  • Page 1 OHM641 6.4” LCD Color Monitor OWNER’S MANUAL...

  • Page 2: Table Of Contents

    INTRODUCTION The Clarion OHM641 is a full-featured 6.4" LCD Color Monitor. It can be integrated into a mobile multimedia system. The OHM641 has the following features: • 6.4” wide-screen color LCD panel • A bright, clear screen • Video input terminal...

  • Page 3: Description

    DESCRIPTION The OHM641 has a TFT active matrix color LCD monitor which delivers a striking picture and superior image resolution. The OHM641 can be used to enjoy video images with the Clarion VCP9600 or DVD9600, even if no TV tuner is connected.

  • Page 4: Wiring Precautions

    3. When connecting the ground lead, fasten the ground lead (black) securely to a clean metal plate on the vehicle. NOTE: The OHM641 mointor displays video images only. It does not provide audio output. Refer to the owner’s manual of the connected device for information on audio output.

  • Page 5: Picture Adjustment

    Brightness To adjust the picture brightness, use the Brightness UP and DOWN buttons located on the front panel of the OHM641. Press the UP button to increase the picture brightness. Press the DOWN button to decrease the picture brightness. Viewing Angle To adjust the viewing angle gently tilt the cabinet to the desired posiion.

  • Page 6: Applications

    IR extension into the Y connector. 5. At the OHM641, plug the IR extension and power cables supplied with the OHM641. Run these cables to the back of the video player. Plug the video RCA into the video output of the player.
  • Page 7 • Turn the modulator and the radio on and tune to the modulated frequency. Turn the FM100S’s switch on. The audio can now be heard over the sound system. You can control the video player and the TV tuner by pointing their respective remotes at the IR eye in the monitor.
  • Page 8 2. Mount the TV antenna (ZCB-303 or equivalent) and plug into the tuner. 3. At the OHM641, plug in the video RCA, IR extension and power cables supplied with the OHM641 and run to the tuner. Plug the video RCA and IR extension into the tuner.

  • Page 9: Optional Remote Control Battery Installation

    OPTIONAL REMOTE CONTROL BA TTERY INSTALLATION • Insert 2 AAA batteries into the compartment located on the back of the unit, observing the proper polarity. NOTES: • Each time you change the batteries, you must reprogram the channels. • We suggest you use alkaline batteries; do not use rechargeable batteries. •...

  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE Cleaning the cabinet: • Use a soft, dry cloth to gently wipe off any dirt. • Do not use benzene, thinner, car cleaner, etc., as these substances may damage the cabinet or cause the paint to peel. Cleaning the LCD panel: •...

  • Page 11: Product Specs

    Problem: The power was turned off when driving on bumpy roads. Solution: • Severe vibration to the operation panel activated the DCP’s sensor. Press the POWER button again to turn the power ON. PRODUCT SPECS Display Type: Screen Size: Pixels: Screen Resolution: Power Source Voltage: Power Consumption:...
  • Page 12 661 W. Redondo Beach Blvd. Gardena, CA 90247 1-800-GO-CLARION www.clarion-usa.com OHM641-10 Rev.3 (03/00)
