PREMIER TECH ECOFLO Owner's Manual

Hide thumbs Also See for ECOFLO:
Table of Contents

Advertisement

Quick Links

Download this manual
Certi ed
Certi ed
to NSF/ANSI
to CAN/BNQ
standard
standard
40 & 245
3680-600
OWNER'S MANUAL
Sustainable septic solution
Certi ed
to BNQ
standard
NQ 3680-910

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECOFLO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PREMIER TECH ECOFLO

Summary of Contents for PREMIER TECH ECOFLO

  • Page 1 OWNER’S MANUAL Sustainable septic solution Certi ed Certi ed Certi ed to NSF/ANSI to CAN/BNQ to BNQ standard standard standard 40 & 245 3680-600 NQ 3680-910...

  • Page 2: Table Of Contents

    Ecoflo biofilter - Owner’s manual Premier Tech thanks you for having installed an Ecoflo biofilter on your property. We are passionate about the protection of underground water sources and the environment. Your choice certainly helps in this way! This manual contains information on the operation, operation guidelines, maintenance, and warranties on your Ecoflo biofilter.

  • Page 3: Operating Principle

    The model and the number of Ecoflo biofilter are determined by the domestic wastewater flow per day. The selection of the model also depends on the available surface area, the topography of the lot, as well as the type, permeability, and depth of the natural soil on site.

  • Page 4: Operating Guidelines

    NEVER plant trees within 3 m (9' 10") of the lid of a fiberglass Ecoflo biofilter or within 2 m (6' 6") of the absorption bed. Roots seek nourishment in the filtering medium of the Ecoflo biofilter and their growth could cause damage to the unit.

  • Page 5: Warranty Start-Up

    3 m (9' 10") NEVER drive a vehicle or place objects weighing more than 225 kg (500 lb) too close of the lid of your Ecoflo biofilter. See minimum distances to respect in table above. If you are planning any kind of landscaping or property work (snow removal, lawn mowing, excavation, etc.), make sure you advise all those involved, so they do not damage your septic...

  • Page 6: Maintenance

    The selective method without a filter allows the solids to settle within the truck before the water is returned to the primary/septic tank. As such, in an effort to ensure the Ecoflo biofilter continues to perform optimally, it is important that you ensure that the water returned to the primary/septic tank has been properly clarified and contains very few, if any, suspended solids.
  • Page 7 The new filtering medium is then installed by an authorized agent or the pumper. To know more about the maintenance of your Ecoflo biofilter, refer to your Maintenance Agreement. If you need help or more information, please contact our Customer Service team at +1 800 632-6356 or visit our website at PT-WaterEnvironment.com.

  • Page 8: Ecoflo Biofilter With Pump

    Ecoflo biofilter with pump Some Ecoflo biofilter models have an integrated pumping station (other situations may require a separate pumping station), that directs treated effluent to an appropriate disposal area. Electro-mechanical components are included in this system. Visual and audio alarm system The pumping station is equipped with a high-water-level float connected to an alarm system.

  • Page 9: What To Do In Case Of

    What to do in case of... An activated alarm If an alarm is activated, unrelated to a power failure, contact Premier Tech’s After-sales Service team so the problem can be identified and corrected. A prolonged power failure If a winter power failure is prolonged or if you are planning to shut down your system, protect the components of your septic system against freezing.

  • Page 10: Certificate Of Warranty For Ecoflo Biofilter

    Premier Tech’s project as described in the Owner's Manual; manager. (f) Any damage or problem, if it is shown that the usage of the Ecoflo biofilter was not in accordance with the instructions and guidelines described in the Owner's Manual;...
  • Page 11 If the Customer and/or the Customer's Successors notify Premier Tech of an alleged defect or malfunction of the Ecoflo biofilter and that, after inspection, it is found that no such defect or malfunction exists or that such defect or malfunction is excluded from or does not apply to the Warranty, a minimum charge of $200.00...

  • Page 12: Annex 1 - Ecoflo Biofilter Models

    Appendix 1 – Ecoflo biofilter models The Ecoflo biofilter can be found in different model series, which are ST, STB, EC, EC5, and EC7. The model number of the Ecoflo biofilter relates to its characteristics, as presented in the following table. NOTE: Some model series may not be approved in your area.
  • Page 13 EC7 model series (maximum applicable HLR 700 L/m d or 17.2 gal/ft Example: EC7-600-P-P-PACK refers to an Ecoflo system with a filtering medium made of coconut husk fragments. The shell is made of polyethylene, the daily flow capacity is 600 US gal/d, there...

  • Page 14: Annex 2 - Installation Diagrams

    Appendix 2 – Installation diagrams Primary/septic tank Ecoflo with effluent filter Infiltration discharge Primary/septic tank Ecoflo with effluent filter Gravity discharge Primary/septic tank Ecoflo with effluent filter Pumped discharge Page 13/14 Ecoflo Owner’s Manual 20201009 Canada and United States Item # 339913...

  • Page 15: Annex 3 - Notice Of Change Of Property Ownership

    ____  Phone (other) ____  Email ________  I hereby declare that the residence serviced by a Premier Tech treatment system located at the above address changed ownership on this date If you are the PREVIOUS owner:  I have provided the system’s Owner’s Manual and the included Warranty Certificate* to the new owners. I have informed them that an annual maintenance is required on the system as per local regulation and to maintain the validity of the product’s warranties.
