  • Page 1 FERRARI T H E L E G E N D A RY 1 9 7 0 F 1 F E R R A R I PAC K SCALE...

  • Page 2: Table Of Contents

    FERRARI SCALE Contents STAGE 43 ..........1 BRAKE AIR INTAKE © Agora Models STAGE 44 ..........5 WISHBONE ARMS STAGE 45 WARNING: NOT SUITABLE PARTS TO SECURE SUSPENSION TO FOR CHILDREN UNDER THE ..............9 CHASSIS AGE OF 14. THIS PRODUCT IS...

  • Page 3: Brake Air Intake

    312 T4 PACK 06 BRAKE AIR INTAKE WITH THE PARTS INCLUDED IN THIS STAGE, YOU CAN CONTINUE BUILDING THE SECOND FRONT WHEEL BRAKE. LIST OF PARTS LIST OF PARTS Air intake (outer) Hubcap Air duct (inner) Brake disc support F E R R A R I 3 1 2 t4 Pa c k 0 6 .
  • Page 4 43-01 Place the two parts of the brake air intake together on your work surface, so they are facing the direction shown in the image. You can see the interlocking structures that allow you to press the two parts together. 43-02 Join the two parts by pressing them together so that the...
  • Page 5 43-03 Take the brake assembly that you built in the previous stage and place it alongside the air intake, as shown in the photo. The brake assembly has two pins (yellow circles) and a reference mark (yellow arrow); the air intake has two holes and a small recess.
  • Page 6 43-05 Now take the brake disc support. Join it to the brake disc. The pins and fixing holes mean they can simply snap together. Final result You have just completed another important step in building the brake assembly on the second front wheel. In the next stage In the next stage Parts for the front right...

  • Page 7: Wishbone Arms

    PACK 06 WISHBONE ARMS STAGE 44 INCLUDES THE PARTS THAT SERVE TO BUILD THE RIGHT FRONT SUSPENSION OF YOUR 1:8 SCALE FERRARI 312 T4. USING THESE INSTRUCTIONS, YOU CAN START TO BUILD THIS MECHANICAL ASSEMBLY. type C screws type D screws...
  • Page 8 44-01 Place the upper wishbone and the shock absorber on your work surface. Rest the shock absorber plate in the seat highlighted by a circle in the image (pay attention to the reference notch – highlighted by the arrow in the photo –, which needs to match with the recess in the shock absorber plate).
  • Page 9 44-03 Take the lower wishbone arm and the steering slider. There are two columns to secure the brake assembly, shown by the circle in the image. 44-04 Now it is the turn of the lower wishbone arm. In this case too, you should look at the images to ensure the parts are facing the right way.
  • Page 10 C screw. Final result Now you have started to build the right front suspension of your 1:8 scale Ferrari 312 T4. In the next stage In the next stage New parts for the right front suspension and the screws needed to assemble the parts.

  • Page 11: Parts To Secure Suspension To Chassis

    TO CHASSIS NOW YOU HAVE THE PARTS YOU NEED TO COMPLETE THE RIGHT FRONT SUSPENSION AND SECURE IT TO THE CHASSIS OF YOUR FERRARI 312 T4. type D screws type E screws type G screws type L screws LIST OF PARTS...
  • Page 12 45-01 Take the cockpit cradle and the sheath provided with stage 30. Insert the three tubes from the console on the left of the steering wheel into the sheath. 45-02 Now place the cockpit cradle on the underbody, starting from the front. Press the rear section until the two pins (shown inside the inset photo) have slotted perfectly into the relevant columns.
  • Page 13 45-04 Use the hex-head screw to join the 45-05 Join the ends of the lower wishbone upper wishbone arm to the front and rear links. arm to the rear joint of the suspension and the Make sure the parts are facing the right way, as master cylinder support.
  • Page 14 G screws. Final result Now you have fastened the front right suspension to your 1:8 scale Ferrari 312 T4. Place the model in a safe place. In the next stage In the next stage The suspension mounting brackets and joints, together with the screws needed for assembly.

