VIBIA Halley Assembly Instructions

Design by jordi vilardell & meritxell vidal

Advertisement

1
Tube of thermal grease
2
Allen key
3
Lamp structure
4190.
Net Weight 1,5 Kg
4195.
Net Weight 1,3 Kg
Caution
Before assembling and installing this product, carefully read the following:
-Switch of the mains before installing the lamp.
-If the steel cable or the power cord of this lamp is damaged, it must be replaced only by the manufacturer or their technical service or by a person capacitated to this effect to avoid
any risk.
-We recommend reading the manual before installaing the lamp. Keep this instructions for future reference.
Halley
Design by Jordi Vilardell & Meritxell Vidal
ASSEMBLY INSTRUCTIONS

SUPPLIED MATERIAL

4190
1 un.
1 un.
1 un.

TECHNICAL SPECIFICATIONS

1 x LED STRIP 24V 5,7W
1 x LED STRIP 24V 2,8W
1.
4195
1 un.
1 un.
1 un.
2.
4190.
Class I. Product with an additional protection cable (grounds).
Dust-tight product. Protected against water trickles.
Product that CAN be in contact with normally-flammable
materials (wood or others).
3.
4195.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Halley and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VIBIA Halley

  • Page 1 Halley Design by Jordi Vilardell & Meritxell Vidal ASSEMBLY INSTRUCTIONS SUPPLIED MATERIAL 4190. 4195. 4190 4195 1 un. 1 un. Tube of thermal grease 1 un. 1 un. Allen key 1 un. 1 un. Lamp structure TECHNICAL SPECIFICATIONS Class I. Product with an additional protection cable (grounds).
  • Page 2 ASSEMBLY INSTRUCTIONS IMPORTANT NOTICE: Mains power cable Caution : to avoid possible electrical shock, make certain electricity is shut off at main panel before wiring Ø13,5 cm. 1. Make a hole in the ground of Ø13.5cm and 18.5cm deep to set the casing (B) into, and provide a gravel drainage system 20-30cm deep if the ground is sandy.
  • Page 3 ASSEMBLY INSTRUCTIONS 4. Connect to the mains: Step 1: Remove the 4 screws from the wiring box and open up the cover (D). Second: Loosen the cable gland (E) in order to insert the cable (C) into the wiring box. Third: Make the electrical connection, phase+neutral in the box (F) and grounding to the terminal (G).

This manual is also suitable for:

41904195
