ELECTRIC HALF-SIZE CONVECTION OVEN
POPEYE'S
MODEL
59-E3P
CAUTION:
WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning
Please read this manual completely before attempting
to install, operate or service this equipment
This manual is Copyright © 2022 Duke Manufacturing Co. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
trademark of the Duke Manufacturing Co.
Installation, Operation,
Parts & Maintenance Manual
P/N 155433
Rev AB 01/14/2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Duke 59-E3P
Summary of Contents for Duke 59-E3P
- Page 1 WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning This manual is Copyright © 2022 Duke Manufacturing Co. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered P/N 155433 trademark of the Duke Manufacturing Co.
-
Page 2: Table Of Contents
C. Location of Oven ..............................4 D. Electrical Connections ............................5 E. Ventilation ................................5 F. Electric Oven Assembly .............................5 G. Adjustments Associated with Installation ....................5 59-E3P Electrical Specifications ............................6 Control Panel...................................7 Operation ....................................8 A. Program Parameters ............................8 B. Programming Instructions ...........................8-9 C. Operation of Oven ..............................9 D. -
Page 3: Important Safty Instructions
• This equipment should be serviced by qualified personnel only. Contact the nearest Duke authorized service facility for adjustment or repair. • Do not block or cover any openings on the unit. -
Page 4: Installation Instructions
Electric Half-Size Convection Oven Manual INSTALLATION INSTRUCTIONS A. QUALIFIED PERSONNEL Duke Manufacturing Co. cannot assume liability for loss or damage suffered in transit. The carrier These installation instructions are for the use of assumes full responsibility for delivery in good order qualified installation and service personnel only. -
Page 5: Electrical Connections
D. ELECTRICAL CONNECTIONS • Once the oven has been removed from the carton, lay it on its left side (the side without the Each section of the Duke 5/9 Half-Size controls). Convection Ovens is rated at 8.0 kW. • Hold the leg and align with the matching holes Your oven is supplied for connection to a 208 in base and leg flange. -
Page 6: 59-E3P Electrical Specifications
Electric Half-Size Convection Oven Manual SPECIFICATIONS TOTAL KW VOLTAGE AMPS-1 PHASE AMPS-3 PHASE POWER SUPPLY CONNECTIONS 120001 Block, Terminal 4 Pole SOURCE WIRES GROUND WIRES 153213 Plug, Ground L1, L2 & L3 (3PHASE) L1 & L2 (1PHASE) -
Page 7: Control Panel
Electric Half-Size Convection Oven Manual POPEYE'S OVEN CONTROLS Main Power ON/OFF Switch Power On Light - Indicates elements are on. Light will go out when set temperature has been reached. Display - Indicates Time and/or Temperature Programming Buttons Preprogrammed Buttons - for 1 through 5 different recipe settings. -
Page 8: Operation
Electric Half-Size Convection Oven Manual OPERATION • Select the desired menu item by holding down the A. PROGRAM PARAMETERS MENU push button and pressing the UP/DOWN This unit comes pre-programmed from the factory buttons until the menu item is displayed (The with the following parameters for Menu items S1 Menu items are numbered S1 through S7) and S2... -
Page 9: Operation Of Oven
Electric Half-Size Convection Oven Manual OPERATIONS - continued Baking: Open door and quickly load trays(s). NOTE: The Time Base should never be changed (Slide tray all the way to the back wall, then slide unless directed to do so by America’s Favorite forward one inch). -
Page 10: Cleaning The Oven
If you should require assistance in the selection of a qualified service agency, please contact Duke Manufacturing Co.’s Service Department at 800-735-3853. -
Page 11: Adjustments
Electric Half-Size Convection Oven Manual MAINTENANCE INSTRUCTIONS A. ADJUSTMENTS D. BACK-UP THERMOSTAT CALIBRATION CHECK: Quite often malfunctions which are attributed • Turn the oven on by turning the Power Switch to to defects may be repaired by adjusting certain the ON position. parts rather than replacing them. -
Page 12: Trouble Shooting
Electric Half-Size Convection Oven Manual TROUBLE SHOOTING EMERGENCY BACK-UP SYSTEM DIGITAL DISPLAY IN THE CONTROLLER IS LIT, OVEN NOT HEATING Your oven is equipped with an emergency back-up A simple test. system to be used should the computer controller ever malfunction. It is intended only to be used to 1. - Page 13 Electric Half-Size Convection Oven Manual TROUBLE SHOOTING - continued OVEN NOT RECOVERING WHEN BAKING 1. TEMPERATURE PROBE OPENS 1. Check the Duty Cycle ON-TIME setting. Should the controller’s probe/cable become an 2. Measure the actual ON-TIME and OFF-TIME open circuit following occur: with a stopwatch or use the second hand of a A.
-
Page 14: Repair Parts List And Corresponding Drawings
Electric Half-Size Convection Oven Manual MODEL 59-E3P HALF-SIZE ELECTRIC CONVECTION OVEN REPAIR PARTS LIST Item # Part # Description Item # Part # Description 156333 Mylar 155113 Support, rack, oven 153142 Knob, control 155114 Rack, oven 153204 Light, oven ready, 208v/240v... - Page 15 Electric Half-Size Convection Oven Manual MODEL 59E3P OVEN CONTROLS ...
- Page 16 Electric Half-Size Convection Oven Manual INTERIOR OVEN COMPONENTS ...
- Page 17 Electric Half-Size Convection Oven Manual MODEL 59-E3P DOOR ASSEMBLY ...
- Page 18 Electric Half-Size Convection Oven Manual OVEN BACKUP FLUE GUARD THERMOSTAT SYSTEM SECURING DOUBLE STACKED OVENS 1. On rear of top oven remove two existing screws that are located at the lower right hand corner. 2. On rear of bottom oven remove two existing screws that are located at the upper right hand corner.
- Page 19 Electric Half-Size Convection Oven Manual COIL N.0. CONTACTOR COIL...
-
Page 20: Wiring Diagram
Electric Half-Size Convection Oven Manual Duke Manufacturing Co. Phone: 314-231-1130 Toll Free: 1-800-735-3853 2305 N. Broadway www.dukemfg.com Fax: 314-231-5074 St. Louis, MO 63102...
