OUTDOOR COOKING
Outdoor Side Burner
AEB
Use & Care Manual
Installation & Operation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aspire AEB121NGOR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for hestan Aspire AEB121NGOR

Summary of Contents for hestan Aspire AEB121NGOR

  • Page 1 OUTDOOR COOKING Outdoor Side Burner Use & Care Manual Installation & Operation...
  • Page 2 Yes, we’ve taken the time to know our Aspire by Hestan customer and we’re excited to be on this journey with you. Aspire by Hestan was born from this same perfectionist passion. Our engineers experimented, innovated, tweaked and tinkered until they created the most powerful, versatile and reliable outdoor products available.
  • Page 3 Electrical Parts & Components – disconnect all power supplies and batteries before servicing. READ THIS MANUAL CAREFULLY AND COMPLETELY BEFORE USING YOUR GRILL TO REDUCE THE RISK OF FIRE, BURN HAZARD, OR OTHER INJURY. KEEP THIS MANUAL FOR FUTURE REFERENCE. ©2017 Hestan Commercial Corporation...

  • Page 4: Table Of Contents

    USING YOUR SIDE BURNER CLEANING AND MAINTENANCE TROUBLESHOOTING WIRING SCHEMATICS PARTS LIST SERVICE WARRANTY MODEL NUMBERS AEB122 AEB121 BUILT-IN MODELS Model No. Description AEB121-NG / -LP 12” BUILT-IN SINGLE SIDE BURNER AEB122-NG / -LP 12” BUILT-IN DOUBLE SIDE BURNER ©2017 Hestan Commercial Corporation...

  • Page 5: Rating Labels

    If any burner does not light, or goes out during operation, turn off all gas control knobs, and wait five (5) minutes before attempting to re-light. See the LIGHTING INSTRUCTIONS section of this manual. ©2017 Hestan Commercial Corporation...
  • Page 6 The hose and LP regulator are supplied as a complete assembly and must be replaced together. Do not attempt to repair or replace the hose itself. Contact your Hestan dealer for genuine replacement P/N 014309.
  • Page 7 Clean and perform general maintenance on the side burner twice a year. Watch for corrosion, cracks, or insect activity. See the CLEANING AND MAINTENANCE section of this manual. ©2017 Hestan Commercial Corporation...

  • Page 8: Regulatory / Code Requirements

    DEATH OR SERIOUS INJURY MAY OCCUR. 3. The LP cylinder must be disconnected and stored OUTSIDE in a well-ventilated area, out of the reach of children. 4. Do not store a full cylinder in direct sunlight. ©2017 Hestan Commercial Corporation...

  • Page 9: Installation

    A minimum of three 10 in² (65 cm²) of ventilation openings must be provided for both left and right sides of your enclosure (island), as well as the back. These openings are required to safely dissipate gas vapors if there is a leak in your enclosure. ©2017 Hestan Commercial Corporation...
  • Page 10 INSTALLATION (continued) BUILT-IN DIMENSIONS: ©2017 Hestan Commercial Corporation...

  • Page 11: Gas And Electrical Connections

    NOTE: See rating label for manifold pressure for the type of gas of your appliance. CONVERSION KITS Gas conversion kits are available from your Hestan dealer should you need to convert an LP unit to NG, or vice-versa. HIGH ALTITUDE KITS If you live in a high altitude area, 2,000 ft.
  • Page 12 Your side burner for use with Natural Gas is supplied with its own regulator which MUST be installed. If this regulator needs to be replaced, use only the type specified by Hestan for this appliance. TO CONNECT THE REGULATOR / HOSE ASSEMBLY FOLLOW THE NEXT STEPS: 1.
  • Page 13 CUSTOMER) Your Aspire Side Burner for use with an LP Piped System is supplied with its own convertible regulator which MUST be installed. If this regulator needs to be replaced, use only the type specified by Hestan for this appliance.
  • Page 14 This regulator/hose assembly must be used WITHOUT alteration. If this assembly needs to be replaced, contact your Hestan dealer for genuine replacement P/N 014309. NOTE: To ensure proper heating performance of this appliance, verify that the supply pressure is adequate.
  • Page 15 The hose and LP regulator are supplied as a complete assembly and must be replaced together. Do not attempt to repair or replace the hose itself. Contact your Hestan dealer for genuine replacement P/N 014309.
  • Page 16 NEVER ADJUST THE BURNER SO LOW THAT IT MAY GO OUT DURING USE. DO NOT OPERATE THE SIDE BURNER WITH THE LOW HEAT SCREW REMOVED. GAS CAN ESCAPE AND CAUSE A POTENTIALLY HAZARDOUS CONDITION. ©2017 Hestan Commercial Corporation...
  • Page 17 6. Adjust the flame so the burner is still fully lit on all ports, without fluttering or going out. Turn off the burner and re-light. Check the new low setting once again to assure proper adjustment is reached. Reattach the control panel, control knobs, and push-on the chin. Figure 2 ©2017 Hestan Commercial Corporation...

  • Page 18: Lighting Instructions

    If the burner does not light in 5 seconds, turn the control knob to “OFF” and wait 5 minutes before trying again. If the burner will not light after several attempts, see the TROUBLESHOOTING section of this manual. ©2017 Hestan Commercial Corporation...

