Package Contents
Table of Contents
UniFi Switch
Bracket Screws (Qty. 8)
Installation Requirements
Phillips screwdriver (for rack- or wall-mounting)
Standard-sized, 19" wide rack with a minimum of 1U height available (for rack-
mounting)
Use compatible fiber SFP+ modules with the appropriate fiber optic cabling.
For information about compatible fiber SFP+ modules, visit:
community.ubnt.com/unifi
For indoor applications, use Category 6A (or above) UTP cabling approved for
indoor use.
For outdoor applications, shielded Category 6A (or above) cabling should be
used for all wired Ethernet connections and should be grounded through the
AC ground of the power supply.
We recommend that you protect your networks from harmful outdoor
environments and destructive ESD events with industrial-grade, shielded
Ethernet cable from Ubiquiti. For more details, visit:
Note:
should be housed inside a protective enclosure.
https://dl.ui.com/qsg/US-16-XG/US-16-XG_EN.html
US-16-XG Quick Start Guide
×
Mounting Screws (Qty. 4)
Although the cabling can be located outdoors, the UniFi Switch itself
US-16-XG Quick Start Guide
Power Cord
Rack-Mount Brackets (Qty.
2)
Cage Nuts (Qty. 4)
ui.com/toughcable
1/12
