- Page 1 INSTRUCTION MANUAL Heat/Cool/Purifier Tower Fan Model: DCTF3HCP For domestic household use only.
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your air circulator for the first time and keep them in a safe place.
- Page 3 • Please ask a professional service agent to repair the product. Improper repair may cause danger to users. • Disconnect the appliance from mains power whenever it is not in use, before relocating it, and before cleaning. • Operate the appliance only at the voltage specified on the rating label. •...
- Page 4 • Ensure the water quality is pure and below 40°C when utilising the humidifying function. • Ensure water is being added to the appliance slowly with the use of a container to avoid overflowing and exceeding the maximum water level. •...
- Page 5 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children No extension leads or Where the power may be left unattended power boards cable may be damaged On a slope or Where there is risk Where it may be uneven surface...
-
Page 6: Specification
Specification Model no. DCTF3HCP 220-240V~50Hz Power supply 45W (cooling) Rated power 2200W (heating) Speed settings Heat settings Timer 12 hours Air Purifier 3 Stage Purification Adjustable temperature 15-35°C CADR Oscillation 90° Noise level (MAX) 55dB(A) Weight (net) 5.2kg Filter HEPA 13... - Page 7 Parts Remote Housing Control Panel (back) Front Grille Air Inlet Screen Indicator Light Base...
-
Page 8: Control Panel
Control Panel Timer / Temperature Air Quality In- display dicator light Sleep mode display Child Lock Purification / Heat Sleep Mode Fan Speed Oscillation Timer Temperature On/Off Remote Control Purification On/Off Fan Speed Heat Increase Temperature Increase Timer Decrease Timer Decrease Temperature Sleep Mode Oscillation... - Page 9 Assembly 1. Loosen the fixing screws of the air inlet screen net and pull out the inlet screen. 2. Unpack the HEPA filter in the package, and place it into the slot. Ensure to install in the correctly fitted space. 3.
-
Page 10: Operation
Operation When the power is connected, flick the power switch at the back of the unit to turn the device on. You can select different modes by pressing the keys/buttons on the control panel and/or remote control. 1. After the power switch is turned on, press the ON/OFF button to start the de- vice and begin using the functions. -
Page 11: Other Functionality
Operation 7. Press the PURIFICATION/SLEEP MODE button to enable the device to begin puri- fying the air or enable sleep mode. In PURIFICATION mode, the device will work to detect the air quality. If the air quality is excellent, the indicator light will be green. If the air quality is good, the indicator light will be yellow. - Page 12 Cleaning Over time, dust can accumulate on the grille covers, filter (if applicable) and fan blades, which can affect the fans performance. It is recommended to clean the fan at least once a month. 1. Turn the unit OFF and disconnect the appliance from the power supply. 2.
-
Page 13: Maintenance
Warranty Please refer to the warranty card in the box for warranty information. For any troubleshooting advice, please contact the relative Customer Care Centre below. Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd 8 Lakeview Drive, 38 Harris Road, East Tamaki,... - Page 16 Supplied by Glen Dimplex Australia 8 Lakeview Drive, Scoresby, Victoria, 3179 © Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