  • Page 15: Left Suspension Joints And Wishbone Arms

    E screws WITH THE CONTENTS OF THIS STAGE YOU CAN SECURE THE FRONT LEFT SUSPENSION TO THE CHASSIS, COMPLETING THE FRONT OF YOUR 1:8 SCALE FERRARI 312 T4. type F screws type G screws type N screws LIST OF PARTS...
  • Page 16 46-01 Place the two joints on the left side of the chassis and secure them with two type D screws. 46-02 Join the ends of the lower left suspension arm (which you built in the assembly stage for stage 6) to the rear suspension joint and the master cylinders support.
  • Page 17 46-04 Take the front wheel, a type L screw and the hubcap, included in previous stages. Fix the wheel to the left front suspension assembly using the type L screw. 46-06 Take a close look at the image of the wishbone arms.
  • Page 18 Final result You have completed the assembly of the mechanical parts in the front section of your 1:8 scale Ferrari 312 T4. Place the model in a safe place. F E R R A R I 3 1 2 t4...

  • Page 19: Brake Line Fittings And First Steering Parts

    312 T4 PACK 06 BRAKE LINE FITTINGS AND FIRST STEERING PARTS NEXT YOU'LL BE ASSEMBLING THE BRAKE LINES. THESE CAN BE BUILT WITHOUT ADDING THE METAL LINER, BUT INCLUDING IT GIVES A MORE REALISTIC RESULT. LIST OF PARTS LIST OF PARTS type E screws type J screws Reinforcement plate for steering...
  • Page 20 47-01 Take a length of the same metal wire used to tie the spark plug cables (stage 18). Take the brake lines, installed on the master cylinders in the assembly steps in stage 39 and then removed in stage 41. Insert a piece of metal wire into one of the brake lines.
  • Page 21 47-04 Thanks to the metal wire inside the brake lines, these can be shaped as required. Bend the two lines so that they take on the approximate shape you can see in the image. 47-05 Glue the finished lines to the master cylinders and bottom pistons of the callipers.
  • Page 22 Final result Now you have fastened the front brake lines of your 1:8 scale Ferrari 312 T4. In the next stage In the next stage The left and right sides of the bodywork and some screws.

  • Page 23: Left And Right Sides Of Bodywork

    LEFT AND RIGHT SIDES OF THE BODYWORK FOLLOW THE INSTRUCTIONS TO FIT THE NOSE TO YOUR MODEL AND COMPLETE THE STEERING MECHANISM OF YOUR 1:8 SCALE FERRARI 312 T4. type P screws LIST OF PARTS LIST OF PARTS Left side of bodywork...
  • Page 24 48-01 Join the nose to the monocoque so that 48-02 To finish the upper hook of the nose is lined up with the fastening the nose, top of the monocoque. Tighten in place with a insert and tighten type E screw. two type F screws in the position shown in the images.
  • Page 25 48-04 The ends of the rack must be secured to the steering arms from the wheel hubs, using two type E screws Make sure not to over-tighten the screws. 48-05 Move the steering column to the correct position, so that the pinion teeth mesh with those on the rack.
  • Page 26 48-06 Now place the protective plate of the steering joint in the position shown in the photograph. Secure the plate using three type J screws as shown in the inset. 48-07 Then fit the reinforcement plate sub-frame of the steering wheel to the model.

  • Page 27: Cross Wrench And Drag Link Plates

    LINK PLATES FOR THIS ASSEMBLY, YOU'LL JOIN THE ENGINE ASSEMBLY TO THE COCKPIT OF YOUR 1:8 SCALE FERRARI 312 T4. LIST OF PARTS LIST OF PARTS Cross wrench Cover plate for left drag link B Cover plate for right drag link B...
  • Page 28 49-02 Tighten a type P screw on the right side of the monocoque so that the assembly is stable. Do the same for the left side of the model. 49-01 Join the engine and monocoque assemblies together. 49-03 Use another type P screw to fasten the top of the...
  • Page 29 49-04 Recover the previously assembled fire extinguisher, built in stage 37 (see the inset image). Fit it to the model, inserting the two fastening pins on the plate into the holes identified in the previous step. 49-05 The left side (stage 48) presses into the monocoque using the three jointed columns, as highlighted in the image.
  • Page 30 Final result You have now joined the engine and cockpit. Your 1:8 scale Ferrari 312 T4 is starting to take shape! In the next stage In the next stage Left-hand radiator parts. F E R R A R I 3 1 2 t4...

