  • Page 1 FERRARI T H E L E G E N D A RY 1 9 7 0 F 1 F E R R A R I PAC K SCALE...

  • Page 2: Table Of Contents

    FERRARI SCALE Contents STAGE 25 ..1 SEAT BELTS AND COCKPIT BACK PLATE STAGE 26 © Agora Models ..5 ROLL BAR AND REINFORCEMENT PLATES STAGE 27 HEADREST, FIRE EXTINGUISHER CONTROL, WARNING: NOT SUITABLE ......... 9 FOR CHILDREN UNDER THE AND BATTERY KILL SWITCH AGE OF 14.

  • Page 3: Seat Belts And Cockpit Back Plate

    312 T4 PACK 04 SEAT BELTS AND COCKPIT BACK PLATE YOU WILL NOW CONTINUE TO ASSEMBLE THE COCKPIT OF YOUR 1:8 SCALE RACING CAR, ATTACHING THE LEFT AND RIGHT SEAT BELTS. type J screws LIST OF PARTS LIST OF PARTS Screws Central belt Sponsor stickers...
  • Page 4 25-01 Using the designated interlocks, fix the left seat belt to the back plate. 25-02 In the same way, also fix the right seat belt to the back plate. Be careful with the orientation of the belts, which must look as shown in the images.
  • Page 5 25-05 Put together both of these components by fitting the openings on the plate on to the columns on the cradle (circled in the photograph) 25-04 Take the cockpit cradle. The image and inserting the end of the highlights the anchor points for the plate. plate into the cradle (arrow).
  • Page 6 Final result The cockpit cradle has been fitted with the back plate and the seat belts have been fixed in place. In the next stage In the next stage Roll bar and reinforcement plates. F E R R A R I 3 1 2 t4 Pa c k 0 4 .

  • Page 7: Roll Bar And Reinforcement Plates

    312 T4 PACK 04 ROLL BAR AND REINFORCEMENT PLATES STAGE 26 PROVIDES YOU WITH THE ROLL BAR AND ITS SIDE PLATES THAT FORM PART OF THE COCKPIT COMPARTMENT. IN THIS ASSEMBLY SESSION YOU WILL BE FITTING THESE NEW PARTS TO YOUR MODEL. type G screws LIST OF PARTS LIST OF PARTS...
  • Page 8 26-01 Lay the roll bar and the right-hand plate 26-02 Using the connections just identified, on your worktop. The image highlights the pins fit these two components together. If the on the plate and the corresponding holes in the coupling between the pins and holes is too roll bar structure.
  • Page 9 26-04 Retrieve the cockpit cradle. The illustration highlights the four holes that take the pins on the bottom of the roll bar structure. 26-05 Mount the roll bar on the cockpit cradle, using the four interlocks identified in the previous item. F E R R A R I 3 1 2 t4 Pa c k 0 4 .
  • Page 10 The headrest, the fire extinguisher control, and the battery kill switch. Final result The cockpit cradle of your 1:8 scale Ferrari 312 T4 now has its roll bar. F E R R A R I 3 1 2 t4 Pa c k 0 4 . S TA G e 2 6...

  • Page 11: Headrest, Fire Extinguisher Control, And Battery Kill Switch

    312 T4 PACK 04 HEADREST, FIRE EXTINGUISHER CONTROL, AND BATTERY KILL SWITCH THESE PARTS WILL BE USED TO ENHANCE THE INTERIOR OF YOUR MODEL WITH ADDITIONAL DETAILS. LIST OF PARTS LIST OF PARTS Headrest Switch Switch base F E R R A R I 3 1 2 t4 Pa c k 0 4 .
  • Page 12 27-01 Look carefully at the switch base. There is a small half-round hole at the centre of the cone. Insert the switch into the base and press these two parts together using the half-round hole. 27-02 Retrieve the cockpit cradle. The opening on the left-hand plate into which the switch base should be fitted is circled in the image.
  • Page 13 27-03 Fit the switch base into the left-hand plate, as shown in the images. 27-04 Finally mount the headrest, which has two holes on the back that must fit on to the pins on the roll bar. F E R R A R I 3 1 2 t4 Pa c k 0 4 .
  • Page 14 Final result More details have been fitted to the cockpit of your 1:8 scale Ferrari 312 T4. In the next stage In the next stage The extinguisher with the pressure gauge and the extinguisher valve. F E R R A R I 3 1 2 t4...

