STI -13000 Series Install

Installation Notes

· When used outdoors, the manual station must also be rated for outdoor use.
· UL Listing does not permit external power source or connection of horn relay contacts to fire alarm or life safety devices.
· When properly installed, the operation of this cover will not interfere with the function of your life safety system.
· Horn operation and performance must be tested annually. Battery replacement is recommended annually dependent on usage and
battery expiration date.
· Ensure the service pin is properly inserted in the service pin receptor to silence horn while performing installation or servicing horn.
· If mounting to an uneven surface, a backplate (STI-1314) is recommended to help ensure proper sealing to mounting surface.
· The backplate may be drilled if wire access or screw mounting holes are needed.

Specifications

Polycarbonate Enclosure
· Flammability - flush and surface mount models (Fig. 2, 3 & 4): UL 94 V-2, enclosed flush and enclosed back box models (Fig. 5 & 6): UL 94 5VA
· Cover wall thickness 0.125 inches
Horn (battery included)
STI-13*20 & STI-13*30 models
5.699 in.
Low volume
(144.75mm)
High volume
Standby current
STI-14*20 & STI-14*30 models
Low volume
High volume
Standby current
Dry Contact Relay
· 30 VAC/VDC, 1A
Temperature Range
· Electronics operating range: -40° to 120°F (-40° to 49°C) Below -4°F (-20°C), a remote power source is recommended
· Polycarbonate rated: -40° to 284°F (-40° to 140°C)

Approvals

It has been tested and approved or listed by:
· UL, CUL Listed - S2466
· UL Certified to meet ADA
· NEMA Type 3RX models with enclosed flush mount and enclosed back box options

Polycarbonate Cleaning Instructions

Rinse with water to remove abrasive dust and dirt. Wash with soap or mild detergent, using a soft cloth. Rinse once more then dry with a
soft cloth or chamois. Exercise caution when using water inside enclosure. Make sure unit is completely dry inside before reassembling.
To remove grease or wet paint from exterior of cover, rub gently with a soft cloth thoroughly wetted with Naptha. Then wash and rinse.
Do not use razor blades.
See website for accessories

Fig. 1 - Dimensions

(144mm)
Universal Stopper Install
STI-13000 & STI-14000 Series
current draw
9vdc
36 mA
155 mA 146 mA
0.03 mA 0.64 mA
current draw
3vdc
60 mA
140 mA
0.04 mA 0.10 mA
TEXT HERE
5.70 in.
(103mm)
Rely on STI
®
TEXT HERE
12vdc 24vdc
42 mA 22 mA
95 mA
1.9 mA
12vdc 24vdc
46 mA 25 mA
87 mA 45 mA
LIFT HERE
0.014 mA
3.83 in.
(97.28mm)
4.08 in.
(103.63mm)
4.898 in.
(124.42mm)
5.95 in.
(151mm)
5.7 in.
(172mm)
(144mm)
LIFT HERE
LOCKING TAB
3.83 in.
(97mm)
4.08 in.
4.90 in.
(124mm)
5.950 in.
(151.13mm)
dBA @ 9VDC
5.7 in.
1 ft.
(144.78mm)
98
108
-
dBA @ 3VDC
1 ft.
84
95
LOCKING
-
TAB
Center pull station to the Universal Stopper with
the help of dimensions shown in Fig. 1.
Open cover, use frame or optional backplate to
mark mounting holes.
6.80 in.
NOTE: Be sure the entire cover travel will not
interfere with operation of the pull station or
other safety system equipment when installed.
6.798 in.
3 ft. 10 ft.
(172.68mm)
87 75
93 82
- -
3 ft. 10 ft.
74 62
85 76
- -
