- Page 1 Owner’s manual OHM875VD OHM1075VD OHM1575VD OVERHEAD MONITOR SYSTEM WITH DVD PLAYER OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 1 OHMOwnersManual.indd 1 1/5/2007 12:26:41 PM 1/5/2007 12:26:41 PM...
-
Page 2: Table Of Contents
Clarion Dealer for assistance. Changes or modifi cations to this product not approved by the manufacturer will void the warranty and violate FCC Approval. - Page 3 General setup page ... 32 Speaker setup page ... 32 Preference page ... 33 7. TROUBLESHOOTING ... 34 8. GLOSSARY ... 37 9. SPECIFICATIONS ... 38 OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 3 OHMOwnersManual.indd 3 1/5/2007 12:26:57 PM 1/5/2007 12:26:57 PM...
-
Page 4: Features
Flexibility Designed primarily for rear seat entertainment, the audio from a OHM875VD / OHM1075VD / OHM1575VD can be enjoyed privately through wireless headphones and/or incorporated into any head unit. -
Page 5: Dvd Video Features
• Built-in IR transmitter for IR wireless headphones • IR remote control • Slot-in DVD mechanism OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 5 OHMOwnersManual.indd 5 10/30/40/40 ): for DVDs that provide multiple views of the same scene 1/5/2007 12:26:57 PM... -
Page 6: Precautions
2. PRECAUTIONS Failure to observe these precautions may damage your car, the monitor, or the video source, and may void the warranty. For questions or problems not covered in this manual, contact your local Clarion Dealer. Operating • Do not operate this product in ways other than those described in this manual. -
Page 7: Maintenance
Do not pour liquid into the unit or poke foreign objects into the DVD drive slot. Water, humidity, and foreign objects may damage internal circuitry. • If the unit becomes wet, turn off all power and ask your authorized Clarion Dealer to clean or service the unit. •... -
Page 8: Controls
OHMOwnersManual.indd 8 OHMOwnersManual.indd 8 Release button Previous button Next button Stop button Play or pause button Eject button ON OFF DOOR Dome light IR window OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:26:58 PM 1/5/2007 12:26:58 PM... -
Page 9: Dvd Drive Slot
DVD drive slot Insert DVD and CD discs into this slot Back seat View of the player from the front seat, passenger’s side OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 9 OHMOwnersManual.indd 9 sends IR signals to the headphones. select each menu item. -
Page 10: Monitor Open
Screw holes Used to attach the player to the mounting plate. OHMOwnersManual.indd 10 OHMOwnersManual.indd 10 ON OFF DOOR Screw hole Screw hole OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:26:59 PM 1/5/2007 12:26:59 PM... -
Page 11: Remote Control
Arrows Selects options on DVD menu and values on Display menu. Audio DVD: Changes the language during playback. For a VCD/CD: Changes audio channel (left, right, stereo) during playback. DISPLAY Displays playback information: title, chapter, track and time. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 11 OHMOwnersManual.indd 11 Setup Mute... -
Page 12: Operations
The monitor and DVD player provide the video; headphones provide the audio. The unit receives power from the power connector used for the car’s dome light, which the unit replaces. OHMOwnersManual.indd 12 OHMOwnersManual.indd 12 OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:26:59 PM 1/5/2007 12:26:59 PM... -
Page 13: Opening The Monitor
When closing the LCD panel, do not let cords or other items get caught between the LCD and the overhead housing. Doing so can seriously damage the TFT screen. For safety, close the LCD panel when you are not using it. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 13 OHMOwnersManual.indd 13 Release button... -
Page 14: Handling Discs
An IR receiver in the headphones that is exposed to direct sunlight for an extended period of time may cause poor sound quality. Let the headphones cool off before you use them. OHMOwnersManual.indd 14 OHMOwnersManual.indd 14 OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:26:59 PM 1/5/2007 12:26:59 PM... -
Page 15: Playing A Disc (Dvd Or Cd)
To mute the sound, press the MUTE button on the remote. Press this button again to enable sound again. Using headphones To hear the audio requires headphones. Do not use the headphones while driving. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 15 OHMOwnersManual.indd 15 WARNING 1/5/2007 12:27:00 PM... - Page 16 The volume control is on the headphones. Turn the volume dial up or down. Note: Some noise may be audible depending on the type of encoder software used while recording. This noise is not caused by the OHM875VD / OHM1075VD / OHM1575VD. OHMOwnersManual.indd 16 OHMOwnersManual.indd 16 Power light...
-
Page 17: Playing Dvds
To change the audible language, press the AUDIO button on the remote. The player displays the current language number and name, and the total number of languages available. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 17 OHMOwnersManual.indd 17 DVD root menu... - Page 18 To turn subtitles off, press the SUBTITLE button until the screen displays “subtitle off.” The display of the subtitle options disappears automatically if you wait for three seconds. OHMOwnersManual.indd 18 OHMOwnersManual.indd 18 Sample language option Sample subtitle option OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:01 PM 1/5/2007 12:27:01 PM...
- Page 19 To cycle through the available viewing angles, press the ANGLE button on the remote while playing back the DVD. The player displays the current angle number and the total number of angles available. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 19 OHMOwnersManual.indd 19 Sample repeat option...
- Page 20 Adjusts the differences between the light and dark areas of the image. Brightness Makes the whole image lighter or darker. Color Adjusts color based on the color spectrum. OHMOwnersManual.indd 20 OHMOwnersManual.indd 20 Sample angle options Setup options OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:01 PM 1/5/2007 12:27:01 PM...