  • Page 15: Extinguisher, Pressure Gauge, And Extinguisher Valve Control

    312 T4 PACK 04 EXTINGUISHER, PRESSURE GAUGE, AND EXTINGUISHER VALVE CONTROL THESE PARTS ARE USED TO BUILD THE FIRE EXTINGUISHER ASSEMBLY, WHICH WILL BE POSITIONED BEHIND THE ROLL BAR ON YOUR MODEL. LIST OF PARTS LIST OF PARTS Fire extinguisher body Pressure gauge dial Valve base and pressure Extinguisher valve...
  • Page 16 28-01 Take the pressure gauge glass, the dial, and the base. Fit the pressure gauge dial into the pressure gauge base. The semi-circular connections will ensure that these are fitted correctly. 28-02 Now position the pressure gauge glass over th dial and press with your fingers to insert it into the front of the dial.
  • Page 17 28-04 Then join the base of the valve and the pressure gauge to the body of the fire extinguisher, using its designated mounting pin. 28-05 Retrieve the cockpit cradle and place it on your work surface. 28-06 Using the rectangular connections shown, attach the fire extinguisher to the cockpit cradle.
  • Page 18 Final result Having now completed the assembly procedures as described, you have put together the fire extinguisher and mounted it on the cockpit cradle of your 1:8 scale model. In the next stage In the next stage The cockpit cradle reinforcement brackets and the tank breather system.

  • Page 19: Tank Vent Valve And Reinforcement Brackets

    312 T4 PACK 04 TANK VENT VALVE AND REINFORCEMENT BRACKETS THE COCKPIT REINFORCEMENT BRACKETS AND THE COMPONENTS OF THE TANK VENT VALVE ARE SUPPLIED WITH THIS STAGE. LIST OF PARTS LIST OF PARTS Right-hand bracket Valve connector Left-hand bracket Valve Cable F E R R A R I 3 1 2 t4 Pa c k 0 4 .
  • Page 20 29-01 Retrieve the cockpit cradle and attach the right-hand bracket. Be careful: The end of the bolt on the bracket must face inwards (arrows). 29-02 In the same way, attach the left-hand bracket to the cradle. The ends of the two bolts should be facing each other (arrows).
  • Page 21 29-05 Using the two pins, fit the valve connector to the tank, which is represented by a black area on the top of the cockpit cradle. 29-06 Attach the valve to the left-hand side plate using the square pin. F E R R A R I 3 1 2 t4 Pa c k 0 4 .
  • Page 22 Final result You have now connected the support brackets and the tank breather system to the cockpit cradle assembly. In the next stage In the next stage The dashboard and steering wheel support frame, the pushbutton panel, and the cables connecting to the rear axle.

  • Page 23: Dashboard Frame, Cables, The Sheath, And Pushbutton Panel

    312 T4 PACK 04 DASHBOARD FRAME, CABLES, SHEATH, AND PUSHBUTTON PANEL YOU WILL NOW INSTALL THE DASHBOARD AND STEERING WHEEL FRAME, THE PUSHBUTTON PANEL, AND THE PLASTIC REPRODUCTION “CABLES” CONNECTING THIS ASSEMBLY TO THE REAR AXLE. LIST OF PARTS LIST OF PARTS Sheath Dashboard and Cables (230 mm)
  • Page 24 30-01 Place the frame and the three cables on your work surface. Measure the cables and check they are 230 mm long. If necessary, shorten them with a sharp knife. 30-02 The frame has three small pins close 30-03 Fit the remaining two cables using the together.
  • Page 25 30-04 Now take the pushbutton panel, which has two perforated columns. These must be fitted into the two pins on the frame (arrows). 30-05 Using the connection points highlighted in the previous step, mount the pushbutton panel on the frame. make sure that the parts are orientated as shown in the photograph.
  • Page 26 Final result You have now begun assembling the dashboard of your 1:8 scale Ferrari 312 T4. Very carefully set it to one side along with the sheath, which you will be using in one of the next assembly stages. In the next phase In the next phase The dashboard with its dials.

