USE AND CARE GUIDE
NOAH 52-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!

Advertisement

loading
Need help?

Need help?

Do you have a question about the 52-SNM and is the answer not in the manual?

Questions and answers

Summary of Contents for Home Decorators Collection 52-SNM

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................14 Warranty ................3 Care and Cleaning ............. 15 Pre-Installation ..............3 Troubleshooting ..............15 Installation ................6 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as To reduce the risk of electric shock, ensure the electricity has...
  • Page 3: Warranty

    A certain amount of “wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Home Decorators Collection hereby disclaims any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by law.
  • Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Blade attachment screws Thumb screw Decorative nut Plastic wire connector...
  • Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket Blade (inside canopy) Light kit pan with decorative cage Ball/downrod assembly Light kit decorative cage Canopy Glass bowl Decorative motor collar cover CFL bulb (23-Watt Max) Fan-motor assembly Receiver Remote control (battery included) IMPORTANT: This product and/or components are...
  • Page 6: Installation

    Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock, proper blade clearance when installing on a steep, sloped or personal injury, mount the fan to an outlet box ceiling.
  • Page 7: Assembly

    Assembly - Standard Ceiling Mount Preparation for standard mounting Routing the wires □ □ Remove the canopy ring (GG) from the canopy (C) by turning Route the wires exiting at the top of the fan-motor the ring counterclockwise until it unlocks. assembly (E) through the canopy ring (GG).
  • Page 8 Assembly - Hanging the Fan Attaching the fan to the electrical Hanging the fan □ Carefully lift the fan-motor assembly (E) up to the slide-on mounting bracket (A). WARNING: To reduce the risk of fire, electric shock, or other □ personal injury, mount the fan to an outlet box or supporting Seat the hanger ball portion of the ball/downrod assembly (B) system marked “Acceptable for fan support of 35 lbs.
  • Page 9 Assembly - Hanging the Fan (continued) Setting the code on the remote □ Install two 1.5V AAA batteries (included). □ control and receiver Replace the battery cover on the remote control (L). □ Insert the silicone rubber stopper (OO) into the hole on the NOTE: The frequencies on your receiver and hand unit have receiver (K) to cover the dip switches.
  • Page 10 Assembly - Hanging the Fan (continued) Wiring the receiver to the household Wiring the fan to the receiver wiring WARNING: To avoid possible electrical shock, turn the IMPORTANT: Use the wire connecting nuts (DD) supplied with electricity off at the main fuse box before wiring. If you your fan.
  • Page 11 Assembly - Hanging the Fan (continued) Mounting the fan-motor assembly Wrapping the extra wire (standard mount) WARNING: When using the standard ball/downrod mounting, the NOTE: Follow this step ONLY if you did not cut the extra length off tab in the ring at the bottom of the mounting bracket must rest in from the wires coming from the ceiling fan to the receiver.
  • Page 12 Assembly - Attaching the Blades Attaching the fan blades □ Attach a blade (F) to blade bracket (M) using the decorative nuts(BB) and blade attachment screws (AA) provided. Insert a blade attachment screw (AA) through a hole in the blade (F) and the blade bracket (M) and into the decorative nut (BB).
  • Page 13 Assembly - Attaching the Light (continued) Installing the bulbs and glass bowl CAUTION: Make sure the power is off before attaching or removing the glass bowl. WARNING: Allow the glass bowl to cool completely before removing. □ With power off, install CFL bulb (J)(Max.23W, included) by screwing into the light bulb sockets.
  • Page 14: Operation

    Operating Your Fan and Remote Control A. Warm weather Remote Control - Your fan is equipped with a remote control to operate the speed and lights of your new ceiling fan. Speed setting for warm or cool weather depends on factors such as the room size, ceiling height, number of fans and so on.
  • Page 15: Care And Cleaning

    Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □...
  • Page 16 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
