- Page 1 Owner’s manual Passive disinfection filter Certi ed to BNQ standard NQ 3680-910...
-
Page 2: Table Of Contents
Owner’s Manual Congratulations on your purchase of a disinfection filter (FDi) system from Premier Tech. With the disinfection filter (FDi) system, you have wisely chosen to protect your health as well as the environment. This manual contains information on the operation, operating guidelines, maintenance and warranties of the disinfection filter (FDi). -
Page 3: Operating Principle
Operating Principle Septic tank with Ecoflo biofilter effluent filter Passive disinfection filter Figure 1 – Overview of Ecoflo biofilter and passive disinfection filter (FDi) The passive disinfection filter (FDi) is designed to reduce the concentration of pathogenic organisms at the Ecoflo biofilter’s effluent for sites where it is impossible to infiltrate wastewater through an absorption bed or polishing field. - Page 4 Table 1 – Passive disinfection filter (FDi) dimensions 100% coco Ecoflo biofilter Bi-layer Ecoflo biofilter Number of Lenght of Daily Flow Width of Width of inlet Width of Width of inlet bedrooms FDi (L1*) zone (L2*) FDi (L1*) zone (L2*) 1 080 L 2 and less 5,4 m...
-
Page 5: Operating Guidelines
• NEVER plant trees within 2 m (6' 5") of the passive disinfection filter (FDi). By respecting these guidelines, you contribute to the proper operation of the system and help prolong the life of your septic installation. Failure to abide by these guidelines may, at Premier Tech’s discretion, render the warranty invalid. Page 4/12 Owner’s Manual... -
Page 6: What You Must Know
Your home must be equipped with an air vent that is in proper working order and all plumbing must comply with the applicable standards of your municipality’s building code. Premier Tech strongly recommends using a 100 mm (4") diameter pipe for the air vent. -
Page 7: Disinfection Filter (Fdi) Features
The light indicator is activated when a water recirculation problem occurs. In that event, the problem must be verified: communicate with Premier Tech Aqua’s After-Sales Service Department. The light indicator may be deactivated by pressing the “RÉARMEMENT / RESET” button. This button can also be used to test a recirculation cycle and thus check the FDi’s status. To do so, press and hold down the button for 5 seconds. -
Page 8: Maintenance
Ecoflo biofilter The maintenance of your Ecoflo biofilter is done by our local Premier Tech partner network or a qualified third party as referred to in section 1x.2) of the Regulation respecting waste water disposal systems for isolated dwellings (Q-2, r.22). This service includes a visual inspection and a verification of all components as well as maintenance of the filtering media. -
Page 9: What To Do In Case Of
If a winter power failure is prolonged or if you are planning to shut down your system, protect the components of your septic system against freezing. If one of these situations occurs, or If you have any questions about restarting your system, contact Premier Tech’s After- Sales Service Department. - Page 10 (g) Any damage or problem, if the maintenance of the passive disinfection filter disinfection tertiary treatment) (hereinafter called “Initial Purchaser”), for a (FDi) was not carried out by a person authorized by Premier Tech or by a qualified residential installation, as well as any subsequent purchaser (hereinafter called third party as referred to in section 1x.2) of the...
- Page 11 Province of Quebec. confirms, by forwarding the attached “Notice of New Property Owner” to Premier Tech within a reasonable delay, that he/she is the new owner of the 11. PRIORITY OF THE CERTIFICATE OF WARRANTY property, he/she understands and is aware of the content of this Certificate of This Warranty supersedes any contract or understanding, written or verbal, Warranty and accepts its terms and conditions.
-
Page 12: Annex 1 - Ecoflo Biofilter Models
Annex 1 – Ecoflo biofilter models Page 11/12 Owner’s Manual 20210721 Disinfection filter (FDi) Item # 339919... -
Page 13: Annex 2 - Notice Of Change Of Property Ownership
____ Phone (other) ____ Email ________ I hereby declare that the residence serviced by a Premier Tech treatment system located at the above address changed ownership on this date If you are the PREVIOUS owner: I have provided the system’s Owner’s Manual and the included Warranty Certificate* to the new owners. I have informed them that an annual maintenance is required on the system as per local regulation and to maintain the validity of the product’s warranties.