  • Page 27: Dashboard, Dials, And Cables

    312 T4 PACK 04 DASHBOARD, DIALS, AND CABLES USING THE PARTS SUPPLIED WITH THIS STAGE YOU CAN NOW ASSEMBLE THE DASHBOARD OF YOUR 1: 8 SCALE MODEL CAR AND FIX IT TO THE SUPPORT THAT YOU BEGAN ASSEMBLING IN THE PREVIOUS STAGES. LIST OF PARTS LIST OF PARTS Cable (340 mm)
  • Page 28 31-01 Place the dashboard, the three dials, and their glass inserts on your work surface. 31-02 Using the shaped holes, position the 31-03 Carefully press the glass inserts over the three dials as shown in the image. dials. We recommend using a cloth to push the glass inserts in place.
  • Page 29 43 mm 245 mm 340 mm 31-04 Turn over the dashboard and connect the three cables following the labels shown in the image. 31-05 Retrieve the dashboard support structure from the previous stage. Temporarily join the dashboard to its structure. The final fixing will be carried out in one of the next stages.
  • Page 30 Final result In this stage you have assembled the dashboard of your 1:8 scale Ferrari 312 T4 and joined it to the support structure. Keep this to one side ready for the next assembly stages. In the next stage In the next stage...

  • Page 31: Steering Wheel, Switch, And Steering Wheel Centre With Emblem

    312 T4 PACK 04 STEERING WHEEL, SWITCH, AND STEERING WHEEL CENTRE WITH EMBLEM IN THIS STAGE YOU'LL PREPARE THE STEERING WHEEL FOR YOUR 1: 8 SCALE MODEL. LIST OF PARTS LIST OF PARTS Steering wheel centre Switch Ferrari emblem Steering wheel F E R R A R I 3 1 2 t4 Pa c k 0 4 .
  • Page 32 32-01 Place the steering wheel and switch on your work surface. 32-02 Fit the parts together by inserting the pin on the switch into the mounting hole (inset, arrow). F E R R A R I 3 1 2 t4 Pa c k 0 4 .
  • Page 33 32-03 Now retrieve the wheel centre and the Ferrari emblem. 32-04 Using the three centring elements highlighted in the image, connect the Ferrari crest to the steering wheel centre. The inset shows you what it should look like when fitted. F E R R A R I 3 1 2 t4 Pa c k 0 4 .
  • Page 34 32-05 If you wish, you can try temporarily placing the centre on the steering wheel. For now, however, do not fully insert the mounting pins into their holes. Final result You have begun assembling the steering wheel of your 1:8 scale Formula 1 car. Keep this in a safe place until it is needed in a later stage.

  • Page 35: Steering Shaft

    312 T4 PACK 04 STEERING SHAFT YOU CAN NOW BEGIN TO ASSEMBLE THE MECHANISM THAT CONNECTS THE WHEELS OF YOUR MODEL TO THE STEERING WHEEL. type B screws type D screws LIST OF PARTS LIST OF PARTS Steering shaft Screws Three type B screws Two type D screws F E R R A R I 3 1 2 t4...
  • Page 36 33-01 Insert the end (without the pinion) of the steering shaft into the centre hole in the dashboard frame. 33-02 Fit the steering wheel, without its centre, on to the end of the steering shaft protruding through the centre of the dashboard.
  • Page 37 33-03 Use a type D screw to join these two components. 33-04 Finally, carefully press the steering wheel centre in place using the two round pins (inset). F E R R A R I 3 1 2 t4 Pa c k 0 4 . s ta g e 3 3...
  • Page 38 Final result You have now connected the steering wheel to the steering shaft of your 1:8 scale model. Store your completed work away safely, ready for the next assembly session. In the next stage In the next stage The components of the gear lever and the rear anti-roll bar lever.
