CAPRI COFFEE TABLE 120X60CM
PRODUCT IMAGE
PRE-ASSEMBLY PREPARATION
BEFORE YOU START
1.Choose a clean, level, spacious assembly area.
2.Avoid hard surfaces that may damage the product.
3.Check and ensure you have all required contents for complete assembly.
4.Always read the assembly instructions carefully before beginning.
5.The packaging and contents can be a choking hazard, therefore keep out of
reach of small children at all time.
6.Do not over tighten bolts as this may damage the thread.
ALLOW 30 MINUTES
FOR ASSEMBLY
2
2 PEOPLE REQUIRED
FOR ASSEMBLY
COMPONENTS / HARDWARE
A
B
1PC
4PCS
D
E
20PCS M6*20
20PCS
G
1PC
IMPORTANT:
On initial assembly, DO NOT tighten bolts
completely until all parts are joined. Once
all parts are joined,
flip table over, ensure all legs are even.
Once even, tighten bolts.
C
1PC
F
20PCS
Advertisement
Related Manuals for Target CAPRI
Summary of Contents for Target CAPRI
- Page 1 COMPONENTS / HARDWARE CAPRI COFFEE TABLE 120X60CM 4PCS PRODUCT IMAGE 20PCS M6*20 20PCS 20PCS PRE-ASSEMBLY PREPARATION BEFORE YOU START 1.Choose a clean, level, spacious assembly area. 2.Avoid hard surfaces that may damage the product. 3.Check and ensure you have all required contents for complete assembly.
- Page 2 STEP 2: STEP 1: PLACE THE TABLE TOP UPSIDE DOWN ON A FLAT,SOFT SURFACE. ALIGN HOLES IN PART(C) WITH THREADS IN PART(B). ALIGN HOLES IN PART (B) OVER THREADS IN PART(A). ATTACH PART(C ) TO PART(B).USING BOLTS AS SHOWN BELOW . DO NOT COMPLETELY TIGHETEN BOLTS AT THIS POINT ATTACH PART(B) TO PART(A) .USING BOLTS AS SHOWN BELOW .
