Caution
Before assembling and installing this product, carefully read the following:
-At least two people are needed to install and desinstall the lamp.
-If the steel cable or the power cord of this lamp is damaged, it must be replaced only by the manufacturer or their technical service or by a person capacitated to this effect to avoid
any risk.
-We recommend reading the manual before installaing the lamp. Keep this instructions for future reference.
Halley
Design by Jordi Vilardell & Meritxell Vidal
ASSEMBLY INSTRUCTIONS
SUPPLIED MATERIAL
4160
1 un.
1 un.
1 un.
TECHNICAL SPECIFICATIONS
1 x LED STRIP 24V 21,6W
1.
2.
C
Class I. Product with an additional protection cable (grounds).
Dust-tight product. Protected against water spray.
Product that CAN be in contact with normally-flammable
materials (wood or others).
3.
B
A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VIBIA Halley
Summary of Contents for VIBIA Halley
- Page 1 Halley Design by Jordi Vilardell & Meritxell Vidal ASSEMBLY INSTRUCTIONS SUPPLIED MATERIAL 4160 1 un. Carry bag 1 un. Base 1 un. Profiles set (A), (B) y (C). TECHNICAL SPECIFICATIONS Class I. Product with an additional protection cable (grounds). 4160.
