- Page 1 USER MANUAL ICU504A USB 3.1 CAT6A/7 EXTENDER 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM...
-
Page 2: Table Of Contents
A.1 FCC Radio Frequency Interference Statement Warning ........................20 A.2 CE Statement ......................................20 A.3 IC Statement ......................................20 A.4 WEEE Statement ....................................20 APPENDIX B. TECHNICAL GLOSSARY ............................21 APPENDIX C. DISCLAIMER/TRADEMARKS ..........................23 C.1 Disclaimer .......................................23 C.2 Trademarks Used in this Manual ................................23 1.877.877.2269 BLACKBOX.COM... -
Page 3: Product Operation And Storage
Do not attempt to open the product casing as this may cause damage and will void the warranty. Use only the power supply provided with this product. When not in use, the product should be stored in a dry location between -4 to +158° F (-20 to +70° C). 1.877.877.2269 BLACKBOX.COM... -
Page 4: Specifications
32 to 122° F (0 to 50° C) Storage Temperature Range -4 to +158° F (-20 to +70° C) Operating Humidity 20 to 80% relative humidity, noncondensing Storage Humidity 10 to 90% relative humidity, noncondensing Compliance FCC Class B, CE Class B Environmental RoHS2 (CE) 1.877.877.2269 BLACKBOX.COM... -
Page 5: Overview
USB devices. The ICU504A enables users to extend beyond the standard 16-foot (5-meter) cable limit for USB peripheral devices. With the Extender, USB device(s) can be located up to 328 feet (100 meters) from the computer. The Extender is composed of two individual units: the local extender and remote extender. -
Page 6: Hardware Description
Figures 2-1 and 2-2 show the front and back of the Local Extender. Table 2-1 describes its components. Power Mode Status Link USB 2 USB 3 Config FIGURE 2-1. LOCAL EXTENDER, FRONT VIEW Link 24V 1A FIGURE 2-2. LOCAL EXTENDER, BACK VIEW 1.877.877.2269 BLACKBOX.COM... - Page 7 Accepts RJ-45 connector for CAT 6a/7 cabling to connect the Local Extender to the Link Port (RJ-45) Remote Extender. USB Host Port USB 3 Type B receptacle used to connect Local Extender to USB 3 Host computer. DC Power Port Locking connector for the included power adapter – accepts 24-VDC, 1-A. 1.877.877.2269 BLACKBOX.COM...
-
Page 8: Remote Extender
Figures 2-3 and 2-4 show the front and back of the Remote Extender. Table 2-2 describes its components. Power Mode Status Link USB 2 USB 3 Config FIGURE 2-3. REMOTE EXTENDER, FRONT VIEW Link 24V 2.71A FIGURE 2-4. REMOTE EXTENDER, BACK VIEW 1.877.877.2269 BLACKBOX.COM... - Page 9 Accepts RJ-45 connector for CAT 6a/7 cabling to connect the Remote Extender to the Link Port (RJ-45) Local Extender. (4) USB Device Ports Accepts all USB devices. DC Power Port Locking connector for the included power adapter – accepts 24-VDC, 2.71-A. 1.877.877.2269 BLACKBOX.COM...
