VT9930WDM
FM VIDEO TRANSMITTER + DATA TRANSCEIVER
DATA
TRANSMIT
DATA
RECEIVE
ifs
VIDEO
IN
POWER
VR9930WDM
FM VIDEO RECEIVER + DATA TRANSCEIVER
DATA
TRANSMIT
DATA
ifs
RECEIVE
VIDEO
GAIN
SYNC
CARRIER
POWER
NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.
RS232 IN - 2
RS232 OUT - 3
GROUND - 7
International
Fiber
- DATA IN - 10
Systems
+ DATA IN - 11
Incorporated
-DATA OUT - 12
+ DATA OUT - 13
ON = RS485
OFF = RS422
RS232 IN - 2
RS232 OUT - 3
GROUND - 7
International
Fiber
- DATA IN - 10
Systems
+ DATA IN - 11
Incorporated
-DATA OUT - 12
+ DATA OUT - 13
ON = RS485
OFF = RS422
RTS - 4
CTS - 5
DSR - 6
DCD - 8
OPTICAL FIBER
VIDEO IN
DTR - 20
AC - 3
24 VAC
CENTER
- 2
TAPPED
AC - 1
RTS - 4
CTS - 5
DSR - 6
DCD - 8
OPTICAL FIBER
VIDEO IN
DTR - 20
AC - 3
24 VAC
CENTER
- 2
TAPPED
AC - 1
Coax cable
Video Source
Blue
Green
Brown
Simplex single mode
fiber optic cable
Coax cable
Video
Monitor
