Samsung HT-C5200/EDC Service Manual page 71

Loc. No. Part No.
VC37 2203-006048
VL6 2703-000398
WR15B 2007-001044
X202 2801-003843
X202 2801-004008
X202 2801-004371
ZRN10 2011-001261
ZVL3 3301-001495
0202-001463
0202-001477
0202-001608
0202-001767
0204-002420
0204-002607
0403-001797
0904-002352
1001-001298
1003-002187
1003-002188
1006-001438
1107-001844
1107-001887
1203-005469
1203-005526
1203-006067
1203-006104
1204-003090
1205-003160
2007-000146
2007-000606
2007-000657
2007-000946
2007-001329
2007-002768
2007-002915
2007-007008
2007-007132
2007-007135
2007-007313
2007-007315
2007-007318
2007-007334
2007-007467
2007-007698
2007-007798
2007-008275
2007-008453
2011-001345
Samsung Electronics This Document can not be used without Samsung's authorization.
Description
C-CER,CHIP
INDUCTOR-SMD
R-CHIP
CRYSTAL-SMD
CRYSTAL-SMD
CRYSTAL-SMD
R-NETWORK
BEAD-SMD
SOLDER-WIRE
SOLDER-CREAM
SOLDER-WIRE FLUX
SOLDER-CREAM
SOLVENT
FLUX
DIODE-ZENER
IC-DSP
IC-ANALOG SWITCH
IC-MOTOR DRIVER
IC-MOTOR DRIVER
IC-BUS DRIVER
IC-NOR FLASH
IC-NAND FLASH
IC-POWER SUPERVISOR
IC-DC/DC CONVERTER
IC-POWER SUPERVISOR
IC-DC/DC CONVERTER
IC-VIDEO DECODER
IC-CODEC
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-CHIP
R-NETWORK
Specification
100nF,10%,10V,X7R,TP,1005
10uH,10%,3225
56ohm,5%,1/10W,TP,1608
18.432MHz,30ppm,SMD,20pF,50o
24MHz,20ppm,28-AAN,12pF,30oh
12.288MHz,50ppm,SX-1,18pF,50
33ohm,5%,1/16W,L,CHIP,8P,TP,2.
120ohm,2012,2500mA,TP,115ohm/10
LFC2-W3.0,-,D3,99.79Sn/0.2Cu
LST309-M,D20~45um,96.5Sn/3A
LFC7-107,D0.8,99.3Sn/0.
LST-5710,D20~38,Sn-57Bi-1Ag
1M-1000,C3H70H,96
DF-234U,13%,14KG,Gravity 0.82
NZH3V0B,2.85/3.15V,500mW,SOD
TMS320DA788B,TQFP,144P,20.2x20.2m
L10X,10P,2.1x1.6,1,1.65
AM9268,SOP,42P,18x7.5mm,
AM9858,SOP,28P,18x7.5mm,
R5H30201NA04NQ08,QFN,20P,4
MX29LV160DTTI-70G,16Mbit,2M
NAND02GW3B2DN6,2Gbit,256Mx
MIC2009YM6,SOT-23,6P
AOZ1025DIL,DFN,16P,5x
TPS2553DBVR,SOT-23,6
MP8707EN,SOIC8E,8P,4.
BCM7630,FCBGA,422P,19x1
AK4113VF,VSOP,30P,9.7x5.6mm,PLA
6.8Kohm,5%,1/16W,TP,1005
240ohm,1%,1/10W,TP,1608
27ohm,1%,1/10W,TP,1608
47ohm,1%,1/10W,TP,1608
7.5Kohm,5%,1/16W,TP,1005
6.2Kohm,1%,1/10W,TP,1608
4.02Kohm,1%,1/10W,TP,1608
300ohm,5%,1/16W,TP,1005
15Kohm,1%,1/16W,TP,1005
18Kohm,1%,1/16W,TP,1005
6.8Kohm,1%,1/16W,TP,1005
3.9Kohm,1%,1/16W,TP,1005
1Kohm,1%,1/16W,TP,1005
200Kohm,1%,1/16W,TP,1005
12.1Kohm,1%,1/16W,TP,1005
5.1Kohm,1%,1/16W,TP,1005
10ohm,1%,1/16W,TP,1005
30Kohm,1%,1/16W,TP,1005
1.24Kohm,1%,1/16W,TP,1005
10Kohm,5%,1/16W,L,CHIP,8P,TP,2
Exploded View & Part List
Qty. SNA Remark
118 SA
1 SA
4 SA
1 SA
1 SA
1 SNA
10 SA
3 SA
6.171 SNA
1 SNA
0.167 SNA
2.788 SNA
3.25 SNA
2.52 SNA
1 SNA
1 SA
4 SNA
1 SA
1 SNA
1 SA
1 SNA
1 SNA
1 SA
1 SA
1 SNA
2 SA
1 SNA
1 SA
1 SNA
4 SA
1 SA
1 SA
1 SA
1 SA
1 SA
1 SNA
1 SA
2 SNA
1 SA
1 SNA
2 SNA
1 SNA
1 SA
1 SNA
8 SA
2 SNA
1 SNA
3 SA
5-12
