STI SA5500 Installation

PCB SCREWS

9 VDC BATTERY (NOT INCLUDED)
9 VDC BATTERY CONNECTOR
CIRCUIT BOARD

REFLECTORS

LENS

ELECTRONIC BASE

O-RING (2) PROVIDED
#6 x 2 1/2 in. SCREW
(2) PROVIDED
LENS
FAST
SLOW
DETAIL A
SCALE 5 : 1
ON
OFF
2306 Airport Road
Waterford • Michigan • 48327-1209
Phone: 248-673-9898 • Fax: 248-673-1246
E-mail: info@sti-usa.com • Web: www.sti-usa.com
DRILL 3/16 DIA. HOLES
1 1/4 in. DEEP WHEN USING ANCHORS
DRILL 7/64 DIA. HOLES 1 1/4 in. DEEP
WHEN ANCHORS ARE NOT USED
#8-10 WALL ANCHOR (2) PROVIDED
2020_V1.6
FLASH RATE
ADJUSTMENT
ON DIP
FAST
SLOW
1 2 3 4
VOL SIREN
OFF
1
ON
2 3 4
ON
OFF
1 6 5 4 3 2 1
LOW
2 3 4
LOW
BAT STROBE
STROBE S1 S2
BAT
DETAIL S1
LOW BATTERY LED
See pg. 2
DETAILS S1
INSTALLATION OF STI-SA5500 SELECT ALERT SIREN/STROBE
All specifications and information shown were current as of publication and are subject to change without notice.

INPUT

9 VDC, 527 mA Max
12-24 VDC, 402 mA Max.
3.73 in.
(94.6 mm)

OPERATING TEMPERATURE

-4°F to 140°F (-20°C to 60°C)

BATTERY INSTALLATION/REPLACEMENT

(23.8 mm)
1. Unscrew lens to remove.
2. Loosen PCB screws (do not remove).
3. Gently rotate PCB without touching LED's and
without damaging the reflectors.
4. Connect battery and slide under retainer.
5. Re-install PCB and tighten screws.

NOTES

1. Internal battery will provide backup power if loss of external power.
2. If no internal battery is used, remove all power and move S1-1 to
"OFF" position (see detail S1).
LOW BATTERY OPERATON
Replace battery when low battery condition occurs,
Low battery LED flashes 1x per 1 minute and sounder
beeps 1x per 3 minutes
VOL SIREN
OFF
DIP
6 5 4 3 2 1
ON WARNING: This product can expose you to chemicals including Dichloromethane, which is
known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the
6 5 4 2 1
3
State of California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
DETAIL S2
Three year warranty or a one year limited warranty (from date of purchase) on most products.
See website for details. Electronic warranty form at www.sti-usa.com/wc14.
DETAILS S2
Taylor House • 34 Sherwood Road • Bromsgrove
Worcestershire • B60 3DR • England
Tel: +44 (0)1527 520 999 • Fax: +44 (0)1527 501 999
E-mail: info@sti-emea.com • Web: www.sti-emea.com
3.73 in.
(94.6 mm)
1.02 in.
.94 in. .94 in.
(26.0 mm)
(23.8 mm)
S1 - LOW BAT. NOTIFICATION/STROBE CONTROL
1 2 3 4
1
* 0
* 0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
*Default Settings
3.87 in.
( 98.2 mm)
1.02 in.
(26.0 mm)
2.83 in.
(71.8 mm)
1 2 3
1 ON
0 OFF
FUNCTION
LOW BATTERY NOTIFICATION ON
LOW BATTERY NOTIFICATION OFF
CONTINUOUS "ON"
DOUBLE LED ROTATION
3 FLASH - DELAY - 3 FLASH
SINGLE LED ROTATION (FAST)
FLASHING
INTENSITY RAMPING UP & DOWN
SINGLE LED ROTATION (SLOW)
RIGHT/LEFT ROTATION
SA5500IS JAN2021
2.83 in.
(71.8 mm)
4
