- Page 1 VMA7192 7” LCD Color Monitor OWNER’S MANUAL...
-
Page 2: Table Of Contents
VMA7192 INTRODUCTION The Clarion VMA7192 is a full-featured 7" wide LCD Color Monitor that can be used as a stand alone monitor, or can be integrated into a mobile multimedia sys- tem. The VMA7192 has the following features: 7" wide-screen color LCD panel... -
Page 3: Description
DESCRIPTION The VMA7192 is a TFT active matrix color LCD monitor which delivers a striking picture and superior image resolution. The VMA7192 can be used to enjoy video images with the Clarion video sources, even if no TV tuner is connected. -
Page 4: Wiring Precautions
INSTALLATION The VMA7192 is a 7" monitor with an Infrared (IR) eye. It will accept a video sig- nal from any video source with composite video out. The IR eye will work direct- ly with any Clarion video source product with an IR Eye Input. -
Page 5: Mounting Options
Clarion's mounting bracket methods. The slot on the back of the VMA7192 also accommodates dash-mount installations. In addition to this, the VMA7192 fits perfectly into all Clarion console shrouds, as well as our new headrest mounting bracket, HRM-150. -
Page 6: Notes
VMA7192 NOTES:... - Page 7 Clarion Co., Ltd. VMA7192-10 Rev.0 (11/00)