  • Page 31: Left Hand Radiator Parts

    312 T4 PACK 06 LEFT-HAND RADIATOR PARTS DURING THE ASSEMBLY PROCESS ILLUSTRATED ON THESE PAGES, YOU WILL BE FITTING THE DRIVER’S SEAT IN THE MONOCOQUE. FOLLOW OUR INSTRUCTIONS AND THE ACCOMPANYING IMAGES. LIST OF PARTS LIST OF PARTS Left radiator main body Rear support with fitting Front support Radiator grille...
  • Page 32 50-01 Take the cover plates for the left drag link. An “L” printed on the parts makes it easier to identify them. Insert part A upwards from the bottom, then turn it and then press it into place with your fingers until its position is correct.
  • Page 33 50-04 Take the seat and pass the seatbelt 50-05 through its openings, as shown in the image. Lift the belts in the monocoque. 50-06 You can now fit the seat on board the model. F E R R A R I 3 1 2 t4 Pa c k 0 6 .
  • Page 34 50-07 There are two appendages on the front 50-08 The seat has two front fixing points and of the seat, which must be placed to the sides two in the rear. Press down on the front of the of the steering column plate. seat,and also close to the central seat belt, so that the fixing pins are correctly inserted.

  • Page 35: Right Hand Radiator Parts

    312 T4 PACK 06 RIGHT-HAND RADIATOR PARTS THE STEPS FOR THIS STAGE DO NOT INVOLVE THE PARTS PROVIDED, STORE THEM AWAY FOR NOW. INSTEAD, YOU'LL CONTINUE TO WORK ON THE COCKPIT USING PARTS PROVIDED IN PREVIOUS STAGES. LIST OF PARTS LIST OF PARTS Right radiator main body Radiator grille...
  • Page 36 51-01 Place the bottom part of the main 51-02 Fit the buckle of the corresponding belt buckle plate (stage 25), so that it is facing the to each of the pins. Then close the main buckle direction shown in the image. Apply a drop of plate, positioning the top part (also provided in cyanoacrylate adhesive to each of the four pins stage 25).
  • Page 37 51-04 Join this to the front support. 51-05 Use the joint elements to fit the rear support. 51-06 Fit the left radiator to the model, inserting the relevant pins into the assembly holes highlighted in the inset image. F E R R A R I 3 1 2 t4 Pa c k 0 6 .
  • Page 38 51-07 After joining it to the pipe, fit the nozzle on the left-hand radiator. Final result Now you have assembled the left radiator and fitted it to your model. In the next stage In the next stage The liquid coolant tank and its pipes.

  • Page 39: Coolant Fluid Tank

    312 T4 PACK 06 COOLANT FLUID TANK THESE INSTRUCTIONS WILL SHOW YOU HOW TO BUILD AND FIT THE RIGHT-HAND RADIATOR TO YOUR MODEL, USING THE PARTS FROM THE PREVIOUS STAGE. THE PARTS FROM THIS STAGE WILL BE USED IN THE FUTURE, SO KEEP THEM SAFELY ASIDE FOR NOW.
  • Page 40 52-01 Take the radiator body and its grille from 52-02 Use the pins and holes highlighted in the the parts provided with stage 51. Set the parts previous step and press the right radiator onto out on your work surface as they are in the its grille.
  • Page 41 52-04 Press the rear fitting onto the pins of the right radiator assembly highlighted in the previous step. 52-05 Press the front fitting onto the radiator assembly in the same way. F E R R A R I 3 1 2 t4 Pa c k 0 6 .
  • Page 42 52-06 Fit the right radiator to the model, inserting the relevant pins into the assembly holes highlighted in the inset image. Final result Now you have assembled the right radiator and fitted it to your model. In the next stage In the next stage New parts of the engine’s cooling system.
