Samsung HT-C5200/EDC Service Manual page 61

 Part List
Loc. No. Part No.
AD330 AH64-05292B
AD340 AH64-05293B
AD504 AH64-05321B
AF020 AH63-02108A
AS078 AH63-02006A
AS102 AH63-02007A
C011 AH61-02527A
CC02 AH64-05291F
D001A AK96-01214J
EF01 3103-001251
ES19 AH61-03102A
F001 AH63-02130A
FD23 AH64-05320A
FK01A AH96-00175B
FL06 3809-002517
FL06 3809-002518
FL261 3809-002351
FL261 3809-002357
FL261 3809-002359
HKF01 AH61-02963A
M0014 AH94-02433F
MA01A AH94-02430B
MF01A AH94-02431C
MK01A AH94-02432B
P001A AH94-02449D
T001 AH63-02119B
T0268 3903-000403
W275 6003-001561
W384 6002-000126
W392 6003-000282
Samsung Electronics This Document can not be used without Samsung's authorization.
Description;Specification
DECORATION-SIDE-L;HT-C5500,ABS,2.5,350,5
DECORATION-SIDE-R;HT-C5500,ABS,2.5,350,5
DOOR-HIDDEN;HT-C5500,ABS+PMMA,2.2,25,80,
FILTER-VFD;HT-C5500,PC,0.5T,90,25,VIOLET
SHEET-FUNCTION;HT-BD3250,PC T0.3,0.3,156
SHEET-POWER;HT-BD3250,PC T0.3,0.3,100,15
SPRING ETC-DOOR;HT-Z310,STS 304 WPS,0.2,
CHASSIS-BOTTOM;HT-C5500,EGI-SECC,0.8,430
ASSY ENGINE P-BD DECK;BD-P6C,OEM,1B
FAN-DC;12,80mA,2000rpm,0.11m^3/mi,0.62mm
SPRING ETC-HIDDEN;HT-C6500,STAINLESS-STS
COVER-FRONT;HT-C5500,ABS+PMMA,2.2,430,80
DOOR-BD;HT-C5500,ABS+PMMA,2.2,15,100,3,B
ASSY KNOB P-VOLUME;HT-C5500,BASIC,PMMA+A
FFC CABLE-FLAT;30V,80C,100mm,28P,1.0mm,U
FFC CABLE-FLAT;30V,80C,220mm,28P,1.0mm,U
FFC CABLE-FLAT;30V,80C,185mm,5P,1.0mm,UL
FFC CABLE-FLAT;30V,80C,90mm,15P,1.0mm,UL
FFC CABLE-FLAT;30V,80C,45mm,5P,1mm,UL206
HOLDER-KEY FUNCTION;HT-BD3250,ABS,13,60,
ASSY PCB MAIN;HT-C5500,BD HOME THEATER,E
ASSY PCB AMP;HT-C5500,BD HOME THEATER,EP
ASSY PCB FRONT;HT-C5200,BD HOME THEATER,
ASSY PCB KEY;HT-C5500,BD HOME THEATER,FR
ASSY PCB SMPS;HT-C5500_220V,BD HTS,1
COVER-TOP;HT-C5500,ABS,2.5,350,58,BLK
CBF-POWER CORD;AT,EU,CP2,HOUSING(2P),250
SCREW-TAPTYPE;BH,+,-,B,M3,L6,ZPC(WHT),SW
SCREW-TAPPING;FH,+,-,2S,M3,L10,ZPC(BLK),
SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW
Exploded View & Part List
Qty. SNA Remark
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SNA
1 SA
1 SNA
1 SNA
1 SA
1 SA
1 SNA
1 SA
1 SNA
1 SA
1 SA
1 SA
1 SA
1 SA
1 SNA
1 SA
1 SA
1 SA
1 SNA
1 SA
1 SA
1 SA
14 SA
2 SA
16 SA
5-2
