Quincy QR-25 Series Instruction Manual

Hide thumbs Also See for QR-25 Series:
Table of Contents

Advertisement

Quick Links

QR-25
Series
®
Instruction Manual
This manual contains important safety information and must be
carefully read in its entirety and understood prior to installation
by all personnel who install, operate and/or maintain this product.
On-line product registration, parts ordering and warranty information is available at www.quincycompressor.com
Manual No. 52201-107
January 2014 Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QR-25 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Quincy QR-25 Series

Summary of Contents for Quincy QR-25 Series

  • Page 1 QR-25 Series ® Instruction Manual This manual contains important safety information and must be carefully read in its entirety and understood prior to installation by all personnel who install, operate and/or maintain this product. On-line product registration, parts ordering and warranty information is available at www.quincycompressor.com Manual No.

  • Page 2: Table Of Contents

    SECTION 6 TROUBLESHOOTING Troubleshooting ............................. 29 SECTION 7 REFERENCE INFORMATION Approximate Capacity Correction for Altitude ..................33 Average Intercooler Pressures ......................34 Decal Locations ............................35 QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 3: Safety First

    At Quincy Compressor safety is not only a primary concern, but a faithfully performed practice. Beginning with the design stage, safety is built into every Quincy compressor. It is the inten tion of this manual to pass along the “safety first” concept to you by providing safety precautions throughout its pages.
  • Page 4 •Be sure that all tools, shipping and installation debris have been removed from the compressor and installation site prior to starting the compressor. Do not operate a Quincy Compressor in excess of 250 PSIG unless WARNING ! it has been tested and certified for high pressure application by Quincy Compressor prior to shipment.

  • Page 5: Summary Of Changes

    40 ft. of #4 gauge cable (GND & HOT). The owner, lessor or operator of any compressor unit manu factured by Quincy Compressor is hereby warned that failure to ob serve the safety precau- tions and procedures outlined in this manual may result in serious personal injury, damage to property, and may void your warranty.

  • Page 6: System Dynamics

    From there the compressed air is released through a discharge valve to an air receiver tank or directly to a network of compressed air supply lines. In one revolution of the crankshaft a compression cycle is completed. QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 7: Principles Of Lubrication Systems

    The idea is to create com pressed air on demand, but to limit the number of times a motor must start the compressor in a given time QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...
  • Page 8 Pix 5093 Fig. 2-5 Control Version LVD *1, 2, or 4 unloader towers are employed depending upon the model of compressor. QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 9: Specifications

    200/250 **Maximum continuous pressure is indicated on left side, maximum intermittent high pressure on right side. †High pressure basics required for pressures above 250 PSIG applications. QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 10: Installation

    If concealed damage is discovered at a later date, the carrier must be notified within 15 days of initial receipt of freight. Concealed ship- ping damage is not covered by Quincy Compressor Warranty. Contact the carrier as soon as possible, giving them an opportunity to inspect the ship-...

  • Page 11: Location

    Location Quincy air compressors must be installed and operated in a secure, upright position in an area that is clean, dry, well lighted, adequately ventilated and not closer than 24 inches to a wall or another compressor. (Note: A gas engine will produce carbon monoxide;...

  • Page 12: Electrical Supply Requirements

    Care must be taken when constructing total enclosures or baffle walls. If not properly constructed or positioned, they could contribute to unacceptable noise levels or over heating. Consult your local Quincy Com- pressor distributor if assis tance is required.

  • Page 13: Mounting

    Mounting Proper mounting of Quincy compressor units is crucial to the safe operation and longevity of the equipment. The installation requires a flat and level concrete floor or pad (for mobile units see Mounting Mobile Units). Satis- factory results can usually be obtained by mounting horizontal tank units on vibration isolators available from your local Quincy distributor.

  • Page 14: Wiring Schematics

    QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...
  • Page 15 QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 16: Induction System

    A clean, cool and dry air supply is essential to the satisfactory operation of your Quincy air compressor. The standard air filter that the com pressor is equipped with when leaving the factory is of sufficient size and design to meet normal...

  • Page 17: Compressed Air Discharge System

    If, however, the compressor is to be installed in a location where consid- erable dust, dirt and other contaminants are prevalent, consult your local Quincy distributor for advice and optional filters. A condensate trap must be installed as close as possible to the inlet filter if, as a result of installation or environmental conditions, there is any risk of moisture forming in the inlet piping.
  • Page 18 (refer to Fig. 3-2, Typical Drop Leg & Component Location). The compressed air supply line from the air receiver of a stationary unit must be equipped with a pressure and heat rated flexible connection. QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...
  • Page 19 (e.g. air hoses, metal air lines, pneumatic tools, spray guns). An in-line filter or dryer, available from your local Quincy distributor, may be re quired to eliminate the moisture. Condensation in the air tank can be kept to a mini- mum by draining the tank on a daily basis.
  • Page 20 120 Gal. Horizontal .131 .162 120 Gal. Vertical .163 .199 200 Gal. Horizontal .163 .199 240 Gal. Horizontal .163 .199 Fig. 3-5 Recommended Air Tank Inspection Intervals QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 21: Start-Up & Operation