-
Page 10: Installation
CAT6a/7 patch cords with RJ-45 connectors (if using premise cabling), ensuring the total cable length does not exceed 328 feet (100 meters). Host USB Cable USB Devices USB 3-2-1 up to 100m over CAT 6a/7 Optional Optional Network Network Connections Connections IP Control Local Extender Remote Extender FIGURE 3-1. TYPICAL INSTALLATION 1.877.877.2269 BLACKBOX.COM... -
Page 11: Preparing Your Site
3.6 INSTALLING THE REMOTE EXTENDER 1. Place the Remote Extender near the USB device(s). 2. Assemble the power adapter and country-specific power cord together and connect them into a suitable AC outlet. 3. Connect the power adapter to the Remote Extender. 1.877.877.2269 BLACKBOX.COM... -
Page 12: Checking The Installation
The USB 3.1 Extender complies with USB 2.0 and USB 3.1 Gen 1 specifications governing the design of USB devices. However, there is no guarantee that all USB devices or hosts will be compatible as there are a number of different characteristics that may impact the operation of USB devices over extended distances. 1.877.877.2269 BLACKBOX.COM... -
Page 13: Optional Ethernet Passthrough Connection
CAT 6a/7 Local Extender Remote Extender FIGURE 3-2. ETHERNET PASSTHROUGH APPLICATION Connect any network device or access port into the RJ-45 socket label “LAN” using up to 328 feet (100 meters) of standard CAT5e, 6 or 7 cabling. 1.877.877.2269 BLACKBOX.COM... -
Page 14: Optional Usb Extender Mounting Options
FIGURE 4-1. MOUNTING KIT Once the bracket mounting is secured onto the extender, it is ready for mounting onto a surface. NOTE: You will need to provide your own screws to secure the extender using the available slots on each bracket. 1.877.877.2269 BLACKBOX.COM... -
Page 15: Option 2: Usb Extender Direct Surface Mounting (Using Your Own Hardware)
5. Place a locking washer on each of the four screws and using a screwdriver, and fasten the extender into place. NOTE: Do not exceed a screw depth of 10-mm (0.4”) into the unit or damage may occur. 1.877.877.2269 BLACKBOX.COM... - Page 16 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: MOUNTING OPTIONS TECHNICAL SUPPORT 1.877.877.2269 4.0mm (5/32”) in 4 places 42.0mm (3.0315”) 205.5mm (8.0905”) FIGURE 4-3. DIRECT SURFACE MOUNTING MEASUREMENT STENCIL 1.877.877.2269 BLACKBOX.COM...
-
Page 17: Troubleshooting
The following table provides troubleshooting tips. The topics are arranged in the order in which they should be executed in most situations. If you are unable to resolve the problem after following these instructions, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com for further assistance. TABLE 5-1. TROUBLESHOOTING TIPS... - Page 18 Contact Black Box 5. The USB extender is malfunctioning. Technical Support at 877-877-2269 or info@blackbox.com for assistance. 7. If the second device operates as a USB 3 device as expected, the first device may not be compatible with this extender.
-
Page 19: Contacting Black Box Technical Support
5.2 CONTACTING TECHNICAL SUPPORT If you are experiencing problems not referenced in the Troubleshooting Guide, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com for assistance and provide them with the following information: Š Host computer make and mode Š... -
Page 20: Appendix A. Regulatory Information
A.2 CE STATEMENT We, Black Box Corporation, declare under our sole responsibility that the USB 2.0 ICU504A, to which this declaration relates, is in conformity with European Standard EN 55022, EN 55024, EN55032 and EN 61000. A.3 IC STATEMENT This Class A digital apparatus complies with Canadian ICES-003 Issue 6. -
Page 21: Appendix B. Technical Glossary
NOTE: Any given cable must be terminated using the same T568 scheme on both ends to operate correctly. RJ-45 Pin Positioning: TABLE B-1. T568A WIRING PAIR WIRE CABLE COLOR White/Green Green White/Orange Blue White/Blue Orange White/Brown Brown FIGURE B-2. T568A WIRING 1.877.877.2269 BLACKBOX.COM... - Page 22 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX B: TECHNICAL GLOSSARY TECHNICAL SUPPORT 1.877.877.2269 TABLE B-2. T568B WIRING PAIR WIRE CABLE COLOR White/Orange Orange White/Green Blue White/Blue Green White/Brown Brown FIGURE B-3. T568B WIRING 1.877.877.2269 BLACKBOX.COM...
-
Page 23: Appendix C. Disclaimer/Trademarks
C.2 TRADEMARKS USED IN THIS MANUAL Black Box and the Black Box logo type and mark are registered trademarks of Black Box Corporation. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners. 1.877.877.2269 BLACKBOX.COM... - Page 24 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2018. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. ICU504A_USER_REV1.PDF...