-
Page 21: Playing Audio Cds
DVDs recorded in the United States). Wide Screen Selects the aspect ratio (width vs. height) of the image. Options are Wide (16:9) and Normal (4:3) for the OHM875VD and OHM1075VD. The OHM1575VD provides two additional options: Panorama and Zoom. -
Page 22: Playing Mp3S
MP3, a format for storing digital audio, compresses each audio track with little loss of audio quality. The result takes up much less disc space than the track would without MP3 compression. The OHM875VD / OHM1075VD / OHM1575VD player supports CD- R/RW and DVD-R discs that contain music MP3 fi les. -
Page 23: Care And Maintenance
The internal parts are not serviceable by the user. Opening any components will void the warranty. All warranty service should be performed by an authorized Clarion service center. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 23 OHMOwnersManual.indd 23... -
Page 24: Changing The Battery In The Remote Control
2. Simultaneously slide the battery latch in the direction of the arrow and pull the battery holder out of the slot. 3. Remove the old battery. OHMOwnersManual.indd 24 OHMOwnersManual.indd 24 CAUTION! Battery holder Battery latch Removing the battery holder OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:03 PM 1/5/2007 12:27:03 PM... -
Page 25: Installation And Wiring
Note: Use only the contents of this package to install and use the DVD player. Using accessories not provided with this player may damage the player. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 25 OHMOwnersManual.indd 25 Battery with the plus side... -
Page 26: Tools And Additional Components
Clarion Dealer or an authorized Clarion service center. Mounting and wiring precautions The OHM875VD / OHM1075VD / OHM1575VD should be mounted in the ceiling of the vehicle. The front panel controls should be easily accessible from the rear seat. In addition: •... -
Page 27: Installation Procedure
Installation procedure The OHM875VD / OHM1075VD / OHM1575VD replaces the car’s dome light. This section provides basic tips and techniques to aid the installation. These are not vehicle specifi c, but should be used as guidelines for performing the installation. - Page 28 1. Pull out the original dome light’s power wire and signal/power cable through the original dome light opening. 2. Place the rubber gasket on the player. Placing the rubber gasket on the player OHMOwnersManual.indd 28 OHMOwnersManual.indd 28 CAUTION OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:03 PM 1/5/2007 12:27:03 PM...
- Page 29 2. Screw in the four CM 4 x 8 screws making sure the wires are not in the way. 3. Reconnect the battery. 4. Check the car’s brake lights, blinkers, wiper, etc. to ensure they are working properly. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 29 OHMOwnersManual.indd 29...
-
Page 30: Wiring Diagram
1. Press SETUP on the remote to access the OSD menus. The main Display menu appears. OHMOwnersManual.indd 30 OHMOwnersManual.indd 30 B+ (yellow) ACC (red) GND(black) Door (green) OUT 2 A/V IN DOOR General setup page OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:04 PM 1/5/2007 12:27:04 PM... -
Page 31: Example: Setting Parental Control
The player prompts you for the password. 5. Type the password and press ENTER again to confi rm the password. 5. Press SETUP to exit the on-screen display menus. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 31 OHMOwnersManual.indd 31 (right arrow) to alternate among three option pages: (right arrow) to display the PREFERENCE PAGE. -
Page 32: General Setup Page
Enables the use the ANGLE button to select a different angle for the current scene. Disables the ANGLE button. Enables captions. Disables captions. Enables the screen saver feature. Disables the screen saver feature. OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:05 PM 1/5/2007 12:27:05 PM... -
Page 33: Preference Page
AUDIO Selects the audible language for the DVD audio track. ENGLISH, FRENCH, SPANISH SUBTITLE Selects the language for subtitles. ENGLISH, FRENCH, SPANISH OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 33 OHMOwnersManual.indd 33 Speaker page Preference page For Europe and Asia For the United States Turns subtitles off. -
Page 34: Troubleshooting
Some material unsuitable for children under 17. Not recommended viewing for children under 17. Only for adults due to the graphic content. This is the default setting. Reset button RESET Player with the monitor open OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:05 PM 1/5/2007 12:27:05 PM... - Page 35 You may be passing near a high voltage wire, transformer, aircraft or other source of electrical interference. The picture will improve when you move away from the source interference. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 35 OHMOwnersManual.indd 35 1/5/2007 12:27:06 PM...
- Page 36 IR transmitter on the player. Infrared transmitter Infrared receiver IR line of sight from the player to the headphones OHMOwnersManual.indd 36 OHMOwnersManual.indd 36 Line of sight OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:06 PM 1/5/2007 12:27:06 PM...
-
Page 37: Glossary
VCD: Video CD, the standard for storing video on a CD. Viewing angle: Pre-recorded alternative angles for individual scenes. WVGA: Wide Angle Video Array, the number of pixels in each direction that can be displayed on a monitor. OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 37 OHMOwnersManual.indd 37 1/5/2007 12:27:06 PM... -
Page 38: Specifications
Vertical adjustable up and down; maximum angle 180° 45/65/65/65 4.313 lbs (1.95 kg) 4.959 lbs (2.25kg) 1Vp-p, 75-Ohm load -5 ~ 55° C -20 ~ 70° C OHM875VD / OHM1075VD / OHM1575VD OHM1575VD 15.4” diagonal 1024x768 10/30/40/40 1/5/2007 12:27:06 PM 1/5/2007 12:27:06 PM... - Page 39 OHM875VD / OHM1075VD / OHM1575VD OHMOwnersManual.indd 39 OHMOwnersManual.indd 39 1/5/2007 12:27:06 PM 1/5/2007 12:27:06 PM...
- Page 40 Clarion Corporation of America All Rights Reserved. Copyright © 2006: Clarion Corp. of America OHMOwnersManual.indd 40 OHMOwnersManual.indd 40 Printed in China OHM875VD / OHM1075VD / OHM1575VD 1/5/2007 12:27:07 PM 1/5/2007 12:27:07 PM...
