Blackbox IC406A Quick Start Manual

4-Port Fiber Optic USB 2.0 Extenders Quick Start Guide
Break the 16-foot (5-m) USB distance barrier.
This local transmitter/remote receiver pair extends
USB over a duplex fiber link.
IC404A extends USB over a multimode LC fiber link up to 1600 feet (500 m).
IC406A extends USB over a single-mode LC fiber link up to 6 miles (10 km).
Before you get started, make sure that all the drivers required for your USB device(s) are installed.
1. Place the units where you want them and connect the fiber cabling to the Link ports on the local and remote units.
Customer
Support
Information
IC404A or IC406A
local unit
LC-LC crossover duplex cable (not included)
Maximum 500 m multimode fiber
for IC404A; maximum 10 km single-mode
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
BLACK BOX
IC404A or IC406A
remote unit
fiber for IC406A
February 2010 June 2010
MT1000A-85-R4
IC404A
IC406A
®
