Ubiquiti UniFi US-16-XG Quick Start Manual

Hide thumbs Also See for UniFi US-16-XG:
Table of Contents

Advertisement

Quick Links

Package Contents
UniFi Switch
Power Cord
Rack-Mount Brackets (Qty. 2)
Bracket Screws (Qty. 8)
Mounting Screws (Qty. 4)
Cage Nuts (Qty. 4)
Installation Requirements
Phillips screwdriver (for rack- or wall-mounting)
Create PDF in your applications with the Pdfcrowd
HTML to PDF API
PDFCROWD

Advertisement

Table of Contents
loading

Related Manuals for Ubiquiti UniFi US-16-XG

Summary of Contents for Ubiquiti UniFi US-16-XG

  • Page 1 Package Contents UniFi Switch Power Cord Rack-Mount Brackets (Qty. 2) Bracket Screws (Qty. 8) Mounting Screws (Qty. 4) Cage Nuts (Qty. 4) Installation Requirements Phillips screwdriver (for rack- or wall-mounting) Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...

  • Page 2: System Requirements

    We recommend that you protect your networks from harmful outdoor environments and destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For more details, visit: ui.com/toughcable Note: Although the cabling can be located outdoors, the UniFi Switch itself should be housed inside a protective enclosure.
  • Page 3 System LED Click here for detailed descriptions. SFP+ Speed/Link/Act LED (Ports 1 - 12) No Link Solid: 1 Gbps Link Established Green Flashing: Activity Solid: 10 Gbps Link Established White Flashing: Activity RJ45 Speed/Link/Act LED (Ports 13 - 16) No Link Solid: 1 Gbps Link Established Green Flashing: Activity...
  • Page 4 White Solid: 10 Gbps Link Established Flashing: Activity SFP+ (Ports 1 - 12) Hot-swappable SFP+ ports support 1 Gbps and 10 Gbps connections. RJ45 (Ports 13 - 16) RJ45 ports support 1 Gbps and 10 Gbps Ethernet connections. Reset Button This button serves two functions for the UniFi Switch: Restart Press and release the Reset button quickly.

  • Page 5: Hardware Installation

    Baud rate 115200 Data bits 8 Parity NONE Stop bits 1 Flow control NONE DC Input The 48/24VDC input can connect a redundant or stand-alone DC power source (not included) with minimum power: 56W, 57 to 20V. Note: You can use the redundant DC power source as a hot spare; if the internal AC/DC power supply no longer provides power, the UniFi Switch will switch to the DC power source without interrupting its operation.
  • Page 6 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
  • Page 7 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
  • Page 8 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...

  • Page 9: Connecting Power

    Connecting Power Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
  • Page 10 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
  • Page 11 Connecting SFP+ Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
  • Page 12 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
  • Page 13 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
  • Page 14 For information about compatible fiber SFP+ modules, visit: community.ubnt.com/unifi Connecting RJ45 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
  • Page 15 Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...

  • Page 16: Software Installation

    Software Installation Download and install the latest version of the UniFi Controller software at ui.com/download/unifi and follow the on-screen instructions. Note: If you already have UniFi Controller v5.4 or higher installed, go to the section, Adopting the UniFi Switch. After you have installed the software and run the UniFi Installation Wizard, a login screen will appear for the UniFi Controller management interface.
  • Page 17 and password that you created and click Sign In. You can manage your network and view network statistics using the UniFi Controller management interface. To adopt the UniFi Switch, proceed to the section, Adopting the UniFi Switch. For information on configuring and using the UniFi Controller software, refer to the User Guide on the website: ui.com/download/unifi Adopting the UniFi Switch...
  • Page 18 2. Locate the UniFi Switch in the list of devices under the Model column. Click Adopt. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...

  • Page 19: Specifications

    3. The System LED on the UniFi Switch will turn blue to confirm that it has been successfully adopted. Specifications US-16-XG Dimensions 443 x 221 x 43 mm (17.44 x 8.70 x 1.69") Weight 2.67 kg (5.89 lb) With Mount Brackets 2.76 kg (6.04 lb) Total Non-Blocking Line Rate 160 Gbps...

  • Page 20: Safety Notices

    US-16-XG Max. DC Power Consumption (excludes SFP/SFP+ modules) Power Method 100-240VAC/50-60 Hz, Universal Input 48VDC/24VDC Power Supply AC/DC, Internal, 56W DC Supported Voltage Range 100 to 240VAC 57 to 20VDC Rack-Mount Yes, 1U High ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV Shock and Vibration ETSI300-019-1.4 Standard LEDs Per Port...

  • Page 21: Electrical Safety Information

    2. Heed all warnings. 3. Only use attachments/accessories specified by the manufacturer. WARNING: Failure to provide proper ventilation may cause fire hazard. Keep at least 20 mm of clearance next to the ventilation holes for adequate airflow. WARNING: To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.

  • Page 22: Limited Warranty

    d. Protective earthing is provided by Listed AC adapter. Building installation shall provide appropriate short-circuit backup protection. e. Protective bonding must be installed in accordance with local national wiring rules and regulations. Limited Warranty ui.com/support/warranty The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and, where applicable, specify arbitration instead of jury trials or class actions.

  • Page 23: Declaration Of Conformity

    CAN ICES-3(A)/NMB-3(A) Australia and New Zealand Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. CE Marking CE marking on this product represents the product is in compliance with all directives that are applicable to it.
  • Page 24 © 2020 Ubiquiti Inc. All rights reserved. Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD...
