heart Rate Chest Strap Heart Rate Reading is Erratic or Absent Entirely Malfunction Probable Cause Corrective Action Belt transmitter electrodes are not wet enough to pick up accurate heart rate Wet the belt transmitter electrodes. readings. -
Page 19: How To Adjust And Tension The Striding Belt
2.5 How to Adjust and Tension the Striding Belt Do not move the treadmill or place hands under the treadmill while it is plugged into an electrical outlet! The Belt Tensioning Bolts A 5/16-inch hex key wrench is required for this task. The Life Fitness Treadmill has access holes (A) in the rear roller guards which allow access to the tensioning bolts. -
Page 20: How To Obtain Product Service
Tensioning an Existing Striding Belt 1. Press GO and operate the treadmill for fi ve minutes at 5.0 MPH (8.0 KPH). Note: DO NOT RUN OR WALK ON BELT. 2. Reduce the speed to 2.0 MPH (3.2 KPH). Walk on the treadmill. Tightly grip the handrails and apply force with feet on the striding belt near the motor cover against the moving belt direction. -
Page 21: Assembly
Assembly Component List Tools Required: • #2 Phillips screwdriver • 4mm, 5mm, 8mm Allen Head Drivers (T-Bar recommended) Part Description Part Description Foam Strip Upright (Left) Right Side Extrusion M12 x 1.75 Hex Button Head Screw (SILVER) Left Upright Cover M12.5 Washer Upright (Right) Right Upright Cover... - Page 22 Hardware M6 X 14 BUTTON HEAD SCREW (#7) M12.5 WASHER (#3) M6 X 25 BUTTON HEAD SCREW (#36) M6.5 WASHER (#8) M6 X 20 SOCKET HEAD SCREW (#31) M5 X 10 PHILLIPS PAN HEAD SCREW (#17) #10 X 8 PHILLIPS PAN HEAD SCREW (#22) M5 X 14 PHILLIPS PAN HEAD SCREW (#37) #8 X 12 PHILLIPS PAN HEAD SCREW (#28) M6 X 35 BUTTON HEAD SCREW (#33)
- Page 31 31 31 8 31 31 31 Discover SE3 & SI ONLY...
- Page 32 Discover SE3 & SI ONLY...
- Page 33 Discover SE3 & SI ONLY Explore ONLY 34 35...
- Page 34 11 12 11 12 Explore ONLY Discover SE3 & SI ONLY...
- Page 35 Discover SE3 & SI ONLY...
- Page 36 EXPLORE ONLY...
- Page 38 24 a Discover SE3 Discover SI Discover SE3 IPTV...
- Page 39 24 b Explore...
- Page 41 Explore ONLY...
- Page 42 28 a...
- Page 43 28 b...
- Page 46 Coaxial Cable External Ethernet Cable...
- Page 47 MAKE SURE ALL HARDWARE IS TIGHT! ASSUREZ-VOUS QUE TOUTE LA VISSERIE EST BIEN SERRÉE ! CONTROLEER OF ALLE BEVESTIGINGEN GOED VAST ZITTEN! SICHERSTELLEN, DASS ALLE BEFESTIGUNGSTEILE FESTGEZOGEN SIND! ASSICURARSI CHE TUTTA LA BULLONERIA SIA BE N STRETTA ASEGÚRESE DE QUE TODAS LAS PIEZAS ESTÉN BIEN APRETADAS. ASSEGURE-SE DE QUE TODAS AS PEÇAS ESTÃO APERTADAS! TÜM DONANIMIN SIKI OLDUĞUNU KONTROL EDİN! УБЕДИТЕСЬ, ЧТО...
-
Page 48: Specifications
Specifications 4.1 Life Fitness Treadmill specifications Designed use: Elevation Series 95T: Heavy/Commercial Platinum Club Series: Home Maximum user weight: 400 pounds / 181 kilograms Speed range: Elevation Series 95T: 0.5 - 14.0 MPH (0.8 - 23 KPH) in 0.1 increments Platinum Club Series: 0.3 - 12.0 MPH (0.5 - 19 KPH) in 0.1 increments Elevation range:...