    Open all manual shutoff valves at and beyond the compressor discharge. Step 12) After all the above conditions have been satisfied, the unit can be connected to the proper power source. QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 22: Initial Starting & Operating

    If there are any questions regarding any part of the instructions, please call your local Quincy distributor, or the Quincy Compressor factory. CAUTION ! When using battery cables to start engine driven units do not use more than a total of 40 ft.
  • Page 23 Quincy Compressor recommends that a new or rebuilt reciprocating compressor should be run for a total of 100 hours at full discharge operating pressure to break­in the new piston rings. Until the rings are seated, the compressor will discharge higher than normal amounts of lubricant. In light of this fact, the lubricant level should be checked more frequently during the 100 hour break­in period.

  • Page 24: Maintenance & Lubrication

    Check the lubricant level several minutes after the compressor has run. (Discoloration or a higher lubricant level reading may indicate the presence of condensed liquids.) If lubricant is contaminated, drain and replace. QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 25: Lubrication

    / starter. Lubrication QR-25 Series compressors are normally shipped with lubricant in the crankcase. Before starting your compressor, check the lubricant level in the crankcase. The lubricant should register between the high and low marks on the dipstick.

  • Page 26: Pulley / Sheave Alignment & Belt Tension

    It will support the performance characteristics and life designed into all Quincy compressors and is highly rec ommended. Refer to the charts below to determine the correct amount of lubricant and viscosity to use for your model and applica tion.
  • Page 27 Recheck the tension of the new belts several times in the first 50 hours of operation and adjust if necessary. Thereafter, check belt tension on a regular basis (refer to SECTION 5, Maintenance Schedule). QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 28: Pressure Switch Adjustment

    Pressure Switch Adjustment Pressure switches provided by Quincy Compressor are pre­set at the factory and usually do not require adjustment. However, the following procedures can be performed by a qualified electrician to adjust the pressure switch. Step 1) Remove the pressure switch cover.
  • Page 29 TO THE OIL FILTER OIL RETURN PORT FROM THE OIL FILTER COUNTERSUNK PIPE PLUG Pix 1154 Fig. 5-6 Relocating Countersunk Pipe Plug *Not applicable to models without oil pumps. QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 30: Pilot Valve Adjustments

    Step 5. Loosen locknut (counterclock- ceed to Step 7. wise).* Stabilize with back-up Step 7. Tighten locknut (clockwise) wrench! with wrench. * Stabilize with back-up wrench! QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 31: Troubleshooting

    •Incorrect speed •Compressor valves not functioning properly •Loose pulley/sheave •Motor or engine out of balance •Compressor, motor or engine not secured tightly, or tightened into a bind QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...
  • Page 32 •Compressor valves in second stage broken or not functioning properly (Two stage models only) •Pilot valve or pressure switch set incorrectly or defective •Pressure gauge defective QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...
  • Page 33 •Piston loose in cylinder bore, cylinder bore worn, piston or piston rings worn •Worn rods or main bearing •Wrong pressure setting, discharge pressure excessive •Crankcase lubrication inadequate •Loose pulley/sheave •Compressor valve assemblies loose QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...
  • Page 34 UE TO PUSH THE RESET BUTTON! •Loose or broken wire Contact your local Quincy distribu- •Motor defective tor for assistance. •Compressor seized Motor stalls •Motor overloaded (refer to Excessive current draw) QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 35: Reference Information

    The result will be the actual capacity (CFM) of the compressor at the given altitude. QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 36: Average Intercooler Pressures

    48.5. 49.0 41.0 46.0 50.0 50.5 42.0 47.0 51.5. 52.0 43.0 53.0 53.5 44.0 54.0 55.0 45.0 55.5 57.0 46.0 57.0 58.5 47.0 58.5 60.0 48.0 QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...

  • Page 37: Decal Locations

    Decal Locations Typical QR-25 Unit with Horizontal Receiver Typical QR-25 Unit with Vertical Receiver QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...
  • Page 38 Typical Engine Driven QR-25 Unit with Horizontal Receiver QR-25 Series Quincy Compressor 52201-107, January 2014 3501 Wismann Lane, Quincy IL - 62305-3116...
  • Page 41 ENVIRONMENTAL AND OSHA REQUIREMENTS: At the time of in transportation or procuring materials, or causes of any kind beyond Seller’s shipment of the equipment from the factory, Quincy Compressor / Ortman Fluid Power will comply with the various Federal, State and local laws and control.
  • Page 42 Reciprocating / Systems: 217.222.7700 Air Master 217.277.0270 E-mail: info@quincycompressor.com Website: quincycompressor.com...
