How to store optical fiber cleaver FC-6 in a case
Be sure to remove and dispose of the fiber off-cuts left in the case. The off-cuts can cause injury to persons.
Warning
If the case is dropped and impacted, and other movements (twisting) except the opening and closing
movement are applied to the case, it may be damaged. Handle with care. If you do not store the cleaver as
illustrated below, the case cover will not be closed completely. Do not force the cover which is not closed
Caution
completely. Doing so can cause damage to the case.
1: Storage orientation
FC-6 cleaver
2: How to store FC-6 in carrying case
View A
(C) 2017 Sumitomo Electric Industries, LTD.
2-1: Place the FC-6 into the case according to "1:
Storage orientation".
2-2: Fit the circled part between the projecting parts.
Projecting part
View A
OME0826013-02A
Operation manual
Space for FCP-20BL
*Optional accessories
<Tips>
This part should be
fitted between the
projecting parts.
PRINTED IN JAPAN
