3. PRODUCT OVERVIEW
3.2 TECHNICAL SPECIFICATIONS
Serial number format Home Advanced 7
Serial number format Home Advanced 11
Maximum charge capacity
Standard configured charge capacity
Electric safety category
Connector type
Dimensions (H x W x D)
Weight
Standard colours
IEC-62262 IK code (robustness)
IEC-60529 IP code (protection class)
Certificates
kWh measurement & meter part number
User interface
Identification
Communication backoffice
Communication Load Shedding module
CONTINUED ON NEXT PAGE
INSTALLATIEHANDLEIDING – P6
INSTRUCTION MANUAL – P6 | P6
07A _ _ _ _ _
07B _ _ _ _ _
Home Advanced 7: single phase 32A*
Home Advanced 11: triple phase 16A*
Home Advanced 7: 3,7 kW - single phase 16A**
Home Advanced 11: 11 kW - triple phase 16A**
Class I
Type 2S - socket with shutter
503.5 x 200 x 137 mm
± 4.5 kg
Rear side RAL 7031 (grey)
Front side RAL 9010 (white)
IK10
IP54*** (for indoor and outdoor use)
IEC-61851-1
IEC-61851-22
EV-Ready 1.4G1 & ZE-Ready 1.4G1
IEC-62262 -> IK10
IEC-60529 -> IP54
MID certified
LED
Plug & Charge (standard configured)
RFID (NFC) Mifare 13.56 MHz (via local configuration)
IEC 14443A
IEC 14443B
Ethernet connection (DHCP, TCP 443, TCP80, TCP21)
WiFi - 802.11 (2,4 GHz)
Straight wired RJ11 or RJ12 (6P6C) connectors on
CAT5 cable (max 100 mtr)
VERSION 0129NM02INT01
07A0RNM20ENG05
