Clas Ohlson 31-3766 Instructions

Timer with clock
Art.no. 31-3766
Please read the entire instruction manual before using and save it for future
use.
Description
Timer with clock and two alarms. Countdown/stopwatch for max. 24 hours.
Countdown , stopwatch and both alarms operate independently of each other
and can be used simultaneously.
Buttons and functions
A
B
C
D
a) MODE-button. Use this button to switch between functions, in order;
clock, countdown timer, stopwatch, normal alarm and a simple alarm for
shorter periods of rest.
b) START/STOP button. Push this button to start, pause or stop the timer.
c) HR button. Push this button to set the hour. Hold the button down to
advance the hour more quickly.
d) MIN button. Push this button to set the minutes. Hold the button down to
advance the minutes more quickly.
e) SEC button. Push this button to set the minutes. Hold the button down to
advance the minutes more quickly.
f) MEM button. Push this button to display the countdown time recorded in
the memory.
g) Battery compartment.
Inserting the battery
Remove the battery cover and insert one R03 battery. Make sure that the
poles of the battery are facing the right way.
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk and click on customer service. Internet: www.clasohlson.co.uk
Setting the time
1) Push the MODE button to enter the clock mode ("CLOCK" appears on the
display).
2) Hold the START/STOP button in for 3 seconds to enter the setup mode.
3) Choose between the 12-hour and 24-hour clock times using the MODE
button.
4) Confirm setup by pushing the START/STOP button.
5) Use the HR and MIN buttons to set the hours and minutes.
6) Confirm the settings by pushing the START/STOP button.
NOTE! If, whilst setting the time, no button is pressed for eight seconds, the
timer will automatically revert to normal mode.
Setting the timer (countdown function)
The timer can count down from max. 23 hrs, 59 mins and 59 s. When the
countdown reaches zero, the alarm will sound and the display will flash. If you
do not turn off the alarm it will sound for 15 seconds and be silent for 45 se-
conds. This will be repeated 5 times (as long as you do not turn off the alarm).
1) Push the MODE button until you enter the timer mode ("TIMER"
appears on the display).
2) Set the timer by using the HR button to set the hours and the MIN button
to set the minutes. Holding down the button will advance the setting more
quickly.
3) Push the START/STOP button to start, pause or stop the countdown.
4) When the countdown reaches zero and the alarm sounds, turn off the
alarm by pushing any button.
5) If you wish to reset the alarm in advance, stop the alarm and push the HR
G
and MIN buttons simultaneously. NOTE! It is important that the HR and
MIN buttons are pushed at exactly the same time.
Memory
1. Push the MODE button until you enter the timer mode ("TIMER"
appears on the display).
F
2. If the timer is counting down, first stop it by pushing the START/STOP
E
button.
3. Push the START/STOP button and the MEM button simultaneously to
erase the memory. If you have not previously stored anything in the
memory, you can save your time in the memory straight away. If you
already have data stored in the memory, "CLr" will flash on the display
several times, to indicate that the memory is now erased. NB! It is
important that the START/STOP button and MEM button are pushed in at
exactly the same time in order to erase the memory.
4. Set the memory by using the HR button to set the hours and the MIN
button to set the minutes. Holding down the button will advance the
setting more quickly.
5. Push the MEM button to confirm the setup. "REC" will flash on the display
to indicate that the time is saved in the memory.
6. When you have saved a time in the memory, you can enter the timer
mode and recall the memorised time using the MEM button.
7. Pushing the HR and MIN buttons simultaneously will reset the timer, but
not the memory. If you want to reset the memory, follow steps 1-3.
ENGLISH
▼
▼
Stopwatch
▲
1. Push the MODE button until "TIMER" appears on the display.
2. Push the START/STOP button to start, pause or stop the timekeeping.
3. Reset the stopwatch by pushing the HR and MIN buttons simultaneously.
NB! It is important that the HR and MIN buttons are pushed at the same
time.
Setting the alarm
1. Push the MODE button until the symbol appears on the display.
2. The alarm is activated when the symbol flashes. When the
is constantly lit the alarm is deactivated.
3. The alarm can only be set when it is deactivated. If the alarm is activated,
first push the START/STOP button to deactivate it.
4. Set the time by using the HR button to set the hours and the MIN button
to set the minutes. Holding down the button will advance the setting more
quickly.
5. The alarm is activated and deactivated using the START/STOP button.
6. At the preset time the alarm will sound and the display will flash. If you
do not turn off the alarm it will sound for 15 seconds and be silent for 45
seconds. This will be repeated 5 times (as long as you do not turn off the
alarm).
7. Turn off the alarm with any button.
Setting the nap timer
This function allows you to program the alarm for short periods of rest.
1. Push the MODE button until "NAP TIMER" appears on the display.
2. Push either the HR, MIN or SEC button one or several times to program
the time that is to count down until the alarm sounds. Each push of the
button advances the time as follows: 15, 30, 45, 60, 90 and 120 minutes.
3. Push the START/STOP button to start the countdown. "NAP TIMER" will
flash on the display to indicate that the countdown has begun.
4. When the timer reaches zero the alarm will sound. If you do not turn off
the alarm it will sound for 15 seconds and be silent for 45 seconds. This
will be repeated 5 times (as long as you do not turn off the alarm).
5. The countdown can not be paused once it has begun. However, pushing
the START/STOP button during a countdown will reset it.
Care and cleaning
- Do not expose the timer to extreme temperatures, as this can greatly
shorten the battery life.
- Do not leave an uncharged battery in the timer for any length of time
because the battery fluid can leak out.
- Clean the timer using a dry, soft cloth. Avoid strong detergents and
solvents.
Disposal
This timer operates on one battery. Follow local ordinances when disposing
of this product. If you are unsure about how to dispose of this product contact
your municipality.
Specifications
Size: 85 x 75 mm
Battery 1x R03
