3. PRODUCT OVERVIEW
3.4.2
OVERVIEW INSTALLING ACCESSORIES
P1 Port
for Load Shedding
Shunt connection
(L1 & N from
accessories cable)
5 wires Ø 1,5mm
2
accessories cable inlet
INSTALLATIEHANDLEIDING – P10
INSTRUCTION MANUAL – P10 | P10
INSIDE
VERSION 0129NM02INT01
07A0RNM20ENG05
ON/OFF Peak
connection
(L2 & L3 from
accessories cable)
Cable clamp
UTP data cable inlet
with rubber seal for
Load Shedding
