Assembly
1. Loosen the fixing screws of the air inlet screen net and pull out the inlet screen.
2. Unpack the HEPA filter in the package, and place it into the slot. Ensure to install
in the correctly fitted space.
3. Push the air inlet screen back into position and fasten with the screws.
4. Install the HEPA filter on the other side as well by following the above steps.
②
③
①
