Watertight Sand Filter; Triggering System Start-Up - PREMIER TECH REWATEC Phosphorus removal unit Owner's Manual

The primary reactor model PRT-660 is designed to treat up to 1,440 L/d (up to 4 bedrooms). the primary reactor model PRT-960,
composed of 2 tanks installed in series, is designed to treat up to 2,160 L/d (up to 6 bedrooms). The EC unit, model DpEC-090 can
also treat up to 2,160 L/d (up to 6 bedrooms). As the primary reactor the electroagulation unit is available in concrete or polyethylene.
Designation of different models is show in the table below.
Number of bedrooms
1
2
3
4
5
6*
1.3.

Watertight sand filter

The watertight sand filter is a wastewater treatment system whose design is based on the replacement of the natural soil layer by a
filtering media. The sand filter unit combined with a phosphorus removal unit (DpEC) provides an efficient solution for phosphorus
removal and for disinfection.
At the phosphorus removal unit (DpEC) effluent, the wastewater is directed to the watertight sand filter by a pumping station to feed the
distribution device. The water percolates vertically through the sand bed and then collected by a network of perforated pipes located
on the gravel bed at the base of the watertight sand filter.
The sand filter allows continuous or intermittent use without requiring any special precautions and without any impact on the quality of
the treatment. The owner has no particular action to make to bring the system into operation; the owner only needs to ensure
compliance with the operating instructions described below.
The dimensions of the watertight sand filter
wastewater coming from the residence and any domestic wastewater coming from any other type of building.
1.3.1. Dimensions of the watertight sand filter
Total daily flow
1,080 L
1,260 L
1,440 L
1,800 L
2,160 L
1.4.

Triggering system start-up

The start-up of the phosphorus removal unit (DpEC) (i.e. the electrification of the Electrodes and Agitating Pump) can be performed
two ways. However, two simultaneous conditions must be taken into consideration. Should one of these two conditions not be met,
the system will not start. The device will also detect the presence of incoming wastewater.
Owner's manual
Phosphorus removal unit (DpEC)
Maximum daily flow (L/d)
540
1 080
1 260
1 440
1 800
2 160
are determined by the number of bedrooms in the residence or by the total daily flow of
Number of bedrooms
2 and less
3
4
5
6
Polyethylene
Electrocagulation unit
DpEC-090P
DpEC-090P
DpEC-090P
DpEC-090P
DpEC-090P
DpEC-090P
Length of the sand filter
6.4 m
Page 4/14
Concrete
Electrocagulation unit
DpEC-090B
DpEC-090B
DpEC-090B
DpEC-090B
DpEC-090B
DpEC-090B
Width of the sand filter
3 m
4.5 m
20220816
Item # 339921
