Overhead video monitor

Advertisement

Quick Links

Warning!
THE CLARION OHM653 OVERHEAD VIDEO MONITOR IS
DESIGNED TO BE VIEWED BY REAR-SEAT OCCUPANTS
ONLY!
CLARION VIDEO PRODUCTS ARE NOT INTENDED FOR
VIEWING BY THE DRIVER WHILE THE VEHICLE IS IN MOTION.
SUCH USE MAY DISTRACT THE DRIVER OR INTERFERE WITH
THE DRIVER'S SAFE OPERATION OF THE VEHICLE, AND
THUS RESULT IN SERIOUS INJURY OR DEATH. SUCH USE
MAY ALSO VIOLATE STATE LAW.
CLARION DISCLAIMS ANY LIABILITY FOR ANY BODILY
INJURY, INCLUDING FATALITIES, OR PROPERTY DAMAGE
THAT MAY RESULT FROM ANY IMPROPER OR UNIN-
TENDED USES OF THIS PRODUCT.
About Installation
Installation of mobile audio and video components requires
experience with a variety of mechanical and electrical proce-
dures. Even though this manual provides general installation
and operation instructions for your new Clarion OHM653
Overhead Video Monitor, it does not show the exact installa-
tion methods for your particular vehicle.
If you do not have the required knowledge and experience to
successfully complete the installation, we strongly recommend
consulting an authorized Clarion dealer about professional
installation options.
OHM 653 122302.p65
1

Table of Contents

1. Introduction .................................................................... 2
2. Care and Maintenance .................................................. 3
3. Using the OHM653 .......................................................... 3
5. The Remote Control ....................................................... 5
6. Installation and Wiring ................................................... 7
7. Troubleshooting ........................................................... 15
8. Specifications ............................................................... 15
9. Limited Warranty Information ..................................... 16
12/23/02, 10:40 PM
