ELECTRIC HALF-SIZE CONVECTION OVEN
LITTLE CAESARS
MODEL
59-E3L
CAUTION:
WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning
Please read this manual completely before attempting
to install, operate or service this equipment
This manual is Copyright © 2021 Duke Manufacturing Co. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
trademark of the Duke Manufacturing Co.
Installation, Operation,
Parts & Maintenance Manual
P/N 523513
Rev B 02/11/2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Duke 59-E3L
Summary of Contents for Duke 59-E3L
- Page 1 WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning This manual is Copyright © 2021 Duke Manufacturing Co. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered P/N 523513 trademark of the Duke Manufacturing Co.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions ............................2-3 Pre-Installation Instructions ..............................4 A. Qualified Personnel ............................4 B. Delivery & Inspection ............................4 59-E3L Electrical Specifications ............................5 Wiring Diagram ..................................6 Installation Instructions ..............................7 C. Location of Oven ..............................7 D. Electrical Connections ............................7 E. Ventilation ................................7 F. -
Page 3: Important Safety Instructions
• This equipment should be serviced by qualified personnel only. Contact the nearest Duke authorized service facility for adjustment or repair. • Do not block or cover any openings on the unit. -
Page 4: Pre-Installation Instructions
Electrical code, ANSI/NFPA 70-1990. DELIVERY AND INSPECTION Duke Manufacturing Co., does everything within its power to insure you receive your oven in good condition. They are strapped down on heavy wooden skids and surrounded by heavy “tri-wall” cartons to prevent shipping damage. They have all been carefully inspected before they were packaged and consigned to the carrier. - Page 5 Electric Half-Size Convection Oven Manual SPECIFICATIONS 48" 4 " 8 " 4 " 8 " 8 " 36" 2 " 4 " POWER SUPPLY CONNECTIONS Electrical Specifications - Per Section Block, Terminal 4 Pole 208V 240V Amps Amps 3 Phase 24.0 21.0 ▲...
- Page 6 Electric Half-Size Convection Oven Manual WIRE DIAGRAM COIL COIL N.0. N.0. CONTACTOR COIL COIL...
-
Page 7: Wiring Diagram
The rating plate and serial number data are located behind the motor access cover on the right side panel. ELECTRICAL CONNECTIONS Each section of the Duke 5/9 Half-Size Convection Ovens is rated at 8.0 kW. Your oven is supplied for connection to a 208 or 240 volt, 1 phase or 3 phase grounded circuit. -
Page 8: Adjustments Associated With Installation
Electric Half-Size Convection Oven Manual INSTALLATION INSTRUCTIONS ADJUSTMENTS ASSOCIATED WITH INSTALLATION Each oven section and all its components parts have been tested thoroughly and inspected before your oven was shipped from the factory. However, it is sometimes necessary to further test or adjust the oven once it has been installed. -
Page 9: Program Parameters
Electric Half-Size Convection Oven Manual CHANGING OVEN PARAMETERS A. PROGRAM PARAMETERS Button 1 Pressed: The display will show the number “2”. This unit comes pre-programmed from the factory with the following parameters for Menu items S1 1. Press the button that is to have its baking time and S2 changed. - Page 10 Electric Half-Size Convection Oven Manual CHANGING OVEN PARAMETERS - continued NOTE: pressing the DOWN switch until the display goes past zero (0) will be negative values, and will be indicated by a lighted COLON. 1. Press the “ENTER” switch to store the new Offset. NOTE: The Offset is used as a means to calibrate the probe temperature to agree with the temperature in the center of the...
-
Page 11: Operation Of Oven
Electric Half-Size Convection Oven Manual OPERATIONS OPERATION OF THE OVEN Operation: Operation of the computerized Auto Rack Load 1. Turn power switch to off position. Push the toggle Controller is quite simple. switch located on the right access panel of the Preheat: Close oven door and turn power knob oven to the up position. -
Page 12: Cleaning The Oven
Electric Half-Size Convection Oven Manual CLEANING CLEANING THE OVEN The stainless steel on your oven can be kept clean with a good stainless steel cleaner. Other surfaces should be wiped clean regularly with MILD detergent. Moisten a cloth and wipe down the oven while it is COLD. Wiping down an oven while hot will cause streaking and otherwise unsatisfactory results. -
Page 13: Maintenance Instructions
Electric Half-Size Convection Oven Manual MAINTENANCE INSTRUCTIONS A. ADJUSTMENTS D. BACK-UP THERMOSTAT CALIBRATION CHECK: Quite often malfunctions which are attributed • Turn the oven on by turning the Power Switch to to defects may be repaired by adjusting certain the ON position. parts rather than replacing them. -
Page 14: Trouble Shooting
Electric Half-Size Convection Oven Manual TROUBLE SHOOTING Oven Not Heating DIGITAL DISPLAY IN THE CONTROLLER IS LIT, OVEN NOT HEATING 1. Oven heating lamp is off. A simple test. 2. Digital display in the controller is not lit. (Make sure backup thermostat control switch is in the 1. - Page 15 Electric Half-Size Convection Oven Manual TROUBLE SHOOTING - continued OVEN NOT RECOVERING WHEN BAKING 1. TEMPERATURE PROBE OPENS 1. Check the Duty Cycle ON-TIME setting. Should the controller’s probe/cable become an 2. Measure the actual ON-TIME and OFF-TIME open circuit following occur: with a stopwatch or use the second hand of a A.
- Page 16 Electric Half-Size Convection Oven Manual MODEL 59-E3P HALF-SIZE ELECTRIC CONVECTION OVEN REPAIR PARTS LIST Item # Part # Description Item # Part # Description 156333 Mylar 155113 Support, rack, oven 153142 Knob, control 155114 Rack, oven 153204 Light, oven ready, 208v/240v 155404 Handle, door 153200...
- Page 17 Electric Half-Size Convection Oven Manual MODEL 59E3L OVEN CONTROLS ...
- Page 18 Electric Half-Size Convection Oven Manual INTERIOR OVEN COMPONENTS ...
- Page 19 Electric Half-Size Convection Oven Manual OVEN BACKUP MODEL 59-E3L THERMOSTAT SYSTEM DOOR ASSEMBLY FLUE GUARD ...
- Page 20 Electric Half-Size Convection Oven Manual Duke Manufacturing Co. Phone: 314-231-1130 Toll Free: 1-800-735-3853 2305 N. Broadway www.dukemfg.com Fax: 314-231-5074 St. Louis, MO 63102...
