- Page 1 SUW49DA2 CURVED GAMING MONITOR USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
-
Page 3: Table Of Contents
Table of Contents Section 1: Safety Precautions..............4 Section 2: Box Contents .................5 Section 3: Product Overview ..............6 3.1 – Monitor Buttons .................6 3.2 – Monitor Ports ................6 Section 4: Remote Control ..............7 Section 5: Stand Installation ..............8 Section 6: Wall Mounting................9 Section 7: Basic Operation ..............10 Section 8: Indicator Light ...............10 Section 9: OSD ..................11... -
Page 4: Section 1: Safety Precautions
VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter. -
Page 5: Section 2: Box Contents
Section 2: Box Contents Stand Stem x 1 Monitor x 1 (with Attached Bracket) Stand Base x 1 15 mm NO. 2 Screws x 4 Remote Control x 1 NO. 1 Screws x 4 (for Mounting) Power Cable x 1 DP Cables x 2 Screwdriver x 1 User Manual x 1... -
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off. -
Page 7: Section 4: Remote Control
Section 4: Remote Control : Press to turn the monitor on or off. : Press to switch between HDMI or DP input. : Press to enter the OSD menu or press to confirm. : After entering the OSD settings menu, press any of the arrow buttons to move within the menu. -
Page 8: Section 5: Stand Installation
Section 5: Stand Installation Keep the foam underneath the monitor before attaching the stand. Open the package and take out the monitor with foam still attached. Gently place it top- down on a desktop or table. And remove the upper foam. 2. -
Page 9: Section 6: Wall Mounting
Section 6: Wall Mounting This monitor ONLY includes screws which may be used when attaching the monitor to a mount. No mount or mounting accessory is included. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. -
Page 10: Section 7: Basic Operation
It is compatible with GPUs that use AMD® FreeSync™ or NVIDIA® G-Sync™. The feature is off on VIOTEK monitors by default and must be manually enabled in the monitor’s OSD (see Section 9: OSD). To use this feature, the connecting device must be compatible with adaptive sync (FreeSync and/or G-Sync);... -
Page 11: Section 9: Osd
Section 9: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration. -
Page 12: Osd Menu Functions
9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description Input Source HDMI 1; NONE Switch to HDMI signal input HDMI 2; DP 1, DP 2 NONE Switch to DP signal input Brightness/ Brightness 0~100 Adjust display brightness Contrast Blacklevel 0~100 Adjust display black level Contrast... - Page 13 Main Menu Sub-Menu Options Description Multi-Window Multi-Window Off, PBP 2Win, Select PBP modes according to the PBP 4Win number of input signals etc. Sub Win2 Input DP 1, DP 2, HDMI Select according to input signal for PBP 1, HDMI 2 mode Sub Win 3 Input DP 1, DP 2, HDMI Select according to input signal for PBP...
-
Page 14: Section 10: Display Mode And Gameplus Switching
Section 10: Display Mode and Gameplus Switching Press any one of the buttons (M, , E, ) to activate the navigation window. 2. Press ( ) to switch Gameplus modes. According to the needs of your game, choose the corresponding game icon. These game icons are primarily designed to optimize your aim during shooting games, though they can be used for other scenarios. -
Page 15: Pbp (Picture By Picture) Resolution Information
The color bleeds or visual effects appear unusual. • If your screen is all red or blue, or any colors disappear, check to see that the cable is properly inserted. A loose connection can cause a bad signal. • Try connecting to another video source for comparison. The screen appears to be scrolling, rolling, or moving unusually. -
Page 16: Section 12: Information
Section 12: Information 12.1 – Specifications Item Detail Model Number SUW49DA2 Screen Size 49’’ Curvature 1800R Viewing Angle H178° / V178° Panel Type Aspect Ratio 32:9 Resolution 5120x1440 Backlight E-LED Typical Brightness 400cd/m (Typ), 350cd/m (Min) Default Color Temperature 6500K... -
Page 17: Section 13: Cleaning
Warranty services are provided by Viotek Warranty Pro (“WP”). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;... - Page 18 longer made or stocked. This Warranty is not assignable or transferable. The original purchaser may call WP’s toll-free number at 1-855-229-9472 for service requests. When a product or part is exchanged, any replacement item becomes your property and the replaced item becomes WP’s property.
- Page 20 COPYRIGHT © 2022 VIOTEK. ALL RIGHTS RESERVED.
