OHM733
OHM833
7" LCD COLOR MONITOR
8" LCD COLOR MONITOR
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OHM733 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clarion OHM733

Summary of Contents for Clarion OHM733

  • Page 1 OHM733 OHM833 7” LCD COLOR MONITOR 8” LCD COLOR MONITOR OWNER’S MANUAL...

  • Page 2: Table Of Contents

    OWNER’S MANUAL NTRODUCTION The Clarion OHM733/OHM833 is a full-featured 7” / 8” LCD Color Monitor that can be used as for a mobile multimedia system. The OHM733/OHM833 has the following features: ． TFT Active Matrix Display ． Swivel Mechanism ． Adjustable Wide-Screen Format (16:9 / 4:3) (OHM733 only) ．...

  • Page 3: Precautions

    Small black and shiny dots inside the liquid crystal panel are normal for liquid crystal product. ● DESCRIPTION The OHM733/833 is a TFT active matrix color LCD monitor that delivers a striking picture and superior image resolution. The OHM733/833 can be used to enjoy video images with the Clarion video sources.

  • Page 4: Monitor Button Functions

    OWNER’S MANUAL MONITOR BUTTON FUNCTIONS DESCRIPTION OF IR REMOTE CONTROL POWER AV1/AV2 PICTURE SELECT Monitor Release Button Dome Light Switch Power Button Mode Selector FM Modulator On/Off Button Auxiliary Input Selector IR Sensor Power LED Not Applicable Power Button for Monitor Powers on monitor.

  • Page 5: Using Remote Control

    USING REMOTE CONTROL Inside the vehicle, simply aim the IR Remote Control directly at the OHM733/OHM833, or at a Clarion monitor, or video source with an IR eye input and press any desired button for better results. Also note the following: Aim the IR Remote Control from no further than 2 Meters away and no more than 0.9 Meters...

  • Page 6: Installation Instructions

    Run necessary wires to the mounting location. When necessary cut the headliner and pull wires through. Use a 30cm x 30cm x 2cm or 1.2cm think piece of plywood to mount the OHM733/OHM833. Silicone the piece of plywood to the top of the roof or screw the plywood to the dome light mounting assembly and or the roof support rail.

  • Page 7: Dome Light Wiring

    White : Door Switch DOME LIGHT ON/OFF SWITCH DESCRIPTION A three-position slide switch controls the lights integrated into the OHM733/OHM833 sliding the switch to the ON position will turn the lights on. The OFF position will prevent the lights from turning on at all times and the auto position will allow the lights to turn on and off with the vehicle interior lighting.

  • Page 8: Picture Adjustments

    To adjust the picture use the mode button to select the mode feature you would like to Adjust. Adjustment selections are as follow: Contrast ● Brightness ● Color ● Wide screen ON/OFF (OHM733 only) ● Tint ● Press the up button to increase and the down button to decrease. FM MODULATOR (FM201) SYSTEM DIAGRAM...

  • Page 9: Complete A/V System Diagram

    OHM733,OHM833 COMPLETE A/V SYSTEM DIAGRAM...

  • Page 10: Care And Maintenance

    OHM733 Dimensions: OHM833 Dimensions: OHM733 Weight: OHM833 Weight: Operation Temperature ONITOR PECIFICATIONS: Display Type: OHM733 Display Screen Size: 7.0” OHM833 Display Screen Size: 8.0” Format Screen Resolution: Video Signal Video System Car Battery (DC 9-16V) DC 12V 15W (without Dome lights) Less than 1.5A (without Dome lights)
