Summary of Contents for Blackbox LC100 SERIES
- Page 1 QUICK INSTALL GUIDE AND USER MANUAL KVXLC-100, KVXLCF-100 LC100 SERIES DVI KVM-IP EXTENDER 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM...
-
Page 2: Table Of Contents
4.2 Connect All Devices to the Switch ................................12 5. FIRMWARE UPGRADE ................................. 14 APPENDIX A. REGULATORY INFORMATION ..........................16 A.1 FCC Statement .......................................16 A.2 NOM Statement .....................................17 APPENDIX B. DISCLAIMER/TRADEMARKS ..........................18 B.1 Disclaimer ....................................... 18 B.2 Trademarks ......................................18 1.877.877.2269 BLACKBOX.COM... -
Page 3: Quick Installation Guide
2. Set your display device’s (TV, monitor, etc.) input source as DVI. 3. Check the PC BIOS configuration of the video output setting. 4. Connect your video source to the Display DIRECTLY to check if the video signal gets through. 1.877.877.2269 BLACKBOX.COM... -
Page 4: Specifications
0 to 80% Power Supply External 5-VDC, 2-A power supply Dimensions 1.06" H x 3.27" W x 7.09" D (2.7 x 8.3 x 18 cm) KVXLC-100 transmitter: 0.79 lb. (0.36 kg); Weight KVXLCF-100 transmitter: 0.77 lb. (0.35 kg) 1.877.877.2269 BLACKBOX.COM... - Page 5 0 to 80% Power Supply External 5-VDC, 2-A power supply Dimensions 1.06” H x 3.27” W x 7.09” D (2.7 x 8.3 x 18 cm) KVXLC-100 receiver: 0.84 lb. (0.38 kg); Weight KVXLCF-100 receiver: 0.81 lb. (0.37 kg) 1.877.877.2269 BLACKBOX.COM...
-
Page 6: Overview
IT device. There are two models of the LC100 Series DVI KVM-IP Extender: one is KVXLC-100 via a CATx link, and the other is KVXLCF-100 via a fiberoptic link. Each extender consists of a transmitter (TX) and a receiver (RX). -
Page 7: Hardware Description
Lights when power to the transmitter is ON Audio jack Connects to analog audio input for audio extension Audio jack Connects to analog audio output for audio extension DB9 connector Connects to source device’s RS-232 port for serial over IP RS-232 extension 1.877.877.2269 BLACKBOX.COM... - Page 8 For Fiber model: Install fiber SFP module here USB Type B connector Connects to source device’s USB port DVI In port Connects to source device’s signal for DVI/VGA extension DVI Out port Connects to local out Power connector Links to 5-VDC power supply 1.877.877.2269 BLACKBOX.COM...
-
Page 9: Receiver
FIGURE 2-4. RECEIVER FRONT PANEL TABLE 2-3. RECEIVER FRONT-PANEL COMPONENTS NUMBER IN FIGURE 2-4 COMPONENT DESCRIPTION PWR LED Lights when power to the receiver is ON DB9 connector Connects to sink device’s RS-232 port for serial over IP RS-232 extension 1.877.877.2269 BLACKBOX.COM... - Page 10 DVI Out port Connects to sink device’s signal for DVI/VGA extension Phone jack Links to analog audio input for audio extension Phone jack Links to analog audio output for audio extension Power connector Links to 5-VDC power supply 1.877.877.2269 BLACKBOX.COM...
-
Page 11: Connection Diagram
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: CONNECTION DIAGRAM TECHNICAL SUPPORT 1.877.877.2269 Figure 3-1 shows a typical connection. CATx UTP/STP Cable Fiberoptic Cable Source Console FIGURE 3-1. CONNECTION DIAGRAM 1.877.877.2269 BLACKBOX.COM... -
Page 12: Installation
Š Stop bits: 1 Š If the default settings do not meet your needs, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com. 4.2 CONNECT ALL DEVICES TO THE SWITCH NOTE: The examples below show a CAT5e/6 connection for the CATx Extender. The connections for the Fiber Extender are similar, but use fiberoptic cable instead of CAT5e/6 cable. - Page 13 NOTE: We recommend that you only have 1 TX and 1 RX connected to the network switch at any time to eliminate any IP address conflicts. If you require more units to be on the network, please contact our Black Box Technical Support team at 877-877-2269 or info@blackbox.com. 4. Power on all devices.
-
Page 14: Firmware Upgrade
4. Launch the web browser, and type the transmitter’s IP address. The transmitter’s web user interface displays. 5. To select the appropriate firmware file for the transmitter, click the System tab > Update Firmware section > Browse. FIGURE 5-1. SYSTEM TAB > UPDATE FIRMWARE 6. Click Upload to start the firmware upgrade. 1.877.877.2269 BLACKBOX.COM... - Page 15 8. Now you can verify the current version by clicking the System tab >Version Information section. 9. Type the receiver’s IP address in the browser to show the receiver’s web user interface. 10. Repeat the same firmware upgrade steps for the receiver. Note that the firmware file is different from the transmitter. 1.877.877.2269 BLACKBOX.COM...
-
Page 16: Appendix A. Regulatory Information
This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio Interference Regulation of Industry Canada. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada. 1.877.877.2269 BLACKBOX.COM... -
Page 17: Nom Statement
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o C: El aparato ha sido expuesto a la lluvia; o D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o E: El aparato ha sido tirado o su cubierta ha sido dañada. 1.877.877.2269 BLACKBOX.COM... -
Page 18: Appendix B. Disclaimer/Trademarks
B.2 TRADEMARKS USED IN THIS MANUAL Black Box and the Black Box logo type and mark are registered trademarks of Black Box Corporation. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners. 1.877.877.2269 BLACKBOX.COM... - Page 19 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________\ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ 1.877.877.2269 BLACKBOX.COM...
- Page 20 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2019. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. K VXLC-100_QIG-USER_REV1.PDF...