  • Page 19: Using Your Side Burner

    These brown marks are only superficial stains, which will not harm the side burner. They should be removable using a soft damp cloth and a multi-purpose, non-abrasive, cream cleanser. Occasionally, it may be necessary to resort to a proprietary stainless steel cleanser to return the surface of ©2017 Hestan Commercial Corporation...
  • Page 20 You can gently clean them with a soapy water solution and a toothbrush. Wipe down with a clean cloth. NOTE: Rough handling of the igniter can crack the ceramic body, causing it to fail. Handle with care. ©2017 Hestan Commercial Corporation...
  • Page 21 For those in desert communities, wind-driven sand is highly abrasive and constant exposure will eventually pit and scratch the surface. Another reason to keep your grill and side burner covered when not in use. ©2017 Hestan Commercial Corporation...
  • Page 22 Orifice sized incorrectly for gas type Control panel LED lights not Power cord not plugged in, or no power to receptacle working Check fuse on electrical box. Nuisance clicking of side Windy conditions burner Flame too low Food debris on electrode ©2017 Hestan Commercial Corporation...

  • Page 23: Wiring Schematics

    WIRING SCHEMATIC ELECTRICAL BOX SINGLE ©2017 Hestan Commercial Corporation...
  • Page 24 WIRING SCHEMATIC WIRE HARNESS SINGLE ©2017 Hestan Commercial Corporation...
  • Page 25 WIRING SCHEMATIC ELECTRICAL BOX DOUBLE ©2017 Hestan Commercial Corporation...
  • Page 26 WIRING SCHEMATIC WIRE HARNESS DOUBLE ©2017 Hestan Commercial Corporation...

  • Page 27: Parts List

    PARTS LIST Please visit the Hestan website to access the parts list for your Aspire by Hestan product: www.hestanaspire.com. SERVICE All warranty and non-warranty repairs should be performed by qualified service personnel. To locate an authorized service agent in your area, contact your Hestan dealer, local representative, or the manufacturer.
  • Page 28 Product; damage from service by someone other than an authorized agent or representative of the Hestan Commercial Service Network; normal wear and tear; damage from exposure of the Product to a corrosive atmosphere containing chlorine, fluorine, or any other damaging chemicals;...
  • Page 29 This warranty gives you specific legal rights, and you may also have other rights which vary depending on location. Any questions about this Limited Warranty may be directed to Hestan Commercial Corporation at (888) 905-7463 ©2017 Hestan Commercial Corporation...
  • Page 30 Pièces et composants électriques – débrancher les alimentations électriques de toute nature avant de procéder à une opération d’entretien. LIRE CE MANUEL ATTENTIVEMENT ET ENTIÈREMENT AVANT D’UTILISER LE BRÛLEUR POUR LIMITER LES RISQUES D’INCENDIE, DE BRÛLURES OU D’AUTRES BLESSURES. CONSERVER CE MANUEL À TITRE DE RÉFÉRENCE. ©2017 Hestan Commercial Corporation...
  • Page 31 NUMÉROS DE MODÈLE AEB122 AEB121 MODÈLES ENCASTRÉS Numéro de Modèle Description AEB121-NG / -LP ENCASTRÉ BRÛLEUR LATÉRAL UNIQUE 12 po AEB122-NG / -LP ENCASTRÉ BRÛLEUR LATÉRAL DOUBLE 12 po ©2017 Hestan Commercial Corporation...
  • Page 32 Ne jamais utiliser une bouteille de GPL cabossée ou rouillée. Ne jamais raccorder ou débrancher une bouteille de GPL ni déplacer ou modifier les raccordements de gaz alors que le brûleur latéral est en marche ou Aspire chaud. ©2017 Hestan Commercial Corporation...
  • Page 33 être remplacé avant utilisation du brûleur latéral. Le tuyau et le détendeur de GPL sont fournis sous forme d’ensemble complet et doivent être remplacés comme tel. Ne pas essayer de réparer ou remplacer le tuyau seul. S’adresser au concessionnaire Hestan pour une pièce de rechange authentique, n° réf. 014309.
  • Page 34 Nettoyer le brûleur latéral et procéder à son entretien général deux fois par an. Rechercher tout signe de corrosion, de fêlure ou d’activité des insectes. Voir la section NETTOYAGE ET ENTRETIEN de ce manuel. ©2017 Hestan Commercial Corporation...
  • Page 35 LISTE DES PIÈCES Visiter le site Web Hestan pour consulter la liste des pièces de ce produit de plein air Hestan : www.hestanaspire.com. SERVICE Toutes les réparations dans le cadre ou en dehors de la garantie doivent être effectuées par du personnel d’entretien qualifié.
  • Page 36 Produit ; dommages résultant d’un service après vente assuré par quiconque autre qu’un agent ou représentant agréé du réseau commercial de Hestan ; usure normale et détérioration ; dommages résultant de l’exposition du Produit à une atmosphère corrosive contenant du chlore, du fluor ou toute autre substance chimique nuisible ;...
  • Page 37 Provinces ou Territoires, y compris certaines garanties implicites. La présente garantie confère des droits précis, auxquels peuvent s’en ajouter d’autres qui varient selon le lieu. Toute question relative à la présente Garantie limitée peut être adressée à Hestan Commercial Corporation au (888) 905-7463 ©2017 Hestan Commercial Corporation...
  • Page 40 RETAIN THIS MANUAL FOR FUTURE REFERENCE CONSERVEZ CE MANUEL POUR UNE RÉFÉRENCE FUTURE Hestan Commercial Corporation 3375 E. La Palma Ave Anaheim, CA 92806 (888) 905-7463 ©2017 Hestan Commercial Corporation P/N 015309 REV B...
