Provision the RT AMU-912
1. Right arrow to the CONFIG column and arrow down
to SHELF OPTIONS and press <enter>. Arrow
down to the DB-25 SETTING and use the space bar to
toggle to ENV-ALARMS. Arrow down to ACCEPT
SHELF OPTIONS and press <enter>. You will be
prompted to save changes. Type 'y' to confirm.
2. (Optional) You may assign a shelf ID at this time.
Arrow up to PG-Flex Shelf ID and type in a system
Plus
ID with 20 characters maximum. Arrow down to
ACCEPT SHELF OPTIONS and press <enter>.
You will be prompted to save changes. Type 'y' to
confirm.
3. Press the ESC key once to exit SHELF OPTIONS.
The CONFIG column should still be highlighted.
Press the arrow down key until ENVIRONMENTAL
ALARMS SETUP is highlighted and press <enter>.
Use the arrow keys to navigate to each SETUP option
and then use the space bar to toggle through the
options. Set the options as shown in Table 9.
4. Arrow down to ACCEPT ENVIRONMENTAL
ALARM SETUP CHANGES and press <enter>.
You will be prompted to save changes. Type 'y' to
confirm.
5. Press the ESC key once to exit ENVIRONMENTAL
ALARMS SETUP. The CONFIG column should
still be highlighted. Press the arrow down key until
ENVIRONMENTAL ALARM TYPES is
highlighted and press <enter>. Use the arrow keys to
navigate to each TYPE option and then use the space
bar to toggle through the options. Set the options as
shown in Table 10.
6. Arrow down to ACCEPT ENVIRONMENTAL
ALARM TYPE CHANGES and press <enter>. You
will be prompted to save changes. Type 'y' to confirm.
7. Press the ESC once to return to CONFIG. You are
now ready to provision the PMX-744.
Table 9. ENVIRONMENTAL ALARMS SETUP
ENV Alarm Setup TR-08 Datalink ALM
Environmental alarm 1 COM-PWRMISC
Environmental alarm 2 COM-PWRMISC
Environmental alarm 3 COM-MJ
Environmental alarm 4 COM-MN
Table 10. ENVIRONMENTAL ALARM TYPES
Environmetal Alarms
Environmental Alarm 1 (ENV1)
Environmental Alarm 2 (ENV2)
Environmental Alarm 3 (ENV3)
Environmental Alarm 4 (ENV4)
Provision the RT PMX-744
You should still be logged in and the CONFIG column
should be highlighted under the PG-Flex
Management Unit banner as described in step 1 under
Provision the AMU-912.
NOTE: You must provision the ACTIVE MUX.
Provisioning information will be copied to the stand-by
MUX once accepting changes is completed.
1. Left arrow to the SELECT column and arrow down to
MUX 1. This assumes MUX 1 is the active MUX. If
not, arrow down to MUX 2, and press <enter>. Note
the banner now reads PG-FlexPlus CO MUX Unit #
n where n is the MUX unit that is active.
2. Right arrow to CONFIG and press the down arrow.
The Equipment Options menu item should be
highlighted. Press <enter>.
3. Use the arrow keys to navigate to each option and then
use the space bar to toggle through the options. Set the
options as shown in Table 11. Note the difference with
a Universal versus Integrated application under the
MUX Configuration option.
4. Arrow down to ACCEPT EQUIPMENT OPTION
CHANGES and press <enter>. You will be prompted
to save changes. Type 'y' to confirm.
Page 5 of 11
5. Press ESC three times to return to the main AMU
logout screen and press 'y' to logout and return to the
password screen.
Table 11. PMX-744L1B Configuration
TDM Cross Connect Mode
Primary Timing Source
Secondary Timing Source
Type
MUX Protection Switching
MN
TDM DS1 Frame Format
MN
TDM DS1 Line Code
MJ
TR-08 Alarm Format
MN
TR-08 Facility Protection
MUX Configuration
*The RT MUX must loop time off of the incoming DS1-1
signal. The provisioning shown assumes a single DS1 input. If
Advanced
Plus
a second DS1 input is used, set the secondary timing source to
DS1-2.
NOTE: In Universal mode the MUX Configuration option
must be set to CB-RT. In Integrated mode, the MUX
Configuration option must be set to NORMAL. Refer back
to the first section under PG-Flex
description of each configuration.
Install the PLL-735 and FLL-814 Line Unit
NOTE: The following procedures assume the transmission
circuits between the CO and the Cabinet Shelf are
configured correctly and fully operational (Table 11) and the
HDSL circuits between the Cabinet and remote enclosures
are wired correctly and equipment is placed at the remote
locations.
Table 12 describes the LED indicator status on the front
panel of the PLL-735. Refer to Table 14 for fault isolation
and troubleshooting procedures.
Option Setting
12 DS0/SLOT
DS1-1*
DS1-1*
ENABLED
TR-08
AMI
16 FRAME
DISABLED
See Note
System on page 1 for a
