QUICK INSTALL GUIDE AND USER MANUAL
KVXLCH-100, KVXLCHF-100, KVXLCH-200, KVXLCHF-200, KVXLCHDP-200, KVXLCHDPF-200
KVX SERIES
4K HDMI KVM
EXTENDER
24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KVX Series and is the answer not in the manual?

Questions and answers

Related Manuals for Blackbox KVX Series

Summary of Contents for Blackbox KVX Series

  • Page 1 QUICK INSTALL GUIDE AND USER MANUAL KVXLCH-100, KVXLCHF-100, KVXLCH-200, KVXLCHF-200, KVXLCHDP-200, KVXLCHDPF-200 KVX SERIES 4K HDMI KVM EXTENDER 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM...

  • Page 2: Table Of Contents

    2.4.2 Receiver..........................................11 3. CONNECTION DIAGRAM ................................15 4. INSTALLATION .................................... 16 APPENDIX A. REGULATORY INFORMATION ..........................17 A.1 FCC Statement .......................................17 A.2 NOM Statement .....................................18 APPENDIX B. DISCLAIMER/TRADEMARKS ..........................19 B.1 Disclaimer ....................................... 19 B.2 Trademarks ......................................19 1.877.877.2269 BLACKBOX.COM...

  • Page 3: Quick Installation Guide

    2. SFP module’s bandwidth requirement is 1 Gbps minimum. 3. When plugging into any microphone or speaker ports of TX or RX units, digital HDMI audio extension will be disabled and only analog audio LINE-IN/LINE-OUT extension is enabled. 1.877.877.2269 BLACKBOX.COM...

  • Page 4: Specifications

    KVXLCH-100 transmitter: 0.82 lb. (0.372 kg) KVXLCHF-100 transmitter: 0.83 lb. (0.378 kg) (no SFP); KVXLCH-200 transmitter: 0.82 lb. (0.372 kg); Weight KVXLCHF-200 transmitter: 0.82 lb. (0.372 kg) (no SFP); KVXLCHDP-200 transmitter: 0.84 lb. (0.381 kg); KVXLCHDPF-200 transmitter: 0.84 lb. (0.381 kg) (no SFP) 1.877.877.2269 BLACKBOX.COM...
  • Page 5 KVXLCH-100 receiver: 0.82 lb. (0.372 kg) KVXLCHF-100 receiver:0.83 lb. (0.378 kg) (no SFP); KVXLCH-200 receiver: 0.83 lb. (0.378 kg) Weight KVXLCHF-200 receiver: 0.83 lb. (0.378 kg) (no SFP); KVXLCHDP-200 receiver: 0.85 lb. (0.386 kg); KVXLCHDPF-200 receiver: 0.84 lb. (0.381 kg) (no SFP) 1.877.877.2269 BLACKBOX.COM...

  • Page 6: Overview

    (2) HDMI outputs on the receivers. There are six models of the KVX Series 4K HDMI KVM Extender: the single-head models are KVXLCH-100 via a CATx link and KVXLCHF-100 via a fiberoptic link. The dual-head models are KVXLCH-200 and KVXLCHDP-200 via a CATx link and KVXLCHF-200 and KVXLCHDPF-200 via a fiberoptic link.Each extender consists of a transmitter (TX) and a receiver (RX).

