VX1000 Series HDMI Extender - 4K, HDMI, HDBaseT, USB
Extend 3840 x 2160 @ 60Hz video, power,
Ethernet, RS-232, and USB up to 328 feet
(100 meters) over a single CAT5e or higher cable.
Contact
Order toll-free in the U.S. or for FREE 24/7 technical support:
Information
Call 877-877-BBOX (outside U.S. call 724-746-5500)
www.blackbox.com • info@blackbox.com
Chapter
VX-1001-TX
VX-1001-RX
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blackbox VX-1001-RX
Summary of Contents for Blackbox VX-1001-RX
- Page 1 Extend 3840 x 2160 @ 60Hz video, power, Ethernet, RS-232, and USB up to 328 feet (100 meters) over a single CAT5e or higher cable. Contact Order toll-free in the U.S. or for FREE 24/7 technical support: Information Call 877-877-BBOX (outside U.S. call 724-746-5500) www.blackbox.com • info@blackbox.com...
-
Page 2: Instrucciones De Seguridad
2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas. 4. Todas las instrucciones de operación y uso deben ser seguidas. 877-877-2269 | blackbox.com Page 2... - Page 3 15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia. 16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo. 877-877-2269 | blackbox.com Page 3...
- Page 4 C: El aparato ha sido expuesto a la lluvia; o D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o E: El aparato ha sido tirado o su cubierta ha sido dañada. 877-877-2269 | blackbox.com Page 4...
- Page 5 Black Box Network Services may revise this document at any time without notice. 877-877-2269 | blackbox.com Page 5...
-
Page 6: Table Of Contents
Table of Contents Table of Contents Specifications ..................7 2. Overview .....................11 Introduction ................11 Features ..................11 What's Included ............... 12 Hardware Description .............. 12 2.4.1 Transmitter ..............12 2.4.2 Receiver ................. 14 3. Initial Installation ................16 877-877-2269 | blackbox.com Page 6... -
Page 7: Specifications
Input Signal Type HDBaseT Video Impedance 100 ohms Audio Audio Format Stereo, LPCM 5.1 LPCM 7.1, Dolby True HD, DTS-HD Support Master Audio Control Control Method (1) RS-232, (1) Ethernet, (1) USB Type B female 877-877-2269 | blackbox.com Page 7... - Page 8 Chapter 1: Specifications Receiver (VX-1001-RX) Video Input Connector (1) RJ-45 Input Signal Type HDBaseT Input/Output Maximum 3840 x 2160 (UHD) Resolution Support Input Video Level 0.5-1.0 Vp-p Maximum Pixel 297 MHz Clock Output (1) HDMI Out Connector Output Signal HDMI: HDMI 1.4 w/HDCP 2.2 passthrough...
- Page 9 Chapter 1: Specifications General (VX-1001-TX and VX-1001-RX) Environment Operating 32 to 113° F (0 to 45° C) Temperature Storage -4 to +158° F (-20 to +70° C) Temperature Humidity 10 to 90%, noncondensing ESD Protection Human-body model ±8 kV (air-gap discharge)/4 kV (contact discharge)
- Page 10 1080p @ 60 Hz, 3D; 840 x 2160 @ 60 Hz, 4:2:0 bit CAT6a/7 328 ft. (100 m) 1080p @ 60 Hz, 48-bit; 1080p @ 60 Hz, 3D; 3840 x 2160 @ 60 Hz, 4:2:0 bit 877-877-2269 | blackbox.com Page 10...
-
Page 11: Overview
Chapter 2: Overview 2. Overview 2.1 Introduction The VX-1001-TX and VX-1001-RX are a pair of HDMI extenders with USB-HID* and PoH (Power over HDBaseT). *Keyboard and mouse only. • VX1000 Series Extender Transmitter - 4K, HDMI, HDBaseT, USB (VX-1001-TX) • VX1000 Series Extender Receiver - 4K, HDMI, HDBaseT, USB (VX-1001-RX) -
Page 12: What's Included
• (1) 3.5-mm 3-pin Phoenix male connector • (2) mounting brackets • This user manual VX-1001-RX: • VX1000 Series Extender Receiver - 4K, HDMI, HDBaseT, USB (VX-1001-RX) • (1) 12-VDC, 1.5-A power supply • (1) 3.5-mm 3-pin Phoenix male connector • (2) mounting brackets •... - Page 13 (1) RJ-45 RJ-45 port connects to an Ethernet device. port Speed LED (Amber) and (2) LEDs Link/Activity LED (Green) USB Type B Connects to a device you wish to control, such as a server or computer. 877-877-2269 | blackbox.com Page 13...
-
Page 14: Receiver
Chapter 2: Overview 2.4.2 Receiver Figures 2-3 and 2-4 show the front and back panels of the receiver. Table 2-2 describes its components. 1 2 3 4 Figure 2-3. Receiver front panel. Figure 2-4. Receiver back panel. 877-877-2269 | blackbox.com Page 14... - Page 15 Connects to an HDMI display device. port (1) RJ-45 RJ-45 port connects to an Ethernet device. port and Speed LED (Amber) (2) LEDs Link/Activity LED (Green) (2) USB Type Connects to a USB keyboard or mouse. A connectors 877-877-2269 | blackbox.com Page 15...
-
Page 16: Initial Installation
3. Connect the HDMI display device (LED/LCD display or projector) to the HDMI OUT of the VX-1001-RX Receiver. NOTE: We strongly recommend using the supplied mounting brackets to secure the receiver to a flat surface behind/near the display device. - Page 17 NOTES 877-877-2269 | blackbox.com Page 17...
- Page 18 NOTES 877-877-2269 | blackbox.com Page 18...
- Page 19 NOTES 877-877-2269 | blackbox.com Page 19...
- Page 20 Tech support the way it should be. Great tech support is just 60 seconds away at 877-877-2269 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 60 seconds or less.
