ASSEMBLY INSTRUCTION
VIVALDI 3 SEATER CHAISE
ITEM CODE 68998
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
292cm
Depth: 168cm
1
68998
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amart Furniture VIVALDI 68998
Summary of Contents for Amart Furniture VIVALDI 68998
- Page 1 ASSEMBLY INSTRUCTION VIVALDI 3 SEATER CHAISE ITEM CODE 68998 Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 292cm 99cm Depth: 168cm Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 68998...
- Page 2 PRE‐ASSEMBLY PREPARATION Before you start: Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product Take care when lifting. Product should be assembled as near as possible to the point of use Ensure that you have all required contents for complete assembly Always read the assembly instructions carefully before beginning assembly.
- Page 3 Step1: Keep back rest in upright position, then slide receivers into steel mechanism posts at the seat of LHF facing recliner, and press both sides of the back firmly into place to ensure fully locked. Receiver at bottom of back rest Mechanism post at rear of seat slide receiver into post Step2: Locate package of sofa legs that is placed into zipper pocket at the bottom of armless chair. With 2 people carefully turn onto back on piece of cardboard or carpet to protect covering Plastic leg a. Bolt M8X60 4pcs 68998...
- Page 4 Step3: Take out the 4 plastic legs, then screw them into holes at the bottom of armless chair. Step4: Slide back receivers into steel mechanism posts in the base of armless chair, and then press both sides of the back firmly into place to ensure the back automatically locks in place. Receiver at bottom of back rest Mechanism post at rear of seat slide receiver into post 68998...
- Page 5 Step5: Locate package of sofa legs and hardware that is placed into zipper pocket at the bottom of RHF facing chaise. With 2 people carefully turn onto back on piece of cardboard or carpet to protect covering Bolt M8X60 Washer Support leg Hexagon key Side leg a. Bolt M8X60 4pcs 4pcs 4pcs 1pcs 1pcs Step6: Take out 4 side legs, then use hexagon key to fasten the legs to the holes at bottom of the RHF chaise with bolts and washers. Arm Side 68998...
- Page 6 Step7: Take out the support leg and then screw into the hole at rear of armless side of the RHF chaise. Armless Side Arm Side clockwise turning for tighten of center leg with screw Step8: Slide back receivers into steel mechanism posts in the base of the RHF chaise, and then press both sides of the back firmly into place to ensure the back automatically locks in place. Receiver at bottom of back rest Mechanism post at rear of seat slide receiver into post 68998...
- Page 7 Step9: Connect 3 pieces of the suite from right to left. Begin with RHF chaise, then armless chair, then LHF recliner finally. Right Left 1st PCS 3rd PCS slide clips at connecting item into clips at connected item, then together press front and rear side of connecting item to ensure the clips go into each other to the bottom. ASSEMBLY IS COMPLETE 68998...
- Page 8 68998...