  • Page 7: Hardware Description

    Figure 2-1 shows the front panel that is common to the single-head CATx and fiber transmitters. Table 2-1 describes the components. FIGURE 2-1. SINGLE-HEAD TRANSMITTER FRONT PANEL Figure 2-2 shows the front panel that is common to the dual-head CATx and fiber transmitters. Table 2-1 describes the components. FIGURE 2-2. HDMI DUAL-HEAD TRANSMITTER FRONT PANEL 1.877.877.2269 BLACKBOX.COM...
  • Page 8 Connects to analog audio output for audio extension BACK PANEL Figures 2-4 and 2-5 show the back panels of the single-head CATx and fiber transmitters. Table 2-2 describes their components. FIGURE 2-4. SINGLE-HEAD CATX TRANSMITTER BACK PANEL FIGURE 2-5. SINGLE-HEAD FIBER TRANSMITTER BACK PANEL 1.877.877.2269 BLACKBOX.COM...
  • Page 9 Links to 5-VDC power supply Figures 2-6 and 2-7 show the back panels of the dual-head CATx and fiber transmitters. Table 2-3 describes their components. FIGURE 2-6. HDMI DUAL-HEAD CATX TRANSMITTER BACK PANEL FIGURE 2-7. HDMI DUAL-HEAD FIBER TRANSMITTER BACK PANEL 1.877.877.2269 BLACKBOX.COM...
  • Page 10 Connects to local out (1) or (2) HDMI Input port(s) Connects to source device’s signal for HDMI extension (0) or (1) DisplayPort Input port Connects to source device’s signal for DisplayPort extension Power connector Links to 5-VDC power supply 1.877.877.2269 BLACKBOX.COM...

  • Page 11: Receiver

    Figure 2-11 shows the front panel that is common to the dual-head CATx and fiber receivers. Table 2-4 describes its components. FIGURE 2-11. DUAL-HEAD RECEIVER FRONT PANEL Figure 2-12 shows the front panel that is common to the dual-head CATx and fiber receivers. Table 2-4 describes its components. FIGURE 2-12. DUAL-HEAD RECEIVER FRONT PANEL 1.877.877.2269 BLACKBOX.COM...
  • Page 12 (4) USB 2.0 ports Connect to USB device ports for extension DB9 connector Connects to sink device’s RS-232 port for serial extension HDMI Out port Connects to sink device’s signal for HDMI video extension Power connector Links to 5-VDC power supply 1.877.877.2269 BLACKBOX.COM...
  • Page 13 FIGURE 2-15. HDMI DUAL-HEAD CATX RECEIVER BACK PANEL FIGURE 2-16. HDMI DUAL-HEAD FIBER RECEIVER BACK PANEL Figures 2-17 and 2-18 show the back panels of the HDMI/DP dual-head CATx and fiber receivers. Table 2-6 describes their components. FIGURE 2-17. DUAL-HEAD CATX RECEIVER BACK PANEL 1.877.877.2269 BLACKBOX.COM...
  • Page 14 Connects to sink device’s RS-232 port for serial extension (2) HDMI Out ports Connects to sink devices’ signals for HDMI video extension Power connector Links to 5-VDC power supply NOTE: While the HDMI/DP Transmitters have HDMI and DP ports, the HDMI/DP Receivers only have HDMI ports. 1.877.877.2269 BLACKBOX.COM...

  • Page 15: Connection Diagram

    RS-232 keyboard/mouse DC 5V DC 5V Fiber RS232 HDMI OUT HDMI IN CATx RS232 HDMI OUT TX unit over fiber link RX unit over fiber link (KVXLCHF-100) (KVXLCHF-100) Fiber cable FIGURE 3-2. FIBER MODEL CONNECTION DIAGRAM 1.877.877.2269 BLACKBOX.COM...

  • Page 16: Installation

    2. SFP module’s bandwidth requirement is 1 Gbps minimum. 3. When plugging into any microphone or speaker ports of TX or RX units, digital HDMI audio extension will be disabled and only analog audio LINE-IN/LINE-OUT extension is enabled. 1.877.877.2269 BLACKBOX.COM...

  • Page 17: Appendix A. Regulatory Information

    This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio Interference Regulation of Industry Canada. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada. 1.877.877.2269 BLACKBOX.COM...

  • Page 18: Nom Statement

    B: Objectos han caído o líquido ha sido derramado dentro del aparato; o C: El aparato ha sido expuesto a la lluvia; o D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o E: El aparato ha sido tirado o su cubierta ha sido dañada. 1.877.877.2269 BLACKBOX.COM...

  • Page 19: Appendix B. Disclaimer/Trademarks

    B.2 TRADEMARKS USED IN THIS MANUAL Black Box and the Black Box logo type and mark are registered trademarks of Black Box Corporation. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners. 1.877.877.2269 BLACKBOX.COM...
  • Page 20 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2021. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. K VXLCH-100_K VXLCHDP-200_QIG-USER_REV7.PDF...
