STI 6529 Installation

MOUNTING SURFACE
INSTALLATION
1. Place assembly over device.
2. Mark mounting hole locations on mounting surface.
3. Predrill mounting holes
· If using anchors: 3/16" diameter 1 ¼" deep
· If anchors are not used: 7/64" diameter 1 ¼" deep
5.375 in.
(137mm)
0.48 in.
(12mm)
INSTALLATION of STI-6529 PROTECTIVE COVER
All specifications and information shown were current as of publication and are subject to change without notice.
COVER
FRAME
4.58 in.
(116mm)
5.63 in.
(143mm)
5.14 in.
(131mm)
4.10 in.
(104mm)
4.50 in.
(114mm)
WARNING: This product can expose you to chemicals including Dichloromethane, which
is known to the State of California to cause cancer, and Bisphenol A (BPA), which is
known to the State of California to cause birth defects or other reproductive harm. For
more information go to www.P65Warnings.ca.gov.
Three year warranty or a one year limited warranty (from date of purchase) on most
products. See website for details. Electronic warranty form at www.sti-usa.com/wc14.
7.04 in.
(179mm)
5.43 in.
(138mm)
6529 SEPT2020
6.57 in.
(167mm)
2.67 in.
(68mm)
2.79 in.
(71mm)
