Table of Contents
Safety Notice
Hardware Pack
Assembly
Instruction
Parts List
Warranty
Ordering Parts
Model
XJ-6860RW
Retail This
Manual for
Reference
220421
OWNER'S
MANUAL
ROWING MACHINE
XJ-6860RW
IMPEX
2801 S. Towne Ave. Pomona, Ca 91766
Tel: (800)999-8899 Fax: (626)961-9966
www.marcypro.com
support@impex-fitness.com
®
INC.
Advertisement
Table of Contents
Related Manuals for Impex MARCY XJ-6860RW
Summary of Contents for Impex MARCY XJ-6860RW
- Page 1 Table of Contents XJ-6860RW Safety Notice Hardware Pack Assembly Instruction Parts List Warranty Ordering Parts Model XJ-6860RW Retail This Manual for Reference 220421 IMPEX ® INC. 2801 S. Towne Ave. Pomona, Ca 91766 Tel: (800)999-8899 Fax: (626)961-9966 www.marcypro.com support@impex-fitness.com OWNER’S MANUAL...
-
Page 2: Table Of Contents
EXERCISE GUIDELINES WARRANTY ORDERING PARTS BEFORE YOU BEGIN Thank you for selecting the MARCY XJ-6860RW Rowing Machine by IMPEX ® INC. For your safety and benefit, read this manual carefully before using the Machine. As a manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Imporant Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. -
Page 4: Warning Label Placement
The Warning Labels and Caution Label shown here have been placed on the Front Stabilizer and Main Frame. If the labels are missing or illegible, please call customer service at 1-800-999- 8899 for replacement. Apply the labels in location shown. ©Impex Inc. www.marcypro.com... -
Page 5: Hardware Pack
HARDWARE PACK ©Impex Inc. www.marcypro.com... -
Page 6: Component For Assembly
COMPONENTS FOR ASSEMBLY ©Impex Inc. www.marcypro.com... - Page 7 NOTE: Do not over tighten any component with pivoting function. Make sure all pivoting components are able to move freely. Do not tighten all Nuts and Bolts in this step. ©Impex Inc. www.marcypro.com...
-
Page 8: Care And Maintenance And Storage
Rowing Machine around. 6. Disposal Instructions – The equipment can be safely disassembled and disposed without unreasonable hazards. Call your local recycle agency regarding details of recycling. 7. The maximum user weight is 250 lbs. 8. Assembled Dimension: 68.5”x19.6”x31.2”. ©Impex Inc. www.marcypro.com... -
Page 9: Parts List
Phillips Bolt M6×15 Washer Φ6 Locking Washer Φ6 Hex Bolt M12×140 Allen Bolt M6×45 Nylon Washer Φ6 Aircraft Nut Phillips Bolt M5×10 Allen Bolt M6×16 Washer Φ18×Φ6.5 Bushing Φ14×Φ10×12.5 Top Roller Wheel Axel Roller Wheel Axel Sleeve ©Impex Inc. www.marcypro.com... - Page 10 Bottom Roller Wheel Axel Pedal Stopper Self Tapping Screw ST4.8×15 Self Tapping Screaw ST4.2×15 C-Clip Φ10 Computer Roller Wheel Adjustment Bolt Tension Knob Right Shroud Left Shroud Rowing Handle Rest Cup Holder Aircraft Nut Leveler Computer Cable Computer Receiver Cable ©Impex Inc. www.marcypro.com...
-
Page 11: Exploded Diagram
EXPLODED DIAGRAM ©Impex Inc. www.marcypro.com... -
Page 12: Computer Functions And Operation
1.The key to reset the value to zero by pressing the key. BATTERY: 2.The unit can be reset by either changing the If the display starts to fade, the batteries need batteries or pressing the MODE key for 3 replacing. ©Impex Inc. www.marcypro.com... - Page 13 2. Replace 2x1.5V (AAA) batteries. 3. Make sure the batteries are installed correctly and the polarities are correct. 4. The battery life is approx. 10 months under normal usage. 5. When the batteries are removed, all values will reset to zero. ©Impex Inc. www.marcypro.com...
-
Page 14: Operating Notes
• To store the rower, please lower the computer, and stand the rower upright with the front of the rower facing down. Adjust the leveler (52) on the front of the rower to ensure that the rower is in a stable position and perpendicular to the floor. ©Impex Inc. www.marcypro.com... -
Page 15: Exercise Guidelines
Work to your but it is very important to maintain a steady tempo throughout. The rate of work should be sufficient to raise your heartbeat into the target zone shown on the graph below. ©Impex Inc. www.marcypro.com... - Page 16 The important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn. Effectively this is the same as if you were training to improve your fitness, the difference is the goal. ©Impex Inc. www.marcypro.com...
-
Page 17: Warranty
IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
